FLIR TruWITNESS Quick Manual

1. TruWITNESS SENSORY

2. TruWITNESS PCS

(Power/Communications/Storage Unit)

3. Mounting Hardware

Safety Glasses
Collar/Cap

Attaching Sensory to Mount

1. Plug the cable into the Sensory.
2. Slide the sensory into the mount with
the bottom toward the release clip (1)
3. Push until there is a click
Note: When mounted, the cable cannot be detached from the sensory unless removed from the mount
All mounting hardware can be rotated, and therefore can be used on
- Always mount the Sensory with the Alarm button facing outwards.
TruWITNESS Wearer's Quick Guide
Vest/Epaulette
1/4" - 20 Fixed
The mounts use a universal mounting clip, making

Wearing your Sensory

*Left or Right?
The Sensory knows which way is 'up' .
either the left or right side of the body / head / glasses
The Wearable Sensory includes:
·
Hi-Res Camera
·
User controls
·
User and Ambient Microphones
·
Speaker
·
Gyroscope, Accelerometer
·
Optional attachment hardware, giving flexible wearer options.
ALARM
FLIR Logo Button
(Long Press)
The Power/Communications/Storage Unit shows:
·
Status Display (OLED)
The PCS display shows the User the unit's key status indicators
- Battery level, Communications status,
On-board Recording status
·
Battery Condition
- when below 5% the user will also get a 'low battery' message
·
Communications Status
- shows 3G/4G status
·
Recording status
- The PCS records continuously (even when in Live mode),
except when the user sets it to 'Privacy'
·
Text Message
- The default message shows the User Name.
Other Status messages listed overleaf.
Note: For T cables, power source with 1.8A to 2.5A should be used (no
less than 1.8A) – DO NOT CONNECT TO PC USB – USE A DEDICATED
POWER SOURCE
the process the same for all types.

Sensory Controls

Privacy On/OFF
Top/Bottom

4. 'L' and 'T' Cables

Detaching Sensory from Mount

1. Pull the release clip out, away from the
sensory (1)
2. Push the sensory from the bottom in
the direction of the lens
Glasses
EVENT
FLIR Logo Button
(Short Press)
together
Cap Shoulder
