Technical Reference Guide Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor...
Page 2 The hardcopy of this document is designed to be placed into a standard 3-ring binder. Provided below is a title block that can be copied and cut out and placed into the slip or taped onto the edge of the binder. Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor...
Page 3 For more information regarding specifications and Compaq-specific parts please contact Compaq Computer Corporation, Industry Relations Department. Technical Reference Guide Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition - October 1997 Document Number DSK-113A/1097 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition –...
Page 4 Technical Reference Guide Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition –- October1997...
Page 5: Table Of Contents
INTRODUCTION... 3-1 PENTIUM II-BASED PROCESSOR/MEMORY SUBSYSTEM ... 3-2 3.2.1 PENTIUM II PROCESSOR... 3-3 3.2.2 SYSTEM MEMORY... 3-6 3.2.3 SUBSYSTEM CONFIGURATION... 3-10 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition – October1997 Technical Reference Guide...
Page 6 5.3.2 DISKETTE DRIVE CONNECTOR... 5-13 SERIAL INTERFACES ... 5-14 5.4.1 RS-232 INTERFACE ... 5-14 5.4.2 IrDA INTERFACE... 5-15 5.4.3 SERIAL INTERFACE PROGRAMMING ... 5-16 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition –- October1997...
Page 7 7.2.2 POWER CONTROL... 7-3 POWER DISTRIBUTION... 7-4 7.3.1 3.5/5/12 VDC DISTRIBUTION... 7-4 7.3.2 LOW VOLTAGE DISTRIBUTION... 7-5 SIGNAL DISTRIBUTION ... 7-6 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition – October1997 Technical Reference Guide...
Page 8 CEMM PRIVILEDGED OPS ERROR MESSAGES... A-12 A.21 CEMM EXCEPTION ERROR MESSAGES ... A-12 APPENDIX B ASCII CHARACTER SET ... INTRODUCTION...B-1 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor )... A-3 )... A-4 ) ... A-4 ) ... A-5 ) ...
Page 9 APPENDIX E MATROX MILLENNIUM II GRAPHICS CARD ... INTRODUCTION...E-1 FUNCTIONAL DESCRIPTION...E-2 DISPLAY CONFIGURATIONS ...E-3 PROGRAMMING...E-4 E.4.1 CONFIGURATION...E-4 E.4.2 CONTROL...E-4 MONITOR POWER MANAGEMENT CONTROL ...E-6 CONNECTORS ...E-6 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition – October1997 Technical Reference Guide...
Page 10: List Of Figures
IAGRAM 7–3. L IGURE OLTAGE UPPLY 7–4. S IGURE IGNAL ISTRIBUTION viii Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor LIST OF FIGURES ESKTOP ERSONAL OMPUTER WITH ... 2-4 ... 2-5 ... 2-6 ... 2-6 AYOUT ...
Page 11 RAPHICS LOCK DIAGRAM , (F DB-15, EMALE AS VIEWED FROM REAR ... 7 XPANSION ONNECTORS Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition – October1997 Technical Reference Guide ...C-3 IAGRAM ...C-5 ...C-5 ...C-6 OSITIONS ...C-6...
Page 12: List Of Tables
ABLE YSTEM 4–20. 87307 I/O C ABLE ONTROLLER 4–21. S ABLE YSTEM ANAGEMENT Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor LIST OF TABLES ... 1-3 ... 2-8 ... 2-12 OMPARISON ... 2-14 ... 2-14 ... 2-14 ...
Page 13 ... A-7 ESSAGES ... A-8 ESSAGES ... A-9 ESSAGES ... A-9 ... A-10 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition – October1997 Technical Reference Guide ... 5-10 ... 5-30 ... 6-9 APPING ... 6-10...
Page 14 OWER ANAGEMENT E–5. DB-15 M ABLE ONITOR ONNECTOR E–6. G ABLE RAPHICS EMORY XPANSION Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor ... A-10 RROR ESSAGES ... A-11 ESSAGES ... A-11 RROR ESSAGES ... A-12 RROR ESSAGES ...
Page 15: Chapter 1 Introduction
INTRODUCTION 1. Chapter 1 INTRODUCTION ABOUT THIS GUIDE This guide provides technical information about the Compaq Deskpro 4000 and 6000 Personal Computers that employ the Pentium II Processor. NOTE: This guide specifically covers systems employing system board PCA# 006627- xxx (systems introduced September 1997). Pentium II-based systems introduced in July...
Page 16: Notational Conventions
(MSb) of a byte. Bytes, words, double words, and quad words are typically shown with most-significant portions on the left or top and the least- significant portions on the right or bottom respectively. Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Index port...
Page 17: Common Acronyms And Abbreviations
DOS compatibility hole Display Data Channel direction flag Table 1-1. Acronyms and Abbreviations Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition - October1997 Technical Reference Guide Continued...
Page 18 Joint Electron Device Engineering Council Kb / KB kilobits / kilobytes (x 1024 bits / x 1024 bytes) Kb/s kilobits per second kilogram kilohertz kilovolt Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition - October 1997 Continued...
Page 19 Relative humidity root mean square read-only memory revolutions per minute real time clock read/write First Edition - October1997 Technical Reference Guide Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Continued...
Page 20 Video Electronic Standards Association video graphics adapter vibrato VLSI very large scale integration VRAM Video RAM watt WRAM Windows RAM zero flag zero insertion force (socket) Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition - October 1997...
Page 21: Chapter 2 System Overview
Chapter 2 SYSTEM OVERVIEW INTRODUCTION The Compaq Deskpro 4000 and 6000 Series Personal Computers (Figure 2-1) based on the Pentium II microprocessor include minitower and desktop models designed with an emphasis on speed, storage capacity, and multimedia compatibility to meet the requirements of the business environment.
Page 22: Features
Monitor Type Data Compaq Insight Edition The Intelligent Manageability features provide support for DMI 2.0, Compaq Insight Manager, and Management Solutions Partners. Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Fault Management ECC RAM Fault Prediction SMART II Hard Drive Monitor Fault Diag.
Page 23: Series Differences
2.2.2 SERIES DIFFERENCES The differences between the Pentium II-based Compaq Deskpro 4000 and the Pentium II-based Compaq 6000 Series Personal Computers are listed below: Deskpro 4000 Hard drive interface: Graphics Solution: Matrox 1064-SG NOTE: The differences listed above do not apply to systems based on system board PCA no.
Page 24: Mechanical Design
Chapter 2 System Overview MECHANICAL DESIGN The Compaq Deskpro 4000 Series features two formfactors; desktop and minitower. This section illustrates the layouts used by these two formfactors. In addition, this section includes the layouts of the system boards. 2.3.1 CABINET LAYOUTS Desktop Figure 2–2.
Page 25: Figure 2-3. Cabinet Layout , R
Headphones output connector Mic input connector Line output connector Line input connector Figure 2–3. Cabinet Layout, Rear View Compaq Deskpro 4000 and 6000 Personal Computers First Edition – October 1997 Technical Reference Guide 16 18 Minitower featuring the Pentium II Processor...
Page 26: Chassis Layouts
PCI Slot 2 PCI Slot 1 ISA Slot 1 Slots On Riser Card, Rear View @90 Figure 2–5. Minitower Chassis Layout, Left Side View Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Back Front Front System Board...
Page 27: System Board Layouts
[1] Board p/n 006650-xxx shown here for identification only. See note at beginning of chapter 1. Figure 2–6. System Board Layout, Component Side System Board p/n 006627-xxx Bottom: Line Out (audio) connector Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition – October 1997 Technical Reference Guide...
Page 28: System Architecture
Chapter 2 System Overview SYSTEM ARCHITECTURE Figure 2-7 shows the architecture of the Compaq Deskpro 4000 and 6000 Series Personal Computers based on the Pentium II processor and matched with a support chipset that is complimentary in design. Both minitower and desktop systems share the same basic architecture, which utilizes three main buses: the Host bus, the Peripheral Component Interconnect (PCI) bus, and the Industry Standard Architecture (ISA) bus.
Page 29: Figure 2-7. System Architecture
I/F (2) Deskpro 4000 only Deskpro 6000 only [1] Only three PCI connectors on desktop. Figure 2–7. System Architecture, Block diagram Compaq Deskpro 4000 and 6000 Personal Computers First Edition – October 1997 Technical Reference Guide 64-Bit Host Bus 64-Bit Mem.
Page 30: Pentium Ii Processor
EV data. The BIOS is updateable by remote or local flashing of the ROM, which includes boot block ROM support. 2-10 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Secondary Cache First Edition - October 1997...
Page 31: Support Chipset
Support Chipsets Component Type 82440LX 82371 87307 ES1869 AIC-7860 TLAN 3.1 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition – October 1997 Technical Reference Guide Subfunctions System Controller Data Buffer Host/AGP Bridge EIDE Controller...
Page 32: Graphics Subsystem
The Deskpro 4000 system features a PCI graphics card that is based on the Matrox MGA- 1064SG graphics accelerator. The card includes two megabytes of SGRAM as standard and can be expanded to four megabytes by adding a 2-MB SGRAM module.
Page 33: Universal Serial Bus Interface
Two Universal Serial Bus (USB) ports are included to provide a high speed interface for future systems and/or peripherals. The USB operates at 12 Mbps and provides hot plugging/unplugging (Plug ’n Play) functionality. Compaq Deskpro 4000 and 6000 Personal Computers 2-13 featuring the Pentium II Processor...
Page 34: Specifications
Parameter Height Width Depth Weight NOTE: Metric measurements shown in parenthesis. 2-14 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Table 2-4. Environmental Specifications Operating to 95 F (10 to 35 2.0 g for 11 ms half-sine pulse...
Page 35: Table 2-7. Diskette Drives
Full Stroke Audio Output Level Cache Buffer Data Transfer Time Sustaiined Startup Time Compaq Deskpro 4000 and 6000 Personal Computers First Edition – October 1997 Technical Reference Guide Measurement 3.5 in 1.44 MB/720 KB diskette 3 ms/3 ms 94 ms/94ms...
Page 36: Table 2-9. Standard Hardd
Disk RPM: EDMA Mode Support (max): PIO Mode Support (max): Power Mode Commands: Drive Fault Prediction: 2-16 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Table 2-9. Standard Hard Drive Specifications 2.1 GB 2.4 GB SCSI...
Page 37: Chapter 3 Processor/Memory Subsystem
MEMORY SUBSYSTEM Chapter 3 PROCESSOR/MEMORY SUBSYSTEM INTRODUCTION This chapter describes the processor/cache memory subsystem of the Compaq Deskpro 4000 and 6000 Series of Personal Computers featuring the Pentium II microprocessor. This chapter includes the following topics: Pentium II-based processor/memory subsystem [3.2] Table 3-1 lists the highlights of the processor/memory architecture.
Page 38: Pentium Ii-Based Processor/Memory Subsystem
The 440LX controller provides the Host/PCI bridge functions and controls data transfers with system memory over the 64-bit memory data bus. The system memory comes with 32 or 64 megabytes of SDRAM expandable to 384 megabytes. Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Cntl 64-Bit Mem.
Page 39: Pentium Ii Processor
Accesses with the L2 cache occur at Host bus speed, although the close proximity of the cache provides higher efficiency than caches located on the system board. Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition - October 1997...
Page 40: Thermal Considerations
The system board includes a header (E101) that allows the connection of a cooling fan that may be integrated onto some upgrade SEC cartridges, depending on source. Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition - October 1997...
Page 41: Table 3-2. Pentium Ii M
SW1-5 CFG_SPD60 First Edition - October 1997 Technical Reference Guide Host Bus Core Speed (MHz) GPIO Number I/O Port 78h bit <1> bit <0> bit <3> bit <2> Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor...
Page 42: System Memory
Write Page Miss Posted Write Write Retire Rate from Posted Write Buffer SLD = Speculative Lead Disable Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor DIMM 1, Bank A DIMM 1, Bank B DIMM 2, Bank A...
Page 43 DIMM Slot J10 [1] DIMM Slot J11 None None C-type bus interface using BIOS call INT 15, Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition - October 1997 Technical Reference Guide DIMM Slot J12 [2]...
Page 44 [8] Field specified as optional by JEDEC but required by this system. [9] Field format proposed to JEDEC. This system requires that the DIMM’s EEPROM have this space available for reads/writes. Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Table 3-5.
Page 45: Figure 3-3. System Memorym
Graphics/SMM Area (128 KB) 000A 0000h 0009 FFFFh Base Memory (640 KB) 0000 0000h Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition - October 1997 Technical Reference Guide 4 GB 64 MB 16 MB...
Page 46: Subsystem Configuration
Assume unmarked locations/gaps as reserved. Device 1 (virtual PCI/PCI bridge for AGP) of the 440LX is not used in the Deskpro 4000 system but is accessed during POST to configure the DOS compatibility area for usage by the graphics controller.
Page 47: Chapter 4 System Support
System management (4.8) This chapter covers functions provided by off-the-shelf chipsets and therefore describes only basic aspects of these functions as well as information unique to the Compaq Deskpro 4000/6000 Personal Computers. For detailed information on specific components, refer to the applicable manufacturer’s documentation.
Page 48: Pci Bus Overview
Host/PCI Bridge Function PCI/ISA Bridge Function Minitower only Figure 4–1. PCI Bus Devices and Functions Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor PCI Connector Slot 4 PCI Connector Slot 3 PCI Connector Slot 2 PCI/AGP...
Page 49: Pci Connector
+5 VDC +5 VDC ACK64- REQ64- +5 VDC +5 VDC +5 VDC +5 VDC Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition–- October 1997 Technical Reference Guide B Signal A Signal Reserved C/BE7- C/BE6-...
Page 50: Pci Bus Master Arbitration
The 440LX and the 82371 support the passive release mechanism, which reduces PCI bus latency caused by an ISA initiator owning the bus for long periods of time. Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Table 4-2.
Page 51: Pci Bus Transactions
00 = Type 0 01 = Type 1 PCI Configuration Data Register I/O Port 0CFCh, R/W, (8-, 16-, 32-bit access) Function 31..0 Configuration Data. Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition–- October 1997 Technical Reference Guide...
Page 52: Figure 4-3. Type 0 Configuration
[2] Minitower only The function number (CF8h, bits <10..8>) is used to select a particular function within a multifunction device as shown in Table 4-4. Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor 24 23 16 15...
Page 53 Group) and a device ID (assigned by the vender). The device and vender IDs for the devices used in these systems are listed in Table 4-5. Compaq Deskpro 4000 and 6000 Personal Computers First Edition–- October 1997 Technical Reference Guide Function No.
Page 54: Option Rom Mapping
During POST, the PCI bus is scanned for devices that contain their own specific firmware in ROM. Such option ROM data, if detected, is loaded into system memory’s DOS compatibility area (refer to the system memory map shown in chapter 3). Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Table 4-5.
Page 55: Pci Interrupt Mapping
PCI Slot 3 INTB- INTC- INTC- INTD- INTD- INTA- INTA- [4] INTB- Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition–- October 1997 Technical Reference Guide PCI Slot 4 [1] INTA- [2] INTB- INTC- INTD-...
Page 56: Pci Configuration
APIC/BIOS Control PCI Interrupt Routing PCI Interrupt Routing PCI Interrupt Routing NOTE: Assume unmarked locations/gaps as reserved. 4-10 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Table 4-6. PCI/ISA Bridge Configuration Registers (82371, Function 0) Reset PCI Config.
Page 57: Agp Bus Overview
PAD19 PAD18 PAD17 PAD16 CBE2- FRAME- IRDY- RSVD RSVD RSVD RSVD Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition–- October 1997 Technical Reference Guide A Signal B Signal VDD3 VDD3 TRDY- DEVSEL- STOP- PME-...
Page 58: Agp Configuration
Secondary Bus Number Subordinate Bus Number NOTE: Assume unmarked locations/gaps as reserved. Refer to Intel documentation for detailed register descriptions. 4-12 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Table 4-8. (82440LX, Function 1) Reset PCI Config.
Page 59: Isa Bus Overview
BIOS ROM and Buffers 8-/16-Bit ISA Bus Serial Parallel IrDA I/F (2) Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition–- October 1997 Technical Reference Guide Audio Controller ISA Connectors (3) System Management...
Page 60: Isa Connector
IRQ7 IRQ6 IRQ5 IRQ4 IRQ3 DAK2- BALE +5 VDC 4-14 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor 16-Bit ISA Connection 8-Bit ISA Connection Table 4-9. ISA Expansion Connector Pinout 16-Bit ISA Interface Signal Signal I/O CHK-...
Page 61: Isa Bus Transactions
When the address changes, devices on the bus may decode the latchable address (LA23..17) lines and then latch them. This arrangement allows devices to decode chip selects and M16- before the next cycle actually begins. Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition–- October 1997...
Page 62 The logic-high voltage at the bus ranges from 3.75 VDC to 5.5 VDC. The logic low voltage ranges from 0 VDC to 0.8 VDC. 4-16 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition - October 1997...
Page 63: Direct Memory Access
Spare & ISA conn. pins D10, D11 Spare & ISA conn. pins D12, D13 Spare & ISA conn. pins. D14, D15 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition–- October 1997 Technical Reference Guide...
Page 64 64 Kwords (128 Kbytes) of data per DMA transfer. Word DMA operations are only possible between 16-bit memory and 16-bit peripherals. 4-18 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Table 4-11. Page Register I/O Port...
Page 65 004h 004h 005h 005h 006h 006h 007h 007h 00Dh 00Ch 00Dh 00Eh Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition–- October 1997 Technical Reference Guide Controller 2 0D0h 0D0h 0D6h 0D4h 0DEh 0D2h 0C0h...
Page 66: Interrupts
If more than one interrupt is pending, the highest priority (lowest number) is processed first. 4-20 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor South Bridge Component IRQ1,3..7...
Page 67: Table 4-13. Maskable Interrupt
0A1h Initialization Command Word 2-4, Int. Cntlr. 2 The initialization and operation of the interrupt control registers follows standard AT-type protocol. Compaq Deskpro 4000 and 6000 Personal Computers First Edition–- October 1997 Technical Reference Guide Table 4-13. featuring the Pentium II Processor...
Page 68 NMI-. Note that the lower six bits of register at I/O port 70h affect RTC operation and should be considered when changing NMI- generation status. 4-22 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition - October 1997...
Page 69 APM BIOS to service the SMI- according to the cause of the timeout. Although the SMI- is primarily used for power managment the interrupt is also employed for the QuickLock/QuickBlank functions as well. Compaq Deskpro 4000 and 6000 Personal Computers 4-23 featuring the Pentium II Processor...
Page 70: Interval Timer
PCI IRQ routing and top-of-memory available to ISA/DMA devices. These parameters are programmed by BIOS during power-up, using registers listed previously in Table 4-6. 4-24 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Table 4-15. Interval Timer Functions...
Page 71: System Clock Distribution
“ PCI Slots, South Bridge, TLAN, SCSI controller “ TLAN3.1 (NIC) W48C67 South Bridge, ES1868. ISA slots ISA slots 87307 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition–- October 1997 Technical Reference Guide 4-25...
Page 72: Real-Time Clock And Configuration Memory
(Compaq p/n 160274-001 or equivalent 4.5 VDC @ 660 ma alkaline battery) to header E50 (pins 9-12, and moving the jumper from pins 1 and 2 to pins 2 and 3. 4-26 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor 87307...
Page 73: Configuration Memory Byte Definitions
Serial port 1 address Serial port 2 address COM1/COM2 port configuration DEh-DFh Checksum of locations 90h to DDh E0h-FFh Client Management error log Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition–- October 1997 Technical Reference Guide 4-27...
Page 74 0 = RTC has lost power 1 = RTC has not lost power 6..0 Reserved 4-28 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor 1000 = 3.90625 ms 1001 = 7.8125 ms 1010 = 15. 625 ms 1011 = 31.25 ms...
Page 75 1101 = Type 13 0110 = Type 6 1110 = Type 14 0111 = Type 7 1111 = other (use bytes 1Ah) Compaq Deskpro 4000 and 6000 Personal Computers First Edition–- October 1997 Technical Reference Guide featuring the Pentium II Processor 4-29...
Page 76 Bytes 17h and 18h hold a 16-bit value that specifies the extended memory size in increments of 1-KB (1024) bytes. 4-30 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor 10 = 3 drives 11 = 4 drives...
Page 77 1 = Not allowed Reserved Diagnostic Status Byte Address 00 = Memory locations 80C00000h-80C00004h 01 = I/O ports 878h-87Ch 11 = neither place Compaq Deskpro 4000 and 6000 Personal Computers First Edition–- October 1997 Technical Reference Guide featuring the Pentium II Processor 4-31...
Page 78 Internal Compaq Memory: 00000 = None 00001 = 512 KB 00010 = 1 MB 00011 = 1.5 MB 11111 = 15.5 MB 4-32 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition - October 1997...
Page 79 0 = No screen blank 1 = Screen blank w/QuickLock 4..0 ScreenSave Timeout. (Index to SIT monitor timeout record) 000000 = Disabled Compaq Deskpro 4000 and 6000 Personal Computers First Edition–- October 1997 Technical Reference Guide featuring the Pentium II Processor 4-33...
Page 80 Standard Numeric Coprocessor Present: 0 = Not installed, 1 = Installed 3..0 Reserved Configuration Byte 34h, International Language Support Default Value = 00h 4-34 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition - October 1997...
Page 81 Byte 41h, month & day Byte 42h, year and month Byte 43h, minutes and seconds Byte 44h, removal flag and minutes Compaq Deskpro 4000 and 6000 Personal Computers First Edition–- October 1997 Technical Reference Guide featuring the Pentium II Processor...
Page 82 ECC Status for DIMM 3 ECC Status for DIMM 2 ECC Status for DIMM 1 ECC Status for DIMM 0 3..0 Reserved 4-36 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition - October 1997...
Page 83 Configuration Byte 81h, 82h, Total Super Extended Memory Tested This byte holds the value of the amount of extended system memory that tested good during POST. The amount is given in 64-KB increments. Compaq Deskpro 4000 and 6000 Personal Computers First Edition–- October 1997 Technical Reference Guide...
Page 84 These bytes hold the APM timer values: Byte 8Ah, minutes Byte 8Bh, hours Byte 8Ch, day Byte 8Dh, month Byte 8Eh, year Byte 8Fh, century 4-38 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition - October 1997...
Page 85 The ISA card uses the RAMDAC on the PCI card The palette snooping feature (sometimes called “RAMDAC shadowing”) on the PCI card is enabled and functioning properly. Compaq Deskpro 4000 and 6000 Personal Computers First Edition–- October 1997 Technical Reference Guide...
Page 86 0 = Disable 1 = Enable Secondary Hard Drive Controller IRQ 00 = IRQ10 01 = IRQ11 10 = IRQ12 11 = IRQ15 Reserved 4-40 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition - October 1997...
Page 87 These bytes contain the number of cylinders, heads, and sectors per track for hard drives C, D, E, and F respectively. The mapping for each drive is as follows: Drive 65 (C) Drive 66 (D) Compaq Deskpro 4000 and 6000 Personal Computers First Edition–- October 1997 Technical Reference Guide Drive 68 (E)
Page 88 Configuration Bytes CAh, DBh; Chassis Serial Number Configuration Bytes DEh, DFh; Checksum of Locations 90h-DDh Configuration Bytes E0h-FFh; Client Management Error Log 4-42 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition - October 1997...
Page 89: I/O Map And Register Accessing
PCI Configuration Data (byte, word, or dword access) FF00..FF07h IDE Bus Master Register NOTE: Assume unmarked gaps are reserved/unused. Table 4-19. System I/O Map Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition–- October 1997 Technical Reference Guide 4-43...
Page 90: 87307 I/O Controller Configuration
07h and writing the desired offset to the index register. The data is then either written to or read from the data register. 4-44 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Table 4-20. Reset Value...
Page 91 Write 0 to enable. Write 1 to disable. GPIO Port 2 Direction/Output Type/PU Cntrl., I/O Addr. 07D-07Fh, (87307 I/O Controller) Compaq Deskpro 4000 and 6000 Personal Computers First Edition–- October 1997 Technical Reference Guide featuring the Pentium II Processor 4-45...
Page 92: System Management Support
The following subsections describe the system management functions. Any BIOS interaction required of these functions is described in Chapter 8, “BIOS” or in the Compaq BIOS Technical Reference Guide. 4-46 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Table 4-21. First Edition - October 1997...
Page 93: Flash Rom Write Protect
Black Box logic is Compaq-proprietary and controlled exclusively through the BIOS ROM. Data Type Protection Option ROM Password write-protected System BIOS Password write-protected ESCD Never write-protected Boot Block Always write-protected Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition–- October 1997 Technical Reference Guide 4-47...
Page 94: I/O Security
. NOTE: Although the SMI is used for initiating QuickLock/QuickBlank functions, these functions are not considered power management features. 4-48 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition - October 1997...
Page 95: Temperature Sensing
The chassis cover can be locked to prevent unauthorized personnel from removing the cover and changing the system hardware. The locking mechanism consists of a solenoid controlled by the GPOC register of CM logic in the Compaq ASIC. Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition–- October 1997...
Page 96: Cover Removal Sensor
Hood Removal NOBOOT Enable/Disable Byte Offset (0-255) Hood Removal NOBOOT Enable/Disable Bit Location: 7..4 CMOS Type (0011b, use INT 15h for flat model CMOS) 3..0 Bit location (0001b) 4-50 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition - October 1997...
Page 97: Power Management
This capability is dependent on the graphics controller employed in the system. For compliance to the monitor power control feature refer to the applicable appendix for the installed graphics controller card. Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition–- October 1997...
Page 98 Chapter 4 System Support This page is intentionally blank. 4-52 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition - October 1997...
Page 99: Chapter 5 Input/Output Interfaces
The IDE interface is configured as a PCI device and controlled through standard I/O mapped registers. page 5-1 page 5-9 page 5-14 page 5-21 page 5-29 page 5-35 page 5-37 page 5-39 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition -October 1997 Technical Reference Guide...
Page 100 Bus Master IDE Status (Primary) Bus Master IDE Descriptor Ptr (Pri.) Bus Master IDE Command (Secondary) Bus Master IDE Status (Secondary) Bus Master IDE Descriptor Ptr (Sec.) Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Table 5-1. Value Conf.
Page 101 The contents of this register are valid when the following conditions exist: Error bit is set in the Status register Hard drive controller has completed execution of its internal diagnostics Table 5-3. Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition -October 1997 Technical Reference Guide...
Page 102 These registers contain the starting cylinder number for each hard drive access. The three most- significant bits of the value are held in byte address 1F5h (bits <2..0>) while the remaining bits are held in location 1F4h. Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition – October 1997...
Page 103 The alternate Status register at location 3F6h holds the same status data as location 1F7h but does not clear hardware conditions when read. First Edition -October 1997 Technical Reference Guide Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor...
Page 104 Alternate Status Register, I/O Port 3F6h/376h (Read Only) The alternate Status register at location 3F6h holds the same status data as location 1F7h but does not clear hardware conditions when read. Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Value...
Page 105 1111 = 0 Drive Select: 00 = Disabled 01 = Drive 1 selected 10 = Drive 0 selected 11 = Invalid First Edition -October 1997 Technical Reference Guide Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor...
Page 106: Ide Connector
[1] Primary connector wired to IRQ14, secondary connector wired to IRQ15. [2] Pin 39 is used for spindle sync and drive activity (becomes SPSYNC/DACT-) when synchronous drive are connected. Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Table 5-5.
Page 107: Diskette Drive Interface
Result phase, in which case the Execution phase can be followed by a Command phase. During periods of inactivity, the diskette drive controller is in a non-operation mode known as the Idle phase. Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition -October 1997...
Page 108: Diskette Drive Programming
Base Address MSB Base Address LSB Interrupt Select Interrupt Type DMA Channel Select Report DMA Assignment Configuration Data Drive ID 5-10 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Table 5-6. Reset Value First Edition – October 1997...
Page 109: Table 5-7. Diskette Drivec
0 = Reset controller, 1 = Enable controller Drive Select 00 = Drive 1 01 = Drive 2 10 = Reserved 11 = Tape drive Table 5-7. Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition -October 1997 Technical Reference Guide 5-11...
Page 110 00 = 500 Kb/s 01 = 300 Kb/s 10 = 250 Kb/s 11 = 1 or 2 Mb/s (depending on TUP reg. Bit <1>) 5-12 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition – October 1997...
Page 111: Diskette Drive Connector
WR DATA- WR ENABLE- TRK 00- WR PRTK- RD DATA- SIDE SEL- DSK CHG- Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition -October 1997 Technical Reference Guide Description Drive head direction control Ground Drive head track step control...
Page 112: Serial Interfaces
Transmit Data Data Terminal Ready Ground Each DB-9 port is independently configurable as to it’s COMn (address) designation. 5-14 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor DB-9 B (RS-232) DIN (IrDA) Table 5-9. DB-9 Serial Connector Pinout Signal First Edition –...
Page 113: Irda Interface
15 degrees off the viewing angle of the dongle’s infrared diodes. Table 5-10. IrDA DIN Connector Pinout Signal RSVD RSVD DETECT RSVD Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition -October 1997 Technical Reference Guide Description Reserved Reserved Detect Dongle...
Page 114: Serial Interface Programming
DMA Channel Select Report DMA Assignment Configuration Data NOTES: [1] Device 5 (UART2) / Device 6 (UART1) 5-16 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Table 5-11. Reset Value [1] 00h / 00h 00h / 00h...
Page 115: Table 5-12. Serial Interface
When read by the CPU, this byte contains receive data. When written to by the CPU, the byte contains data to be transmitted. Table 5-12. Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition -October 1997...
Page 116 011 = Receiver line status reg. 100,101 = Reserved 110 = Character time-out (highest priority) 111 = Reserved Interrupt Pending (if cleared) 5-18 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Decimal Divisor Baud Rate 2304 2400...
Page 117 Serial Interface Interrupts Enabled (if set) Reserved RTS Signal Active (if set) DTR Signal Active (if set) First Edition -October 1997 Technical Reference Guide 1 = Enable TX/RX FIFOs Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor 5-19...
Page 118 DSR- Has Changed State Since Last Read CTS- Has Changed State Since Last Read Scratch Pad Register, I/O Port 3FFh/2FFh This register is not used in this system. 5-20 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition – October 1997...
Page 119: Parallel Interface
The SPP mode uses three registers for operation: the Data register (DTR), the Status register (STR) and the Control register (CTR). Address decoding in SPP mode includes address lines A0 and A1. Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition -October 1997...
Page 120: Enhanced Parallel Port Mode
DMA and RLE are inhibited. NOTE: The 87307 does not support ECP v1.7 submode of ECP mode 4. 5-22 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition – October 1997...
Page 121: Parallel Interface Programming
Base Address MSB Base Address LSB Interrupt Select Interrupt Type DMA Channel Select Report DMA Assignment Configuration Data Table 5-13. Reset Value Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition -October 1997 Technical Reference Guide 5-23...
Page 122: Table 5-13. Parallel Interface
In ECP mode in the forward (output) direction, a write to this location places a tagged command byte into the FIFO and reads have no effect. 5-24 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Table 5-14.
Page 123 These registers are used for reading/writing data. Port 0 is used for all transfers. Ports 1-3 are used for transferring the additional bytes of 16- or 32-bit transfers through port 0. First Edition -October 1997 Technical Reference Guide Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor 5-25...
Page 124 0 = Not full (at least 1 empty byte 1 = Full FIFO Empty Status (Read Only) 0 = Not empty (contains at least 1 byte) 1 = Empty 5-26 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition – October 1997...
Page 125: Parallel Interface Connector
Paper End SLCT Select Table 5-15. DB-25 Parallel Connector Pinout Signal ERR- INIT- SLCTIN- Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition -October 1997 Technical Reference Guide Description Line Feed Error Initialize Paper Select In...
Page 126: Keyboard/Pointing Device Interface
Tch (clock High) Th (Data Hold) Tss (Stop Bit Setup) Tsh (Stop Bit Hold) Figure 5–7. 8042-To-Keyboard Transmission of Code EDh, Timing Diagram 5-28 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Tcl Tch Minimum Maximum 0 us...
Page 127 Clears keyboard buffer and prepare to receive key ID. [1] Clears keyboard buffer and prepare to receive key ID. [1] 8042 detected error in keyboard transmission. Resets program, runs keyboard BAT, defaults to Mode 2. Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor 5-29...
Page 128: Pointing Device Interface Operation
Report DMA Assignment Configuration Data [1] NOTES: [1] Keyboard I/F only. [2] Keyboard I/F / Mouse I/F 5-30 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Table 5-17. Reset Value [2] 01h / 00h 00h / na...
Page 129 A CPU write to I/O port 64h places a command value into the input buffer and sets the CMD/DATA bit of the status register (bit <3>) to CMD. Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor...
Page 130 Disable keyboard command (sets bit <4> of the 8042 command byte). Enable keyboard command (clears bit <4> of the 8042 command byte). 5-32 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Table 5-18. CPU Commands To The 8042 First Edition –...
Page 131 Pulse output port. Controls the pulsing of bits <3..0> of the output port (0 = pulse, 1 = don’t pulse). Note that pulsing bit <0> will reset the system. First Edition -October 1997 Technical Reference Guide Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor 5-33...
Page 132: Keyboard/Pointing Device Interface Connector
Table 5–19. Keyboard/Pointing Device Connector Pinout Keyboard/Pointing Device Connector Pinout Signal Description DATA Data Not Connected Ground 5-34 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Table 5-19. Signal + 5 VDC First Edition – October 1997 Description Power Clock...
Page 133: Ethernet Interface
Distribution” for a discussion of the power control logic). TX/RX Filter TX/RX, Cntrl TX/RX Filter Link Active (Yellow) (Green) Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition -October 1997 Technical Reference Guide AUI Connector TX/RX +12 VDC RJ-45 Connector TX/RX 5-35...
Page 134: Nic Configuration/Control
The network interface provides two choices of connection to a system as shown in the following figures. Figure 5–10. Ethernet AUI Connector (DB-15, viewed from rear) 8 7 6 5 Figure 5–11. Ethernet RJ-45 Connector 5-36 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Description Transmit Receive Receive Low Transmit Low First Edition –...
Page 135: Universal Serial Bus Interface
Serial Base Release Number C0-C1h Legacy Support Reg. (compliant w/UHCI v1.1) Table 5-20. 1106h 3038h 0000h 0280h 2000h Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition -October 1997 Technical Reference Guide Reset Value All 0’s 5-37...
Page 136: Usb Control
Figure 5–12. Universal Serial Bus Connector (one of two as viewed from rear of chassis) Table 5–22. USB Connector Pinout Signal Description +5 VDC USB- Data (minus) 5-38 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Table 5-21. Table 5-22. USB Connector Pinout Signal USB+ First Edition – October 1997...
Page 137: Ultra Scsi Adapter
Synchronous and wide negotiations (initiated using pass-through) Fault prediction support (Compaq-supported drives only) SCSI Activity HD LED [1] SCSI Bus SCSI Connector (Ext) SCSI Connector (Int) Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition -October 1997 Technical Reference Guide 5-39...
Page 138: Scsi Connectors
Ground Ground Ground Ground Ground Ground Ground Ground Ground 5-40 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Pin 1 Table 5-23. Ultra SCSI Connector Pinout Signal Function DB0- Data Bit 0 DB1- Data Bit 1...
Page 139: Chapter 6 Audio Subsystem
FM synthesis for playback of MIDI (.MID) files is also included. This chapter covers the following subjects: Functional description (6.2) Programming (6.3) Specifications (6.4) page 6-2 page 6-8 page 6-11 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition - October 1997 Technical Reference Guide...
Page 140: Functional Description
(i.e., the type designed to be used with portable radio/cassette/CD players). Using this connector defeats (mutes) the internal speaker and Line Out signals. Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor...
Page 141 Figure 6–1. Audio Subsystem Block Diagram (L/R) Spkr Off Mute Volume Control Circuit (L/R) (L+R) Mute (L/R) ISA Bus Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition - October 1997 Technical Reference Guide Headphones Backplane Connector Int. Speaker Line...
Page 142: Pcm Audio Processing
Each sample is quantized into a digital code that specifies the voltage level of the analog signal at that particular time. The quantizing format options are as follows: Mono or stereo 8- or 16-bit Signed or unsigned Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Quantized Values 8-Bit First Edition - October 1997...
Page 143 ESPCM is a proprietary format that offers greater performance. B. Descrete Level Waveform C. Final Analog Output Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition - October 1997 Technical Reference Guide...
Page 144: Table 6-1. Audio Moded
Right 16-bit Mono Mono Hi 16-bit Stereo Left Hi Figure 6–4. Audio Subsystem-to-ISA Bus PCM Audio Data Formats / Byte Ordering Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Table 6-1. Audio Mode Differences Compatibility Mode...
Page 145: Fm Synthesis Audio Processing
Figure 6–6. Audio Car-to-ISA Bus FM Audio Data Format Modulating Signal Carrier Oscillator Frequency Cntrl Address Data Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition - October 1997 Technical Reference Guide FM Signal Address Data...
Page 146: Audio Subsystem Programming
DMA channels. Typically, dual DMA operation would use DMA channel 1 for capture (recording) and DMA channel 0, 1, or 3 for playback. Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor...
Page 147: Control
MPU-401 Port 388-38Bh FM Synthesizer (alias of 2n0-2n3h) Table 6-3. Index Function Master Volume FM Volume CD Volume Line Volume Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition - October 1997 Technical Reference Guide...
Page 148: Figure 6-4. Audio Subsystem
Wave Select NOTE: Refer to OEM’s ES1868 data sheet for detailed registers descriptions. Abbreviations: AM Amplitude Modulation (tremolo) Vib Vibrato 6-10 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Table 6-4. Index Function 60, 62h Master Volume (Left, Right) Master Volume Control Volume Int.
Page 149: Specifications
30 K ohms (nom) 16 ohms (min) 26 db 0 - 22.5 db -46.5 - +10 db 450 - 4000 Hz Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition - October 1997 Technical Reference Guide 6-11...
Page 150 Chapter 6 Audio Subsystem This page is intentionally blank. 6-12 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition - October 1997...
Page 151: Chapter 7 Power Supply And Distribution
This chapter describes the power supply and method of general power and signal distribution in the Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II processor. All models use a similar switching-type power supply. The desktop unit employs a 200-watt supply while the minitower unit features 280-watt supply.
Page 152: Power Supply Assembly
FAN OFF signal if the ambient temperature of the power supply is too high. Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Table 7-1.
Page 153: Power Control
Pressed and Held At least Four Seconds Before Release: If the button is held in for at least four seconds and then released, PS On is negated, de-activating the power supply. Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition - October 1997...
Page 154: Power Distribution
RTN = Return (signal ground) GND = Power ground RS = Remote sense FO = Fan off = not used Figure 7–2. Power Cable Diagram Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Drive Assemblies P2 [2] System...
Page 155: Low Voltage Distribution
00100 1.85 VDC 2.2 VDC 00101 1.80 VDC 2.1 VDC 00110-01111 Reserved CPU not installed Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition - October 1997 Technical Reference Guide Microprocessor VccP Pentium II Processor...
Page 156: Signal Distribution
NOTES: [1] No. of connectors determined by formfactor/riser card type (refer to chapter 2). Deskpro 4000 Deskpro 6000 Figure 7–4. Signal Distribution Diagram Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Hood Switch Cover Backplane Type...
Page 157: Introduction
For detailed information regarding the BIOS, refer to the Compaq Basic Input/Output System Technical Reference Guide. page 8-2 page 8-5 page 8-17 page 8-18 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition- October 1997 Technical Reference Guide...
Page 158: Chapter 8 Bios Rom
(such as the speed beeps and screen messages). Error messages are still displayed. The QuickBoot mode is programmable (through the INT 15, AX=E845h call) as to either TERSE (default) or VERBOSE mode. Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Scroll Lock Meaning Administrator password required.
Page 159: Accessing Configuration Memory
This function is intended for Plug ‘n Play (PnP) support (refer to section 8.5 “Plug ‘n Play” for more information. Two variances of the function are available and described as follows: Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition- October 1997...
Page 160: Accessing Cmos Feature Bits
The BIOS function INT 15, AX=E845h is used for accessing areas in non-volatile memory used to store variables for various features. This is a Client Management function and is described in section 8.4. Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition – October 1997...
Page 161: Client Management Support
Entry point for the BIOS32 Service Directory Revision level Length of data structure (no. of 16-byte units) Checksum (should add up to 00h) Reserved (all 0s) Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition- October 1997 Technical Reference Guide...
Page 162 The following subsections describe aspects of Client Management unique to this system. For a general description of these BIOS functions refer to the Compaq BIOS Technical Reference Guide. Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor ; sig ;...
Page 163: System Id
Record ID for System Standby Timeout No. of Data Bytes in Record First Value Last Value System System ID Pentium II-based 0368h Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition- October 1997 Technical Reference Guide Default Value Default Value...
Page 164 Maximum Memory Installable 0Ch, 0Dh Reserved Processor Designer System Cache Error Correction NOTE: [1] Determined by system at runtime. Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition – October 1997 Default Value Default Value...
Page 165 Serial Port Connector Type Serial Port Maximum Speed Serial Port Maximum Speed Serial Port Maximum Speed DMA Burst Mode Support Keyboard Connector Type Compaq Deskpro 4000 and 6000 Personal Computers First Edition- October 1997 Technical Reference Guide Default Value 04h, DT...
Page 166 Automatic Server Recovery Record, SIT Record 0Bh (Not Used) Memory Banks Information Record, SIT Record 0Ch (Not Used) Multiprocessor Feature Information Record, SIT Record 0Dh (Not Used) 8-10 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition – October 1997 Default...
Page 167 Hood Removal Support Bit Location Hood Removal NOBOOT CMOS Byte Offset Hood Removal NOBOOT CMOS Bit Location Software Hood Lock NOTE: [1] Determined at runtime. Compaq Deskpro 4000 and 6000 Personal Computers First Edition- October 1997 Technical Reference Guide Default Value...
Page 168: Drive Fault Prediction
If data is returned indicating possible failure then the following message is displayed: “1720-Intellisafe Hard Drive detects imminent failure” 8-12 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition – October 1997...
Page 169: Dimm Support
01h, No DIMM EEPROM or socket empty 02h, Boundary error (offset or no. of bytes to read exc. cap) 86h, Not supported Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition- October 1997 Technical Reference Guide...
Page 170 “207-ECC Corrected Single Bit Errors in DIMM/SIMM Pair(s) x,x…” x = DIMM/SIMM pair numbers 0 through 3. 8-14 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor AH = 0 AH = 86h (Not supported)
Page 171: Security Functions
0011 = Bit 3 0100 = Bit 4 0101 = Bit 5 0110 = Bit 6 0111 = Bit 7 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition- October 1997 Technical Reference Guide 8-15...
Page 172: Accessing Cmos Feature Bits
NOTE: For full bit definitions refer to the Compaq BIOS Technical Reference Guide . [1] Determined at runtime. 8-16 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor 40 bits, all 0s 40 bits, all 0s 40 bits, all 0s...
Page 173: Pnp Support
1 of the control flag set for static configuration) with the results from the calls made prior to invoking this function. Table 8-1. Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition- October 1997...
Page 174: Power Management Support
15 minutes before Standby entered: Keyboard Mouse Serial port d. Diskette drive Hard drive 8-18 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor Name APM Control APM Status First Edition – October 1997...
Page 175 Get Power State 530Dh Enable/Disable Device Power Management 530Eh APM Driver Version 530Fh Engage/Disengage Power Management 5380h OEM (Compaq) Specific APM Function Compaq Deskpro 4000 and 6000 Personal Computers First Edition- October 1997 Technical Reference Guide featuring the Pentium II Processor 8-19...
Page 176 Chapter 8 BIOS ROM This page is intentionally blank. 8-20 Compaq Deskpro 4000 and 6000 Personal Computers featuring the Pentium II Processor First Edition – October 1997...
Page 177: Appendix Aerror Messages And Codes
Appendix A ERROR MESSAGES AND CODES A. Appendix A ERROR MESSAGES AND CODES INTRODUCTION This appendix lists the error codes and a brief description of the probable cause of the error. Note that not all errors listed in this appendix may be applicable to a particular system depending on the model and/or configuration.
Page 178: Power-On Self Test (Post) Messages
Appendix A Error Messages and Codes POWER-ON SELF TEST (POST) MESSAGES Table A–3. Power-On Self Test (POST) Messages Error Message Bad PnP Serial ID Checksum Address Lines Short! Cache Memory Failure, Do Not Enable Cache! CMOS Battery Failed CMOS Checksum Invalid CMOS System Options Not Set CMOS Display Type Mismatch CMOS Memory Size Mismatch...
Page 179: Processor Error Messages
PROCESSOR ERROR MESSAGES (1xx-xx) Table A–4. Processor Error Messages Message Probable Cause 101-01 CPU test failed 101-02 32-bit CPU test failed 101-91..94 Multiplication test failed 102-01 FPU initial sts. word incorrect 102-02 FPU initial cntrl. Word incorrect 102-03 FPU tag word not all ones 102-04 FPU tag word not all zeros 102-05...
Page 180: Memory Error Messages
Appendix A Error Messages and Codes MEMORY ERROR MESSAGES (2xx-xx) Table A–5. Memory Error Messages Memory Error Messages Message Probable Cause 200-04 Real memory size changed 200-05 Extended memory size changed 200-06 Invalid memory configuration 200-07 Extended memory size changed 200-08 CLIM memory size changed 201-01...
Page 181: Printer Error Messages
PRINTER ERROR MESSAGES (4xx-xx) Table A–7. Printer Error Messages Message Probable Cause 401-01 Printer failed or not connected 402-01 Printer data register failed 402-02 Printer control register failed 402-03 Data and control registers failed 402-04 Loopback test failed 402-05 Loopback test and data reg. failed 402-06 Loopback test and cntrl.
Page 182: Diskette Drive Error Messages
Appendix A Error Messages and Codes A.10 DISKETTE DRIVE ERROR MESSAGES (6xx-xx) Table A–9. Diskette Drive Error Messages Message Probable Cause 6xx-01 Exceeded maximum soft error limit 6xx-02 Exceeded maximum hard error limit 6xx-03 Previously exceeded max soft limit 6xx-04 Previously exceeded max hard limit 6xx-05 Failed to reset controller...
Page 183: Modem Communications Error Messages
A.12 MODEM COMMUNICATIONS ERROR MESSAGES (12xx-xx) Table A–11. Serial Interface Error Messages Message Probable Cause 1201-XX Modem internal loopback test 1201-01 UART DLAB bit failure 1201-02 Line input or UART failure 1201-03 Address line failure 1201-04 Data line fault 1201-05 UART control signal failure 1201-06 UART THRE bit failure...
Page 184: Hard Drive Error Messages
Appendix A Error Messages and Codes A.13 HARD DRIVE ERROR MESSAGES (17xx-xx) Table A–12. Hard Drive Error Messages Message Probable Cause 17xx-01 Exceeded max. soft error limit 17xx-02 Exceeded max. Hard error limit 17xx-03 Previously exceeded max. soft error limit 17xx-04 Previously exceeded max.hard error limit 17xx-05...
Page 185: Hard Drive Error Messages
A.14 HARD DRIVE ERROR MESSAGES (19xx-xx) Table A–13. Hard Drive Error Messages Message Probable Cause 19xx-01 Drive not installed 19xx-02 Cartridge not installed 19xx-03 Tape motion error 19xx-04 Drive busy erro 19xx-05 Track seek error 19xx-06 Tape write-protect error 19xx-07 Tape already Servo Written 19xx-08 Unable to Servo Write...
Page 186: Audio Error Messages (3206- Xx
Appendix A Error Messages and Codes A.16 AUDIO ERROR MESSAGES (3206-xx) Table A–15. Audio Error Messages Audio Error Message Message Probable Cause 3206-xx Audio subsystem internal error A.17 NETWORK INTERFACE ERROR MESSAGES (60xx-xx) Table A–16. Network Interface Error Messages Message Probable Cause 6000-xx Pointing device interface error...
Page 187: Scsi Interface Error Messages
A.18 SCSI INTERFACE ERROR MESSAGES (65xx-xx, 66xx-xx, 67xx-xx) Table A–17. SCSI Interface Error Messages Message Probable Cause 6nyy-02 Drive not installed 6nyy-03 Media not installed 6nyy-05 Seek failure 6nyy-06 Drive timed out 6nyy-07 Drive busy 6nyy-08 Drive already reserved 6nyy-09 Reserved 6nyy-10 Reserved...
Page 188: Cemm Priviledged Ops Error Messages
Appendix A Error Messages and Codes A.20 CEMM PRIVILEDGED OPS ERROR MESSAGES Table A–19. CEMM Privileged Ops Error Messages Message Probable Cause LGDT instruction LIDT instruction LMSW instruction LL2 instruction A.21 CEMM EXCEPTION ERROR MESSAGES Table A–20. CEMM Exception Error Messages Message Probable Cause Divide...
Page 189: Appendix B Ascii Character Set
Appendix B ASCII CHARACTER SET B. Appendix B ASCII CHARACTER SET INTRODUCTION This appendix lists, in Table B-1, the 256-character ASCII code set including the decimal and hexadecimal values. All ASCII symbols may be called while in DOS or using standard text- mode editors by using the combination keystroke of holding the Alt key and using the Numeric Keypad to enter the decimal value of the symbol.
Page 190 Appendix B ASCII Character Set Table B-1. ASCII Code Set (Continued) Symbol Ç ü é â ä à å ç ê ë è ï î ì Ä Å É æ Æ ô ö ò û ù ÿ Ö Ü ¢ £...
Page 191: C.1 Introduction
Appendix C KEYBOARD C. Appendix C KEYBOARD INTRODUCTION This appendix describes the Compaq keyboard that is included as standard with the system unit. The keyboard complies with the industry-standard classification of an “enhanced keyboard” and includes a separate cursor control key cluster, twelve “function” keys, and enhanced programmability for additional functions.
Page 192: Figure C-1. Keystrokep
Appendix C Keyboard KEYSTROKE PROCESSING A functional block diagram of the keystroke processing elements is shown in Figure C-1. Power (+5 VDC) is obtained from the system through the PS/2-type interface. The keyboard uses a Z86C14 (or equivalent) microprocessor. The Z86C14 scans the key matrix drivers every 10 ms for pressed keys while at the same time monitoring communications with the keyboard interface of the system unit.
Page 193: Figure C-2. Keyboard -T O -S
C.2.1 TRANSMISSIONS TO THE SYSTEM The keyboard processor sends two main types of data to the system; commands (or responses to system commands) and keystroke scan codes. Before the keyboard sends data to the system (specifically, to the 8042-type logic within the system), the keyboard verifies the clock and data lines to the system.
Page 194: Figure C-3. U.s. English
Appendix C Keyboard C.2.2 KEYBOARD LAYOUTS C.2.2.1 Standard Enhanced Keyboards Figure C–3. U.S. English (101-Key) Keyboard Key Positions Figure C–4. National (102-Key) Keyboard Key Positions Compaq Personal Computers Changed - November 1996...
Page 195: Figure C-5. U.s. Englishw
C.2.2.2 Windows Enhanced Keyboards Figure C–5. U.S. English Windows (101W-Key) Keyboard Key Positions Figure C–6. National Windows (102W-Key) Keyboard Key Positions 111 112 111 112 Compaq Personal Computers Changed - November 1996 Technical Reference Guide...
Page 196: Figure C-7. U.s. Englishw
Appendix C Keyboard C.2.2.3 Windows Enhanced Keyboards w/Erase-Ease Figure C–7. U.S. English Windows (101WE-Key) Keyboard Key Positions Figure C–8. National Windows (102WE-Key) Keyboard Key Positions Compaq Personal Computers 111 112 111 112 Changed - November 1996...
Page 197: C.2.3 Keys
C.2.3 KEYS All keys generate a make code (when pressed) and a break code (when released) with the exception of the Pause key (pos. 16), which produces a make code only. All keys, again, with the exception of the Pause key, are also typematic, although the typematic action of the Shift, Ctrl, Alt, Num Lock, Scroll Lock, Caps Lock, and Ins keys is suppressed by the BIOS.
Page 198 Appendix C Keyboard C.2.3.2 Multi-Keystroke Functions Shift - The Shift key (pos. 75/86), when held down, produces a shift state (upper case) for keys in positions 17-29, 30, 39-51, 60-70, and 76-85 as long as the Caps Lock key (pos. 59) is toggled off.
Page 199 C.2.3.3 Windows Keystrokes Windows-enhanced keyboards include three additional key positions. Key positions 110 and 111 (marked with the Windows logo or in combination with other keys to perform specific “hot-key” type functions for the Windows operating system. The defined functions of the Windows logo keys are listed as follows: Keystroke Window Logo Window Logo + F1...
Page 200: Table C-1. Keyboard - To -System
Appendix C Keyboard C.2.4 KEYBOARD COMMANDS Table C-1 lists the commands that the keyboard can send to the system (specifically, to the 8042- type logic). Table C–1. Keyboard-to-System Commands Command Key Detection Error/Over/run BAT Completion BAT Failure Echo Acknowledge (ACK) Resend Keyboard ID Note:...
Page 201: Table C-2. Keyboard Scanc
Table C–2. Keyboard Scan Codes Pos. Legend Mode 1 01/81 3B/BB 3C/BC 3D/BD 3E/BE 3F/BF 40/C0 41/C1 42/C2 43/C3 44/C4 57/D7 58/D8 Print Scrn E0 2A E0 37/E0 B7 E0 AA E0 37/E0 B7 [1] [2] 54/84 [3] Scroll Lock 46/C6 Pause E1 1D 45 E1 9D C5/na...
Page 202 Appendix C Keyboard Table C-2. Keyboard Scan Codes (Continued) Legend Delete E0 AA E0 53/E0 D3 E0 2A [4] E0 2A E0 53/E0 D3 E0 AA [6] E0 AA E0 4F/E0 CF E0 2A [4] E0 2A E0 4F/E0 CF E0 AA [6] Page Down E0 AA E0 51/E0 D1 E0 2A [4] E0 @a E0 51/E0 D1 E0 AA [6]...
Page 203 Table C-2. Keyboard Scan Codes (Continued) Pos. Legend Mode 1 31/B1 32/B2 33/B3 34/B4 35/B5 Shift (right) 36/B6 E0 48/E0 C8 E0 AA E0 48/E0 C8 E0 2A [4] E0 2A E0 48/E0 C8 E0 AA [6] 4F/CF [6] 50/D0 [6] 51/D1 [6] Enter E0 1C/E0 9C...
Page 204: Figure C-9. Scanner Elements
Appendix C Keyboard SCANNER DESCRIPTION The scanner keyboard, available as an option, integrates a scanner with a SpaceSaver Windows ’95 keyboard, providing the ability to scan hardcopy looseleaf documents for faxing or electronic storage. The scanner provides resolutions up to 400 dpi and 256 shades of gray and outputs through a standard serial interface to the system unit.
Page 205: C.3.1 Scanner Operation
C.3.1 SCANNER OPERATION The scanner requires minimum user interface for normal operation. Insertion of a sheet of hardcopy activates the scanner. Operating parameters such as resolution, brightness, and motor speed are programmable for optimum performance. Other characteristics such as gamma correction, modulation transfer function (MTF), image compression, and pixel normalization are optimized through the use of pre-computed tables that are downloaded for image correction and adjustments when necessary.
Page 206: Figure C-10. Scanner Operation
Appendix C Keyboard Start Scan Image (Image Aquisition) PRNU Correction Correction Resolution Conversion Threshold Output Desired? Gamma Conversion Halftone Output Desired? Grayscale Compensation Figure C–10. Scanner operation Flow Chart C-16 Compaq Personal Computers Error Type Diffusion Halftone Pattern Dither Pattern Dither Algorithm Packetized &...
Page 207: Table C-3. Scanner Performance
C.3.1.1 Resolution/Shade Depth The drive motor mechanism of the CIS supports a vertical resolution of 400 dpi. The CIS provides a maximum horizontal resolution of 200 dpi. These factors provide true spatial resolutions of 100 and 200 dpi. Using horizontal interpolation, pseudo 300 and 400 dpi spatial resolutions are possible.
Page 208: Table C-4. Scanner I/F Signals
Appendix C Keyboard C.3.2 SCANNER INTERFACE The scanner communicates with the system unit (host) using a serial port as the primary choice of connection. The scanner interface is adaptable to several types of host connections as shown in Table C-4 (unshaded portion describes standard scanner interface with Compaq system unit). Table C–4.
Page 209 C.3.2.1 Pnyb Mode In the parallel nibble or “Pnyb” mode, the scanner transfers scanned information to the system unit (host) four bits (a nibble) at a time using the P3..P0 signals, which conform to RS-232 voltage and timing specifications. The P3..P0 signals are mapped to bits <7..4> respectively of the Modem Status Register (primary address 3FEh).
Page 210: Table C-5. Scanner Specifications
Appendix C Keyboard C.3.3 SCANNER SPECIFICATIONS/REQUIREMENTS Table C–5. Scanner Specifications Scanner Specifications Parameter Dimensions (Complete keyboard unit): Width Height Depth Weight (Complete keyvoard unit) Scanner Paper Sizes: Minimum Maximum Maximum Scanned Resolution (input) Maximum Scanning Resolution (output) Maximum Scan Time (8.5 x 11” sheet) Power Requirements (Scanner only): Input Voltage Maximum Current Drain (scanning)
Page 211: Onnector
Appendix D MATROX 1064SG GRAPHICS CARD D. Appendix D Matrox MGA 1064SG Graphics Card INTRODUCTION This appendix describes the Compaq/Matrox MGA 1064SG graphics card. This graphics card installs in a PCI connector. This appendix covers the following subjects: Functional description (D.2) Display configurations (D.3) Monitor power management control (D.4) Connectors (D.5)
Page 212: D.2 Functional Description
Appendix D Matrox 1064SG Graphics Card FUNCTIONAL DESCRIPTION The Matrox MGA 1064SG graphics card is based on the Matrox MGA-1064SG graphics accelerator. The card includes two megabytes of SGRAM frame buffer memory, expandable to four megabytes with the addition of an optional 2-MB SGRAM module. . VD7..0 VSFC Connector...
Page 213: Table
DISPLAY CONFIGURATIONS Table D–1. Graphics Configuration Display Modes Pixel Resolution 640 x 480 @ 8 bpp 640 x 480 @ 16 bpp 640 x 480 @ 24 bpp 640 x 480 @ 32 bpp 800 x 600 @ 8 bpp 800 x 600 @ 16 bpp 800 x 600 @ 24 bpp 800 x 600 @ 32 bpp...
Page 214: Figure D-3. Vga Monitorc
Appendix D Matrox 1064SG Graphics Card CONNECTORS Figure D–3. VGA Monitor Connector, (Female DB-15, as viewed from rear). Table D–3. DB-15 Monitor Connector Pinout Signal Description Red Analog Blue Analog Green Analog Not used Ground R GND Red Analog Ground G GND Blue Analog Ground B GND...
Page 215: Figure D-5. Graphics Memory
Figure D–5. Graphics Memory Expansion Connectors Table D–5. Graphics Memory Expansion Connector Pinout Graphics Memory Expansion Connectors Pinout J3 Connector Signal Signal RVMA2 MDQM7 3.3 VDC MDQM6 RVMA0 MDQM4 PD24 MDQM3 PD23 MDQM5 3.3 VDC MDQM2 3.3 VDC PD25 PD22 MDQM1 PD26 3.3 VDC...
Page 216 Appendix D Matrox 1064SG Graphics Card This page is intentionally blank. Compaq Personal Computers Original - September 1997...
Page 217: Figure E-1. Matrox Millennium
Appendix E MATROX MILLENNIUM-II GRAPHICS CARD Appendix E Matrox Millennium-II Graphics Card INTRODUCTION This appendix describes the Matrox Millennium-II Graphics Card used in some models. The Matrox Millennium-II Graphics Card is built by Compaq and based on the Matrox MGA- 2164Wgraphics controller and installs in the AGP slot on the system board.
Page 218: Figure E-2. Matrox Mga M
Appendix E Matrox Millennium II Graphics Card FUNCTIONAL DESCRIPTION The Matrox MGA Millennium-II Graphics Card installs in an AGP slot. The card is AGP- compliant. Operation of the AGP bus is almost identical to the PCI bus but operates at Host bus speed (i.e., in systems with the Pentium II 233, 266, or 300 processor the AGP bus operates at 66 MHz).
Page 219: Table
DISPLAY CONFIGURATIONS The Matrox Millennium-II graphics card directly supports standard CGA, EGA, and VGA modes. Using the supplied drivers, the Matrox Millennium graphics card supports the extended VGA modes listed in the following table. Unless otherwise indicated, all resolutions are supported by the video BIOS and the OS/2, Win3.1, WinNT3.1, Win95, and WinNT4.0 operating systems.
Page 220: Table
Appendix E Matrox Millennium II Graphics Card PROGRAMMING E.4.1 CONFIGURATION The Matrox Millennium-II graphics card works off the AGP bus and is configured through the MGA 2164W’s configuration space registers (listed in Table E-2) using PCI protocol. These registers are configured by BIOS during POST to the default configuration. Table E–2.
Page 221 Direct Draw 3 support Dynamic EDID Additional display mode support Additional language support Color calibration/gamma correction Advanced option setup Virtual desktop Unified driver support for Matrox Millennium, Performance, and Millennium II Uninstall utility Windows 95 APM 1.2 compliant Direct Draw 3 support...
Page 222: Figure E-3. Vga Monitorc
Appendix E Matrox Millennium II Graphics Card MONITOR POWER MANAGEMENT CONTROL This controller provides monitor power control for monitors that conform to the VESA display power management signaling (DPMS) protocol. This protocol defines different power consumption conditions and uses the HSYNC and VSYNC signals to select a monitor’s power condition.
Page 223: Figure E-4. Graphics Memory
Figure E–4. Graphics Memory Expansion Connectors Table E–6. Graphics Memory Expansion Connector Pinout Graphics Memory Expansion Connectors Pinout Signal Signal +3.3 VDC SD60 MDQ49 SD56 MDQ48 MDQ50 SD57 MDQ51 SD58 MDQ52 MDQ56 MDQ57 M_RST (Key) MDQ53 M_BLANK MDQ54 MDQ55 MDQ58 SD49 MDQ59 +5 VDC...
Page 224 Appendix E Matrox Millennium II Graphics Card Table E-6. Graphics Memory Expansion Connectors Pinout (Continued) Signal MDQ22 MDQ21 MDQ20 MDQ19 MDQ18 MDQ17 MDQ16 MDQ23 MDQ24 MDQ25 MDQ26 MDQ27 MDQ28 MDQ29 MDQ30 MDQ31 MDQ39 MDQ38 MDQ37 MDQ36 MDQ35 MDQ34 Compaq Personal Computers J3 Connector Signal Signal...
Page 225 INDEX abbreviations, 1-3 Accelerated Graphics Port (AGP), 4-11 acronyms, 1-3 administrator password, 4-47 AGP, 4-11 analog-to-digital converter (ADC), 6-4 APM BIOS functions, 8-19 architecture, system, 2-8 ASCII character set, B-1 AT attachment (ATA), 5-3 audio card, 6-1 battery replacement, 4-27 BIOS, ROM, 8-1 Black Box logic, 4-47 boot block ROM, 8-2...
Page 226 Magic Packet, 5-35, 7-3 mechanical design, 2-4 media write protect function (BIOS), 8-15 memory map 586-based system, 3-9 memory, expanding, 3-7 modes, graphics, D-3 monitor power control, D-3, 6 notational conventions, 1-2 Options, 2-3 parallel interface, 5-21 password, administrator, 4-47 password, power-on, 4-47 PCI bus, 2-8 PCI bus, overview, 4-2...

This manual is also suitable for:

Deskpro 6000

Compaq Deskpro 4000 Technical Reference Manual

Chapter 1 Introduction

Chapter 2 System Overview

Chapter 3 Processor/Memory Subsystem

Chapter 4 System Support

Chapter 5 Input/Output Interfaces

Chapter 6 Audio Subsystem

Chapter 7 Power Supply and Distribution

Chapter 8 Bios Rom

Appendix Aerror MESSAGES and CODES

Appendix B Ascii Character Set

Quick Links

Need help?

Questions and answers

Related Manuals for Compaq Deskpro 4000

Summary of Contents for Compaq Deskpro 4000
