- Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Mach Power WL- ICDBG24-073 o cerca il tuo prodotto tra le migliori offerte di Wireless e Bluetooth WIRELESS ACCESS POINT DUAL BAND 750MBPS WL-ICDBG24-073 USER MANUAL...
- Page 2 REV211218...
- Page 3 Thanks for choosed our product ___________________________________________________________________ INDEX Chapter 1 Hardware and Operation mode Instruction 1.1 LED indicator 1.2 AP Interface 1.3 Power Supply 1.3.1 PoE Adapter Power Supply 1.3.2 Powered by PoE Switch 1.3.3 Connect Wireless AP with PC Chapter 2 Login Chapter 3 WEB GUI interface Setting...
-
Page 4: Chapter1 Hardware And Operation Mode Instruction
CHAPTER1 HARDWARE AND OPERATION MODE INSTRUCTION LED indicator Green: Power Indicator Blue: WiFi Indicator AP Interface RST: Reset Button, it make AP revert to default data after press it 15 sec. WAN: Gigabit WAN Port, connect with ADSL modem or Internet mainly. It will be LAN port under Wireless AP and WiFi Repeater operation mode LAN: Gigabit LAN Port to end users LED: LED Indicator of WAN port and LAN port... - Page 5 The diagram of LAN cable connection showed as follow: CHAPTER2 LOGIN 1. Connect the Ceiling AP with computer 2. Configure the PC’s local connection IP address as 192.168.0.X (X is number from 2 to 253), subnet mask is 255.255.255.0, follow the image.
-
Page 6: Chapter3 Web Gui Interface Setting
CHAPTER3 WEB GUI INTERFACE SETTING Status After login, then Device Status will be showed: In this ceiling wireless AP, the default operation mode is AP mode. Then in 2.4G Wireless Setting, GUI configuration page showed as below: User can configure the SSID, password, band width, channel here, then Apply to finish. - Page 7 LAN Setting to configure the DHCP or Fix IP AP location setting: can mark where the AP set up, and AP name as netx image: Wizard Configuration Click Wizard in Status page, will pop up following page to configure the operation mode: There are four operation mode of this ceiling wireless AP, and there are explanation for each operation mode for better application.
- Page 8 When click Next, then will complete the Gateway mode setting and show following picture: When return to Status, the page showed as follow:...
- Page 9 3.2.2 WiFi Repeater mode Click WiFi Repeater operation mode in Wizard, then following page will pop up, and choose the right SSID to bridge, then next After click Next button, then should configure the wireless settig as follow, then click Next to finish: Click Return button, will back to Status, show Repeater mode data, show fail or success, and user can configure this data in this page if required.
- Page 10 3.2.3 WISP Operation mode Click WISP operation mode in Wizard, then will pop up the configure page, pls set the WISP operation mode based on the stepes showed in picture: Configure the right WAN setting in WISP operation mode, then next.
- Page 11 Configure wireless data showed as follow: Then complete and back to status, will show the connection fail or suc- cess, then can configure the data based on request: Remark: When click WAN Setting, will pop up following picture...
- Page 12 3.2.4 AP operation mode Set the wireless data, AP Location info as required, then click next to continue and enter into LAN setting. After LAN setting, complete the AP mode configuration and back to Status:...
- Page 13 Advanced Setting In advanced setting, user can check the ceiling AP’s firmware version, working status, 2.4G wireless, 5.8G Wireless, LAN Status, upgrade firmware, Reset Let’s Click Advanced Setting in status page, will show return home, Setup Wizard which we showed before. Let’s shown mode in Device Status, 2.4G Wireless, 5.8G Wireless, Network and Management.
- Page 14 2.4G Wireless Setting: In this part, will show the 2.4G Basic Setting, Virtual AP, Access control and Advanced Setting 2G Wireless Analyzer: Mainly to analyze the AP’s singal strength in some channel, to make user more easy to choose the right channel and avoid the wifi interface.
- Page 15 Virtual AP: There are 3 virtural AP in 2.4G wireless, if need virtural SSID, then users can configure it showed in following picture 2.4G Access Control: Mainly show MAC allow or deny 2.4G Advanced Settings: In this page, will show the regional, RF Power, Max user access. 5.8G Wireless Setting: Almost same as 2.4G Wireless...
- Page 16 Network setting: In this page, mainly to show the LAN setting and VLAN as follow...
- Page 17 Management: In this part, show the system time, Logs, upgrade fir- mware, system, user info. And we show System time, how to upgrade firmware and system page to users...
-
Page 18: Chapter4 Share Internet And Obtain Ip Address Automatically
CHAPTER4 SHARE INTERNET AND OBTAIN IP ADDRESS AUTOMATICALLY Set computer’s TPC/IP as Obtain an IP address automatically, Obtain DNS server address automatically as following picture showed. the computer will obtain the IP address from router or base station to get Internet. CHAPTER5 TROUBLE SHOOTING Failure phenomenon... -
Page 19: Chapter 6 Declaration Of Conformity
Pls Check the computer’s IP address and DNS setting. If it is The connection of Wireless AP and AP is suc- cess, but the dynamin, set the network card as automatically obtain. If it is computer can’t share interne static IP, pls contact with ISP for correct IP address and DNS address. - Page 20 Per qualsiasi informazione ed aggiornamento sui prodotti > www.machpower.it visita il nostro sito Mach Power è un marchio registrato ® All Right Reserved...
