AZZA 845D-AV Manual

Socket 478 ddr atx mainboard
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
845D- - - - AV
845D
845D
845D
Main n n n board
Mai
Mai
Mai
SOCKET 478 DDR ATX
Mainboard
Version 3.0
UM-845DAV-E3
Rev 3.0V
Creation Date: 10 January 2003
The 845D-AV MAINBOARD
AV
AV
AV
board
board
board
Ver 3.x
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 845D-AV and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AZZA 845D-AV

Summary of Contents for AZZA 845D-AV

  • Page 1 845D 845D 845D 845D- - - - AV Main n n n board board board board SOCKET 478 DDR ATX Mainboard Version 3.0 UM-845DAV-E3 Rev 3.0V Creation Date: 10 January 2003 The 845D-AV MAINBOARD Page 1 Ver 3.x...

  • Page 2: User's Notice

                      / #   0   &,%1   &2.    &%0   +% ,                               ,   3                       4               Page 2 The 845D-AV MAINBOARD Ver 3.x...
  • Page 3 -   &    -. ++ /$ * ).$,- -%   *  "$ *  - -$%  $  . $ *   - -'0% &++$ *  --12)1 /32 3'4,$ *  -$'& 3" 56"23" 5' 03" $ * 7 -7 8  8$ * 7 '&* 4 &    &    %19% 2 52## : &+  *$ * ; "$ *   ; <8& $ *  ; 5'(/           7+ /$ * ! 7. % % ! The 845D-AV MAINBOARD Page 3 Ver 3.x...
  • Page 4 $$'   ''(  $"  4-'% &  $"   ,(&% &  $-.    (, & $0 $5  .*'( $ $ 6 7 - ).     $ $ +,'&   $5 $0% 87# .   $ $  (*9  )& $ $''( &  &&  0 $$'3&  &&     $'"#:;-<'<3 7;-<=-<+3<'"#-6>     "(( "?">   - )  Page 4 The 845D-AV MAINBOARD Ver 3.x...
  • Page 5 Introduction                            The 845D-AV MAINBOARD Page 5 Ver 3.x...
  • Page 6 1.2.1. The 845D-AV Mainboard The 845D-AV mainboard is a Pentium™ 4 DDR platform. It supports a maxi- mum memory of 2GB and comes with 4 USB ports. Onboard it has six PCI slots and a 1x/2x/4x AGP slot (which only supports 1.5V AGP cards). The 845D-AV mainboard also comes with three fan connectors (for additional thermal protection) and three power supply connectors.
  • Page 7 DC power supply from +1.10V to +1.85V. System Memory The 845D-AV mainboard uses Double Data Rate Dual Inline Memory Modules (DDR DIMM). Each mainboard has two 184-pin DIMM sockets. These sockets support 2.5V (power level) single-sided or double sided PC1600 (DDR200) or PC2100(DDR266) DDR DIMM modules The maximum memory supported by these mainboards is 2 GB.
  • Page 8 USB Ports USB allows data exchange between your computer and a wide range of simultaneously accessible external Plug and Play peripherals. The 845D-AV mainboard is equipped with four USB connectors. USB 1 and USB 2 are external connectors. They can be found on the PC 99 ATX connector. The other USB connectors are internal connectors and can be used to connect other USB devices.
  • Page 9 1.4.1. Hardware Monitoring System Utility The 845D-AV mainboard comes with the Hardware Monitoring System utility contained on the CD. It is capable of monitoring the systems hardware conditions such as the temperature of the processor, voltage, and the speed of both the CPU and chassis fans.

  • Page 10: Hardware Installation

    PS/2 Keyboard Connector PS/2 KB PS/2 Mouse Connector PS/2 MS Serial Port 1 COM1 Serial Port 2 COM2 Parallel Port Universal Serial Port 1 USB1 Universal Serial Port 2 USB2 CN18 Game/Audio Port Audio/Game Page 10 The 845D-AV MAINBOARD Ver 3.x...
  • Page 11 Note: Before you start installing your mainboard we strongly recommend that you use a grounded anti-static mat. We fur- ther recommend that you attach an anti-static wristband, which is grounded at the same location as the mat to your wrist. The 845D-AV MAINBOARD Page 11 Ver 3.x...
  • Page 12                                  Page 12 The 845D-AV MAINBOARD Ver 3.x...
  • Page 13 CPU. 2.4.2. Memory Modules The 845D-AV mainboard has two 184-pin DDR DIMM slots and are able to support a maximum memory of 2 GB. The DDR DIMM slots are located on the right hand side of the board. To install the DIMMs into these slots, make sure the white lever at each side of the slot has been pulled down to an angle of approximately 45.
  • Page 14 AGP is a dedicated bus slot. It operates at 66 MHz and transfers data at a rate up to 1066 MB/s. This allows 3D applications to run more smoothly. The 845D-AV mainboard comes with a 1.5V AGP slot. This slot is able to support 1x, 2x and 4x AGP cards.
  • Page 15 Type: 40 pin blocks The 845D-AV mainboard all have two IDE connectors: a primary and secon- dary. Each IDE connector can support two IDE drives. These mainboards can therefore support up to four IDE devices each. If you install two hard drives, you need to configure the second drive to slave mode in the BIOS setup.
  • Page 16 Type: 3 pin The 845D-AV mainboard has a WOL (Wake-On-LAN) connector. This connec- tor must be connected to a LAN card that has Wake-On-LAN (WOL) output. This connector powers up the system when a wakeup packet or signal is re- ceived through the LAN card.
  • Page 17 The internal USB connectors allow you to add on an optional kit to ex- pand the total number of USB ports available. The 845D-AV has two internal USB connectors (CN30 and CN31). This enables you to use an extra two USB devices.
  • Page 18 Any read and write activity by the HDD will turn this LED on. 2.6.3. RS: Reset Button Connector If you connect this connector, you will be able to reset you computer by press- ing the reset button at the front of the chassis. Page 18 The 845D-AV MAINBOARD Ver 3.x...

  • Page 19: Speaker Connector

    CN 3 (COM 1) Type: 9 pin male One serial port is available for a mouse and COM 1 COM 2 other serial devices. (I/O addresses used are 3F8H/2F8H/3E8H/2E8H and IRQ3/IRQ4, selected by CMOS setup.) The 845D-AV MAINBOARD Page 19 Ver 3.x...

  • Page 20: Audio/Game Port Connector

    MIDI device. All these motherboards have 3D audio interfaces onboard. SPK-OUT LINE-IN MIC-IN Page 20 The 845D-AV MAINBOARD Ver 3.x...
  • Page 21 FSB will be forced to be 400 MHz. If all the pins are left open then the FSB will be forced to be 533MHz. Pins Frequency Pin 1 and Pin 2 Short Auto Detect FSB Clock Speed Pin 2 and Pin 3 Short 400MHz OPEN 533MHZ The 845D-AV MAINBOARD Page 21 Ver 3.x...
  • Page 22 AGP card has been inserted into the slot. If this jumper remains open the system will boot with both a 1.5V and 3.3V AGP card. Note: if you are using a 3.3V AGP card you can damage your system. Page 22 The 845D-AV MAINBOARD Ver 3.x...
  • Page 23   !%$  &  *9D& .!9 & 8"2  "#$%9*" .>9  : &+  @ @  /+  Note: BIOS software is continuously updated therefore the BIOS menus and the descriptions that are given in this manual are for reference purposes only. The 845D-AV MAINBOARD Page 23 Ver 3.x...
  • Page 24 Hard Drive parameters. Move the selection bar to the IDE Hard Drive you want to configure. Press the "ENTER" key. If you select “AUTO” the system BIOS will detect the HDD type automatically. Page 24 The 845D-AV MAINBOARD Ver 3.x...
  • Page 25 = Drive A /B The 845D-AV mainboard can support up to two floppy disk drives. These two selection fields allow you to select the floppy drives that are installed on your computer. Select the correct specifications for the diskette drive(s) installed on your computer.
  • Page 26 If enabled the amount of time required to run the power-on self-test (POST) will decrease. A quick POST skips certain steps. We recommend that you dis- able quick POST. It is better to find a problem during POST than to lose data during your work. Page 26 The 845D-AV MAINBOARD Ver 3.x...
  • Page 27 On or Off. When it is on the numeric keypad generates num- bers instead of controlling the cursor operations. When it is off the numeric keypad controls cursor operations and does not generate numbers. The 845D-AV MAINBOARD Page 27 Ver 3.x...
  • Page 28 If you are not using a floppy disk this option allows you to release IRQ6. To do this set this option to Yes. You should then also disable the onboard FDC Con- troller in the Integrated Peripherals Screen. Page 28 The 845D-AV MAINBOARD Ver 3.x...
  • Page 29 72-bit ECC RAM. If you are using ECC RAM you should select ECC. This feature will enable the system to detect and correct single-bit errors and detect (not correct) double-bit errors. If you do not have ECC RAM then select Non-ECC (the default mode). The 845D-AV MAINBOARD Page 29 Ver 3.x...
  • Page 30 IDE bus master driver). If your hard drive and your system software both support Ultra DMA/66, select Auto to enable BIOS support. USB Controller This field allows you to enable or disable the onboard USB Controller. Page 30 The 845D-AV MAINBOARD Ver 3.x...

  • Page 31: Init Display First

    Init Display First When both an AGP and PCI VGA card are installed on a mainboard, this field can be used to determine the display loading priority during System Startup. The 845D-AV MAINBOARD Page 31 Ver 3.x...
  • Page 32 IR Transmission Delay This field allows you to “Enable” or “Disable” the IR Transmission Delay. UR2 Duplex Mode This Field allows you to select the IR half or full duplex function. Page 32 The 845D-AV MAINBOARD Ver 3.x...
  • Page 33 This field allows you to select the I/O address for the onboard MIDI port. De- fault is 330. Midi Port IRQ This field allows you to select the IRQ for the onboard MIDI port. Default is 10. The 845D-AV MAINBOARD Page 33 Ver 3.x...

  • Page 34: Acpi Function

     * #     #         :*+ #   %    * #   -     Video Off Method This field determines how a monitor is made blank. See the following table on next page. Page 34 The 845D-AV MAINBOARD Ver 3.x...

  • Page 35: Cpu Thrm-Throttling

    When Enabled, an event occurring on each device listed below will restart the global time for the standby mode. Primary IDE 0 Primary IDE 1 Secondary IDE 0 Secondary IDE 1 FDD, COM, LPT Port PCI PIRQ[A-D] The 845D-AV MAINBOARD Page 35 Ver 3.x...
  • Page 36 MPEG Card) which may not display color properly on your screen. “Enable” the setting in this field may correct this problem. Leave it “Disabled” as the default setting shown above if you are using the normal display card. Page 36 The 845D-AV MAINBOARD Ver 3.x...
  • Page 37 This field shows you the speeds of the three cooling fans on the mainboard. Vcc Core This field and the fields below it show you the current system voltage Shutdown Temperature When the system reaches a certain maximum temperature the system will automatically shutdown. The 845D-AV MAINBOARD Page 37 Ver 3.x...

  • Page 38: Spread Spectrum

    PCI slots. When there is no device present on some of the PCI connectors, the clock on the related PCI slot will be disabled to reduce the Electro-Magnetic Interference (EMI). Spread Spectrum When Spread Spectrum is enabled, the EMI radiation on this mainboard will be reduced. Page 38 The 845D-AV MAINBOARD Ver 3.x...
  • Page 39 If the CMOS data is corrupted, or if you selected some CMOS settings and find that the PC system becomes very unstable, you should try to load the opti- mized default values first and then re-configure the BIOS. The 845D-AV MAINBOARD Page 39 Ver 3.x...
  • Page 40 Whenever you turn on the PC, it will request the user to enter the Password in order to boot up your system. Without the correct password, the PC system will stop and the operating system will not be loaded. Page 40 The 845D-AV MAINBOARD Ver 3.x...
  • Page 41 2. When "System" is selected in Security Option: When you turn on your PC, you will be requested to enter the Password. With- out the correct password, the PC system will stop and the operation system will not be loaded. The 845D-AV MAINBOARD Page 41 Ver 3.x...

  • Page 42: Exit Without Saving

    CMOS RAM. If you do not want to save any of the changes, or settings you selected in the BIOS SETUP utility, move the selection bar to the “EXIT WITHOUT SAVING” option. Press the “Enter” key. Then press “Y” Page 42 The 845D-AV MAINBOARD Ver 3.x...
  • Page 43 If you look at the top of Pin 2 in Pic 2b you will see that there is no connec- tion to the AGP card. This means that this is a 3.3 volt AGP card and can ® therefore not be used on an Intel 845 mainboard. The 845D-AV MAINBOARD Page 43 Ver 3.x...
  • Page 44 The first method is a physical check and the sec- ond method is a simple measurement between Pin 2 (on Side A) and any ground point on the card. The second method is the recommended method but both methods SHOULD suffice. Page 44 The 845D-AV MAINBOARD Ver 3.x...
