ADJUSTING TO THE BODY SIZE

Adjusting the Headrest
NOTE! The headrest (13) ensures the best possible
protection for your child only if it is adjusted to the optimum
height. There are 12 height positions that can be set.
• The headrest must be adjusted so that max. 3 cm (ca. two
finger's width) or less remains free between the child's
shoulder and the headrest.
• Activate the adjustment handle (14) on the bottom side of
the headrest (13) and move it into the required position.
NOTE! The shoulder wings of car seat are connected with the
headrest and do not have to be moved separately.
