Contents
Chapter 1 Quick Installation .................... 3
1.1 Layout ...................................................................................... 3
1.2 CPU setting .............................................................................. 4
1.3 Jumpers .................................................................................... 4
1.4 Expansion Slots / Sockets ....................................................... 7
1.5 Connectors ............................................................................... 9
1.6 Form Factor ........................................................................... 16
Chapter 2 Overview................................. 17
2.1 What is RAID? ....................................................................... 18
2.2 What is IDE RAID? ............................................................... 18
Chapter 3 Features .................................. 20
3.1 Motherboard Components Placement .................................. 20
3.2 Back Panel ............................................................................. 22
3.3 Block Diagram ....................................................................... 23
3.4 Specifications ......................................................................... 24
Chapter 4 Hardware Setup ..................... 26
4.1 Before Installation ................................................................. 26
4.2 Jumper setting ....................................................................... 26
4.3 Install the Processor .............................................................. 29
4.4 Install Memory Modules ....................................................... 33
VD133 Pro\ VD133 PLVer1.2A
FB11342310000
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for IWILL VD133 Pro Series
Summary of Contents for IWILL VD133 Pro Series
-
Page 1: Table Of Contents
Contents Chapter 1 Quick Installation ....3 1.1 Layout ..................3 1.2 CPU setting ................4 1.3 Jumpers ..................4 1.4 Expansion Slots / Sockets ............7 1.5 Connectors ................9 1.6 Form Factor ................16 Chapter 2 Overview......... 17 2.1 What is RAID? ............... - Page 2 5.14Save & Exit Setup ..............75 5.15Exit Without Saving ............. 75 Chapter 6 Power Installer CD....76 6.1 Software Installation ............. 76 6.2 How to use the Power installer CD ........76 6.3 Installing Operating Systems ..........78 VD133 Pro Series...
-
Page 3: Chapter 1 Quick Installation
Several easy installation steps will be described in this chapter to help the experienced users with quick installation. If you are a beginner, or need to know more about this product, please refer to Hardware Setup. Layout VD133 Pro Series... -
Page 4: Cpu Setting
Pentium III 533EB 1.65V, FCPGA 533Mhz(133x4) Pentium III 600EB 1.65V, FCPGA 600Mhz(133x4.5) Pentium III 667EB 1.65V, FCPGA 667Mhz(133x5) Pentium III 733EB 1.65V, FCPGA 733Mhz(133x5.5) Jumpers 1.3.1 JP1 (CMOS) Clear CMOS jumper The jumper is for BIOS setting value. VD133 Pro Series... - Page 5 CPU. Place the jumper cap over pins 1-2 to increase 5% more voltage to the processor’s Vcore. Place the jumper cap over pins 2-3 to increase 10% more voltage to the processor’s Vcore. 1.3.3 JP10(VIO) VIO select jumper This jumper is used to select the VIO voltage. VD133 Pro Series...
- Page 6 1.3.4 JP13 (AC 97) AC97 Codec Enabled / Disabled jumper This jumper is used to enabled / disabled the onboard audio CODEC. 1.3.5 JP70(VD133 Pro only) This jumper is used to disable/enable the IDE RAID function.No jumper cap is used to disable IDE RAID. VD133 Pro Series...
-
Page 7: Expansion Slots / Sockets
Chapter 1 Quick Installation Expansion Slots / Sockets 1.4.1 J1(Socket 370) Processor socket 1.4.2 J3—J5 (DM0—DM2) 168-Pin DIMM Sockets Install memory in any combination as follows: VD133 Pro Series... - Page 8 Single-Side Module Double-Side Module Single-Side Module Double-Side Module Single-Side Module Double-Side Module Total System Memory (Max1.5 GB) 1.4.3 J12—J16 (PCI 1—PCI 5) PCI expansion slots The connectors are Bus Master PCI Expansion Slots. 1.4.4 J27 (AMR) AMR Slot VD133 Pro Series...
-
Page 9: Connectors
Chapter 1 Quick Installation 1.4.5 J11 (AGP) AGP Slot Connectors 1.5.1 J28 (IDE0) Primary ATA/66 IDE channels 1.5.2 J29 (IDE1) Secondary ATA/66 IDE channels VD133 Pro Series... - Page 10 Chapter 1 Quick Installation 1.5.3 J65(IDE2) The Third ATA/66 IDE channels(VD133 Pro only) 1.5.4 J66(IDE3) The Fourth ATA/66 IDE channels (VD133 Pro only) 1.5.5 J30 (FDC) Floppy connector VD133 Pro Series...
- Page 11 Chapter 1 Quick Installation 1.5.6 J37 ATX power connector 1.5.7 J39(FCPU)&J41(FSYS) fan connectors on this motherboard. The J39 (FCPU) is designed to support CPU fan; the J41 (FSYS) is for system fan used . VD133 Pro Series...
- Page 12 Chapter 1 Quick Installation 1.5.8 J43 This connector is composed of all the headers that may be connected to the front panel of the chassis. 1.5.9 J45 (IR) This connector is designed for the SIR devices. VD133 Pro Series...
- Page 13 Chapter 1 Quick Installation 1.5.10 J46 (WOL) This is the Wake-on-LAN connector. In order to wake up the system through a plug- in network card, the card must provide a high active wake signal. 1.5.11 J46(MODEM) VD133 Pro Series...
- Page 14 Chapter 1 Quick Installation 1.5.12 J48(SMBUS) 1.5.13 J54 (CD_IN) The audio output can be transfered from CD-ROM to the audio system This connector can be connected for mid-to-low speed devices such as mice, keyboards, joysticks,etc. VD133 Pro Series...
- Page 15 1.5.14 J54A (USB1) The motherboard provides four USB support for the commonly found USB devices now a days. The motherboard has two USB ports onboard. The extra two USB support can only functionable with the additional USB riser kit. VD133 Pro Series...
-
Page 16: Form Factor
Chapter 2 Overview Form Factor VD133 Pro Series... -
Page 17: Chapter 2 Overview
Chapter 2 Overview Thank you for purchasing the IWILL VD133 Pro series motherboard. This operation manual will instruct you how to configure and install the system properly. It contains an overview about the engineering design and features of this product. Also, this manual provides useful information for later upgrades or configuration changes. -
Page 18: What Is Raid
RAID was associated with SCSI interface only in the past. The capital outlay generally puts people out of the door. This situation is about to change with the introduction of IWILL VD133 Pro™. A high performance IDE RAID host adapter, with Ultra ATA66 interface. The SIDE RAID66™ offers RAID 0 (Striping), RAID 1 (Mirroring) and RAID 0+1 (Striping + Mirroring) functions, and supports the Ultra ATA 33/66 hard disks commonly found in the market today. - Page 19 Iwill Corporation reserves the right to change product specifications at any time without notice. Applications described in this document for any of these products are for illustrative purposes only.
-
Page 20: Chapter 3 Features
Chapter 3 Features Chapter 3 Features This motherboard are well designed for the user. Who wants the most stable plat form, best perform- ance/price ratio and convenience. Motherboard Components Placement VD133 Pro Series... - Page 21 The Fourth IDE Connector (VD133 Pro only) Programmable BIOS 32bit/33MHz Bus Master PCI Slot AMR Slot Joystick, Midi Line Out ,Line in, Microphone In Connector COM1Connector Parallel Connector COM2Connector USB1 Connectors tor. PS/2 Mouse, PS/2 Keyboard Connec VD133 Pro Series...
-
Page 22: Back Panel
Chapter 3 Features Back Panel VD133 Pro Series... -
Page 23: Block Diagram
Chapter 3 Features Block Diagram VD133 Pro Series... -
Page 24: Specifications
Supports two high-speed 16550A serial ports Supports one ECP/EPP parallel ports Supports one PS2 mouse port Supports one PS2 keyboard port Provides One Game/MIDI port to support two joysticks Supports one SIR port Supports PS2 mouse and PS2 keyboard VD133 Pro Series... - Page 25 Supports “AC-Loss Recovery”(Former status/OFF) Supports Suspend to RAM Supports suspend to Disk BIOS Support 2M flash ROM Support Plug & Play Supports APM 1.2 Supports DMI 2.1 Supports ACPI 1.0 Year2000 compliance Others ATX Form Factor 30.5“ x 18.8” VD133 Pro Series...
-
Page 26: Chapter 4 Hardware Setup
1-2, place onto pins 2-3, and then place back onto pins 1-2 again. Then, turn on your computer, press <Del> key during boot up and enter the BIOS setup program to re-set your preferences. VD133 Pro Series... - Page 27 4.2.3 JP10 VIO select jumper (Vio) This jumper allows you to select the voltage supplied to the DRAM, chipset, PCI and the CPU’s I/O buffer. The default voltage should be used unless processor over- clocking requires a higher voltage. VD133 Pro Series...
- Page 28 CODEC must be disabled when using an ISA/PCI audio card or a primary AMR card. 4.2.5 JP70 (VD133 Pro only) This jumper is used to disable/enable the IDE RAID function.No jumper cap is used to disable IDE RAID. VD133 Pro Series...
-
Page 29: Install The Processor
Chapter 4 Hardware Setup Install the Processor c i f a i l The motherboard is provides a ZIF Socket 370. Step1: Locate the ZIF socket and open it by first pulling the lever of socket upward. VD133 Pro Series... - Page 30 Insert the CPU into the socket. Please keep the lever right angle when inserting CPU. Step3: When inserting the CPU please note the correct orientation as shown. The notched corner should point toward the end of the lever. l l i t i f VD133 Pro Series...
- Page 31 Chapter 4 Hardware Setup Step4: Push the lever down to close the socket. Step5: Attach the heatsink onto the CPU. VD133 Pro Series...
-
Page 32: Install Memory Modules
SDRAM modules of 16M, 32M, 64M, 128M and 256M. The motherboard also support SPD (Serial Presence Detect) architecture to provide the best choice for performance vs. stability. l l i l l i a l i . e l VD133 Pro Series... - Page 33 Total System Memory (Max1.5 GB) Step 1:Open latches of DIMM socket Step 2:Proofread the RAM module to the DIMM Socket Step 3:Insert the RAM module into the Step 4:Press the latches into the notches DIMM Socket of the RAM module VD133 Pro Series...
-
Page 34: Install Pci Expansion Cards
There are two type of AMR card, one defined as primary and another defined as secondary. This motherboard uses the primary channel so that a secondary AMR card can coexist without the need to disable the onboard audio CODEC. The onboard audio CODEC must be disabled when using a primary AMR card. VD133 Pro Series... -
Page 35: Usage Of The Agp Slot
OS to access large textures outside the local graphic memory of the card. In order to take advantage of the DIME feature, some software components should be installed or upgraded within your system. VD133 Pro Series... -
Page 36: Connect Devices And Power Supply
A legacy ATA (IDE) drive can coexist with an Ultra ATA/66 drive. However, for the Ultra ATA/66 device to attain Ultra DMA 4 mode, an Ultra ATA/66 capable cable is required. VD133 Pro Series... - Page 37 This motherboard has one floppy connector to support 360K, 720K, 1.2M, 1.44M, 2. 88M, 3 Mode floppy drives and QIC-80 floppy tape drive. After connecting the single end to the board, connect the two plugs on the other end to the floppy devices. VD133 Pro Series...
- Page 38 This connector can be used to support a PS/2 keyboard. 4.8.4.3 Universal Serial Bus Connectors This motherboard has two USB ports, any USB-compatible peripherals and/or hub can be connected into either USB port. , r o l l i VD133 Pro Series...
- Page 39 You may use the hardware monitoring utility to monitor the Rotations per Minute (RPM) of the fan. 1. The CPU will overheat if there is no airflow across the CPU heatsink. 2. Damage may occur to the CPU fan and/or motherboard if these pins are incorrectly used. VD133 Pro Series...
- Page 40 4.8.6.5 System Power LED Connector (PLED) This 3-pin connector connects to the case-mounted system power LED, which lights when the system is powered on. 4.8.6.6 Speaker Connector (SPKR) This 4-pin connector connects to the case-mounted speaker. VD133 Pro Series...
- Page 41 You may need to enable the “Wake Up by Ring/LAN” feature in the BIOS setup program. b. Your system must have a ATX power supply with at least 720mA 5VSB power. c. This motherboard only supports the LAN card with a high-active wake signal. VD133 Pro Series...
- Page 42 This connection works in conjunction with your modem card. If you intend to use a modem card (inserted into the PCI slot), please connect the cable from the modem card into the Modem header. 4.8.10 SMBUS connector J48 (SMBUS) This connector provides the connectivity of SMBUS utilization. VD133 Pro Series...
- Page 43 Chapter 4 Hardware Setup 4.7.11 Internal Audio Connector (CD_IN) This connect allow you to receive stereo audio input from such sound sources as a CD-ROM, TV tuner or MPEG card. 4.8.12 USB 1 VD133 Pro Series...
- Page 44 Many of the power supply support 110V/220V by a switch setting. Switch your power supply to the correct supply voltage (refer to the power supply’s manual). 4.8.14.6 Turn on your system in the following order: The monitor. (2). The external devices. VD133 Pro Series...
- Page 45 Shut down your operating system. 4.8.15.3 Switch off the power button. If you are using Windows 95/98, the power supply should turn off automatically after Windows shut down 4.8.15.4 Turn off all the external devices. 4.8.15.5 Turn off your monitor. VD133 Pro Series...
-
Page 46: Chapter 5 Bios Setup
5.1.1 Upgrade BIOS The BIOS can be upgraded from a diskette with the Award Flash utility — AWDFLASH.EXE. The BIOS image file, and update utility are available from IWILL’s WEB site: www.iwill.net 5.1.2 Enter BIOS setup program Power-on the system by either pressing the Power-On button, or by using any of the power-on features provided by the motherboard. -
Page 47: Main Menu
The main menu allows you to select from several setup pages. Use the arrow keys to select among these pages and press <Enter> key to enter the sub-menu. A brief description of each highlighted selection appears at the bottom of the screen. VD133 Pro Series... -
Page 48: Standard Cmos Features
Selects the type of fixed disk. Auto (*) BIOS automatically fills in the values for the cylinders, heads and sectors fields None Any Disk Drives are attached 5.3.3.3 Capacity Auto Display your disk drive size VD133 Pro Series... - Page 49 No 3 Mode drive is connected Drive A A 3 Mode drive is connected as drive A Drive B A 3 Mode drive is connected as drive B Both Both drive A and drive B are 3 Mode drives VD133 Pro Series...
- Page 50 The BIOS determines how much extended memory is present during the POST. This is the amount of memory located above 1MB in the processor’s memory address map. This field has no options. 5.3.10 Total Memory Displays the total memory available in the system VD133 Pro Series...
-
Page 51: Advanced Bios Features
If you run such a program, we recommend that you first disable the Virus Warning function beforehand. Options Enabled Disabled (*) 5.4.2 CPU Internal Cache This field configures the CPU internal cache (L1 cache). Options Enabled (*) Disabled VD133 Pro Series... - Page 52 5.4.7 First / Secondary / Third / Other Boot Device The BIOS attempts to load the operating system from the devices in the sequence selected in these items. Options Floppy (*) LS/ZIP HDD-0 (**) SCSI CD-ROM HDD-1 HDD-2 HDD-3 RAID66) (***) (VD133 Pro only) Disable VD133 Pro Series...
- Page 53 1 MB. At first, the gate A20 was handled from a pin on the keyboard. While some keyboards still provide this support, it is more common, and much faster, for modern system chipsets to provide support for gate A20. Options Description Fast support by core logic Normal(*) Disable VD133 Pro Series...
- Page 54 When enabled, this field allows you to access the memory that is over 64MB under OS/2. Options OS/2 Non-OS/2 (*) 5.4.18 Report No FDD For WIN 95 For a floppy diskless system that runs Windows 95, this field should be set to Yes. Options No (*) VD133 Pro Series...
-
Page 55: Advanced Chipset Features
Such a scenario might well occur if your system had mixed speed DRAM chips installed. Longer delays might result, however this preserves the integrity of the data held in the slower memory chips. VD133 Pro Series... - Page 56 In order to improve performance, certain space in memory is reserved for ISA cards. This memory must be mapped into the memory space below 16MB. Note: This field is for experienced users only. Options 15M-16M Disabled (*) VD133 Pro Series...
- Page 57 The chipset has embedded 32-bit posted writer buffer to support delayed transaction cycles. When enable, the system is compliant with PCI specificationversion 2.1 Options Enabled (*) Disabled 5.5.10 System BIOS cacheable When enable accesses to the system BIOS will be cached Option Enable(*) Disable VD133 Pro Series...
- Page 58 This should be enabled if your system have USB port 1 internal on the system board and you wish to use it. Even when so equipped, if you add a higher performance controller, you will need to disable this feature. Options Enabled Disabled (*) VD133 Pro Series...
-
Page 59: Integrated Peripherals
This field enables or disables the onboard IDE controller. Options Enabled (*) Disabled 5.6.3 Primary Master/Slave PIO These fields configure the PIO (Programmable Input Output) transfer mode for IDE controller. The maximum transfer rates of each PIO mode are listing as follo VD133 Pro Series... - Page 60 This item allows you to decide which slot to activate first, either PCI slot or AGP slot. This function takes place during the system boot. Options PCI Slot AGP (*) 5.6.7 AC97 Audio This item allows you to decide to enable/disable theVIA chipset family to support AC97 Audio. Options Auto press Enter VD133 Pro Series...
- Page 61 Game port Address This item allows you to select game port enable/disable. Option Disable 200-207H(*) 5.6.8 AC97 Modem This item allows you to decide to enable/disable the VIA chipset family to support AC97 Modem. Options Auto(*) Disable VD133 Pro Series...
- Page 62 Hi, Lo (*) / Lo, Hi / Lo, Lo / Hi, Hi 5.6.12.2 IR Duplex Mode When setting the field to either HPSIR or ASKIR, you must select the mode of receiving and transmitting signals. Options Half (*) / Full VD133 Pro Series...
- Page 63 DMA channel and the EPP version need to be specified. Please check the specifications before selecting field. DMA Options Description Use DMA channel 1 3 (*) Use DMA channel 3 EPP Options Description EPP1.7 Use EPP 1.7 protocol EPP1.9 (*) Use EPP 1.9 protocol VD133 Pro Series...
-
Page 64: Power Management Setup
This field specifies the timer value of Doze Mode. It is available only when the Power Management field set to User Define. Options 1 Min / 2 Min / 4 Min /6 Min / 8 Min /10 Min/ 20 Min 30 Min / 1 Hour / Disable (*) VD133 Pro Series... - Page 65 Options Description V/H SYNC+Blank Turn off the vertical and horizontal synchronization ports and write blanks to the video buffer Blank Screen Writes blanks to the video buffer only DPMS (*) Initial display power management signaling with DPMS VD133 Pro Series...
- Page 66 When On, any activity from one of the listed system peripheral devices or IRQs wakes up the system. Options None LPT/COM (*) 5.7.9.3 HDD & FDD When On, any activity from either hard disk drive or floppy disk drive wakes up the system. Options ON (*) VD133 Pro Series...
- Page 67 I/O device wants to gain the attention of the operating system, it signals this by causing an IRQ to occur. When the operating system is ready to respond to the request, it interrupts itself and performs the service. VD133 Pro Series...
-
Page 68: Pnp/ Pci Configurations
Normally, you leave this field Disabled. Select Enabled to reset Extended System Configuration Data (ESCD) when you exit Setup if you have installed a new add-on and the system reconfiguration has caused such a serious conflict that the operating system can not boot. Options Enabled Disabled (*) VD133 Pro Series... - Page 69 This field determines the IRQ setting forPCI2. The default setting for this field is Auto, which uses automatic-routing to determine the setting. Options Auto (*) / 3 / 4 / 5 / 7 / 9 / 10 / 11 / 12 / 14 / 15 VD133 Pro Series...
-
Page 70: Pc Health Status
Options Auto (*) / 3 / 4 / 5 / 7 / 9 / 10 / 11 / 12 / 14 / 15 PC Health Status This page is monitoring your status of computer. On the screen displays CPU/System temperature, FAN speed, and voltages. VD133 Pro Series... -
Page 71: Iwill Smart Setting
Chapter 5 BIOS Setup 5.10 IWILL Smart Setting Over-clocking is not guaranteed. Users must have substantial knowledge of proper CPU relative to adjusting CPU speeds. Over-clocking should be done only by experienced engineers who conduct tests. 5.10.1 Auto Detect DIMM/PCI Clk When enabled, the motherboard will automatically disable the clock source for a DIMM socket, which does not have a module on it. -
Page 72: Load Fail-Safe Defaults
When you press <Enter> on this item you get a confirmation dialog box with a message similar Pressing ‘Y’ loads the BIOS default values for the most stable, minimal-performance system operations. on this item you get a confirmation dialog box with a message similar to: VD133 Pro Series... -
Page 73: Load Optimized Defaults
To disable a password, bring the cursor to this field, then press <Enter>. The computer will display the message, “Enter Password”. Press <Enter>. A message will confirm that the password is disabled. Once the password is disabled, the system will boot and you can enter setup program freely. VD133 Pro Series... -
Page 74: Save & Exit Setup
Chapter 5 BIOS Setup o l l e i f 5.14 Save & Exit Setup Saves current CMOS value and exit BIOS setup program. 5.15 Exit Without Saving Abandons all CMOS value changes and exits BIOS setup program. VD133 Pro Series... - Page 75 Chapter 5 BIOS Setup VD133 Pro Series...
-
Page 76: Chapter 6 Power Installer Cd
Power Installer CD Software Installation The attached Power Installer CD contains all the necessary drivers, utilities for IWILL’s full range of motherboards. It provides an easy way for users to install the needed drivers without going through a complicated process. The Power Installer CD is able to auto-detect and display the drivers, utilities needed for your motherboard. - Page 77 Chapter 6 Power Installer CD 6.2.1 How to view manual This Power Installer CD includes detailed information of all IWILL manuals for every motherboard manufactured by IWILL. Please insert the IWILL Power Installer CD into the CD-ROM drive; Click the “View Manual” item, and select the product that you want to view.
- Page 78 6.2.6 How to install Iwill SIDE RAID 66 Utility (VD133 Pro only) You may just click on the Iwill SIDE RAID 66 Installation Utility shown on screen . Please follow the istructions to install the network driver.
-
Page 79: Installing Operating Systems
Press <ENTER>. Microsoft ScanDisk will check your disk drives for errors. When ScanDisk finishes, press the X key. Setup will initialize. Then, Windows 98 Setup begins. Please follow the instructions that are displayed. VD133 Pro Series... - Page 80 Select “Boot Sequence” and change the default setting from A, C, SCSI to “CD-ROM, C, A” using Page Up /Page Down key. Place the Windows NT 4.0 CD-ROM in the drive. Follow all instructions to finish Windows NT installation. VD133 Pro Series...
