QUICK START GUIDE
FEATURES:
• 1/2.7" 5.0 Megapixel CMOS Image Sensor
• 24/7 Continuous Full Color Imaging
• Up to 30fps live view @ 5 MegaPixel (2592x1944)
• 2.8mm Fixed Iris Lens
• White Light with 100' IR Range
• True Wide Dynamic Range (120dB)
• True Mechanical Day/Night function by ICR
• Triple Streaming: H.265+, H.264+ & MJPEG Compression
• XD-DNR (3D & 2D-DNR) Noise Reduction
• Backlight Compensation, Highlight Compensation, DeFog, Hardware Reset, ROI
• Gen. IV Advanced Analytics: Intrusion Detection, Line Crossing, Target Counting
[All by Human / Motor Vehicle Classification], Face Detection, Scene Change,
Video Blur, Video Color Cast Detection
• 1 Ch. Audio In + Built-in Mic*
• Built-in MicroSD Card Slot for Local Recording (up to 256GB)
• Smart Alarm: Motion Detection, SD Card Error, SD Card Full
• Remote Viewing via CMS, Internet Explorer, and iOS & Android Apps
• IP67 Weather Resistance
• Optional Wall Mounts (VT-TWMT-3, VT-TWMT-A1 [reqs. VT-TJB08]), Junction Boxes
(VT-TJB01, VT-TJB08), and Pendant Mounts (VT-TPDMT-A1 [reqs. VT-TJB08],
VT-TPDM-2 [reqs. VT-TJB01]) Available
• 12VDC & PoE (Power over Ethernet) Operation
*Please research local, state and federal laws regarding the implementation
of audio surveillance.
VTC-TNT5WFC-2
Transcendent 5 MegaPixel Fixed IP
WDR Full Color at Night Turret Camera
PLEASE NOTE:
Complete User Guide, Software, Tools, and Updates are
available online. Scan the QR Code or visit:
http://www.vitekcctv.com/Downloads
FULL
COLOR
AT NIGHT
Advertisement
Table of Contents
Related Manuals for Vitek VTC-TNT5WFC-2
Summary of Contents for Vitek VTC-TNT5WFC-2
- Page 1 VTC-TNT5WFC-2 Transcendent 5 MegaPixel Fixed IP WDR Full Color at Night Turret Camera QUICK START GUIDE FULL COLOR FEATURES: AT NIGHT • 1/2.7” 5.0 Megapixel CMOS Image Sensor • 24/7 Continuous Full Color Imaging • Up to 30fps live view @ 5 MegaPixel (2592x1944) •...
-
Page 2: Components And Accessories
Components and Accessories Camera Drill Template Quick Guide Plastic Plugs Screws Network Coupler Overview Cable Connections First connect the Weather Resistant Cap to an Ethernet patch cable, then connect the cameras ethernet adaptor. If not powering the camera with PoE, also connect the power Cable to an approved 12VDC Power Supply. -
Page 3: Installation
Weather Resistant Network Coupler 1. Loosen the nut from the Weather Resistant Network Coupler, 2. Run ethernet cable through coupler, then attach a RJ-45 connector. 3. Tighten the nut and coupler for a weather resistant seal. Installation Before beginning installation, make sure that the wall or ceiling is strong enough to withstand 3 times the weight of the camera. - Page 4 3. Secure the mounting base using the screws provided. 3. Adjust the camera to achieve the optimal viewing angle by loosening the fixed screws. Before adjustment, preview the camera’s image on a monitor. 4. Tighten the fixed screws after adjusting the viewing angle of the camera.
-
Page 5: Lan Configuration
LAN Configuration S witch N etwor k C able N etwor k C able MENU IP Camera C omputer R outer The camera can be accessed on the local network either using the IP-Tool or directly in a web browser. Accessing the Camera Using the IP-Tool 1. - Page 6 4. Double-click the IP address and then the system will pop up the web browser to connect IP-CAM . IE browser will download the Active X control. After downloading, a login window will pop up as shown below: Input the user name and password to log in. Default user name: admin / Default password: 123456.
-
Page 7: Wan Configuration
2. Open the IE Browser and input the default address of IP-CAM and confirm. The IE browser will download Active X control. 3. After downloading Active X control, the login dialog box will pop up. 4. Input the default username and password and then enter to view. WAN Configuration Access the camera by the router or virtual server for example. - Page 8 VTC-TNT5WFC-2 Detailed Specifications 1/2.7” 5.0 Megapixel Progressive Scan CMOS Image Sensor Image Size 5 MegaPixel (2592 × 1944) 5MP(2692×1944), 4MP(2592×1520), 3MP(2304×1296), 1080P, 720P, D1, CIF(480 × 240) Resolution S/N Ratio 50dB 0 lux with LED ON Min. Illumination 2.8mm Fixed Iris Lens - M12 Lens Mount...
- Page 9 OPTIONAL ACCESSORIES AND RELATED PRODUCTS FOR VTC-TNT5WFC-2 VT-TJB08 VT-TJB01 VT-TWMT3 VT-TPDM-2 Optional Optional Optional Wall Transcendent Universal Junction Box Junction Box Mount 10” Pendant Mount. Reqs. VT-TJB01 5.10” VT-TWMT-A1 VT-TPLMT VT-TCNMT VT-TPDMT-A1 Transcendent Transcendent Transcendent Transcendent Wall Mount. Reqs. Universal Pole Universal Corner Universal 10”...
- Page 10 OPTIONAL ACCESSORIES AND RELATED PRODUCTS FOR NDAA COMPLIANT TRANSCENDENT IP CAMERAS TRANSCENDENT NVRs A Standalone Solution with Analytic Support and NDAA Compliance! • 8MP (4K) HDMI Output • H.265S / H.265+ / H.265 / H.264 Video Compression • Analytic Support Including Basic Face Detection, License Plate Recognition, and More! •...
- Page 11 Also Consider Vitek NDAA Compliant Wireless Access Points to Reduce Costly Cable Installation! VT-WAP1150 and VT-WAP2150 High Speed 5.8GHz DIP AP / CPE Wireless Bridge w/ 8MB Storage, 64MB RAM, 150MBps transmission, and Point-to-Multi-Point (P2MP) Topology With high speed transmission of 150Mbps and a wireless range of 3000ft.
-
Page 12: Limited Product Warranty
LIMITED PRODUCT WARRANTY VITEK products carry a three (3) year limited warranty. VITEK warrants to the purchaser that products manufactured by VITEK are free of any rightful claim of infringement or the like, and when used in the manner intended, will be free of defects in materials and workmanship for a period of three (3) years, or as otherwise stated above, from the date of purchase by the end user.
