Ethernet
2ND LEVEL
IP Mode
Static IP Config
IP Address
Subnet Mask
Gateway
Link Status
IP Mode
IP Address
Subnet Mask
Gateway
MAC Addr.
1) IP Mode: Set the unit's IP address mode to Static or DHCP.
2) Static IP Config: When the unit is in Static IP mode the IP address,
netmask and gateway addresses may be manually set here. Changes
will occur immediately.
Note: Only editable in Static IP mode.
3) Link Status: Displays the unit's current IP configuration and the unit's
MAC address.
23
3RD LEVEL
STATIC
DHCP
X.X.X.X [192.168.1.50]
X.X.X.X [255.255.255.0]
X.X.X.X [192.168.1.254]
[Current IP Mode]
[Current Network Info]
[Unit's MAC Address]
