Thanks for choosed our product ___________________________________________________________________ INDEX CHAPTER 1 Hardware Introduce and Power 1.1 Interface Description 1.2 Powered by PoE Adapter 1.3 Powered by PoE Switch CHAPTER 2 Run and Login CHAPTER 3 Operation Mode Setting CHAPTER 4 System Tools and Advanced Settings 4.1 System tools 4.2 Advanced Settings 4.3 Operation Mode...
CHAPTER 1 HARDWARE INTRODUCE AND POWER Interface Description Powered by PoE Adapter The connection diagram showed as P2, internet cable connect to PoE adapter’s LAN Port, Ceiling AP’s RJ45 port connect to PoE adapter’s PoE Port, then PC will access into ceiling AP through wireless. Powered by PoE Switch The connection diagram shows as P3, Internet cable from PoE Switch to Ceiling AP’s WAN Port, then PC access into ceiling AP wired/wireless.
internet Gateway AP Controller PoE Switch CHAPTER 2 RUN AND LOGIN Power this in wall AP in right way Set an IP address for your PC: this Wireless Access Point default IP is 192.168.0.254, configure local IP address as 192.168.0.X(X can be selected from 1-253), the same network segment as this access point, subnet mask is 255.255.255.0...
Connect Wireless Access Point with PC by Wireless Pls note, then the default SSID is MachPower2.4, default passwords are 12345678. Log in: Type 192.168.0.1 in your IE, will pop up following picture, pls input admin/admin in User name/Password to Log into this in wall AP CHAPTER 3 OPERATION MODE SETTING Let’s show how to set it from Quick Setup...
Please note: • If signal strength “ ” show blue, mean work fine. • if signal strength “ ” show red, should be some problem. From this page, can see there are Internet Settings, Wireless Repeater, Wireless Coverage operation mode, user can choose the right operation mode based on needs.
mic IP or PPPOE based on your networking, then input the user name, passwords in PPPOE part, after that can change the SSID, Channel, Key as you like, then apply. B. Wireless Repeater: In this mode, the in wall AP will extend the exist wireless networking signal for more range after bridge it SSID and all interfaces.
Page 9
Then scan AP, choose AP, input AP’s passwords to finish the connection setting...
Page 10
If you want to change this device’s SSID, channel, Key, then set it from Wireless Part in P10. After that, then apply. C. AP Mode: in this mode, LAN internet is from the top gateway to Switch, then to in wall AP, the wired networking will change to Wireless network and DHCP disable via this operation mode.
CHAPTER 4 SYSTEM TOOLS AND ADVANCED SETTINGS System tools In system tools, you can ping any IP address/Domain easy to check the AP’s working status.
Page 12
Advanced Settings In this is part, users can set the Wireless AP’s networking function or other functions. Mainly for adminstrator. Click Advanced Setting, the wireless AP’s basic status, WiFi Status and LAN status will pop up as showed in following picture...
Page 13
Operation Mode In this part, same as the 3rd part we showed. Just more choose and setting for users Wireless Basic Settings: In this part, just to set the SSID, password for this wire- less AP. Virtual AP: For this Wireless AP, support 3 Virtual SSID, but disable in default.
Page 14
VLAN Settings: For this part, mainly for the tag VLAN, input the swi- tch’s VLAN ID the white blank part, then apply to finish. Pls note, the VLAN ID is from 0 to 4094. Access Control: In this part, mainly to control the access users. User can set it based on the networking environment.
Page 15
Advanced Settings: In this part, user can configure the AP’s mode, channel, Fregament Threshold, coverage threshold, Max Station. Remark: For Fragment Threshold, RTS Threshold, Beacon Interval, Aggregation, ShortGI, Rev Option, we recommand to keed in default.
Page 16
Max Station, mean QTY of end users. 0 mean no limited. Coverage Threshold: Applicated in Roaming mainly, the working status showed as follow: Network: In this part, mainly refer to LAN setting, including DHCP and Static IP, default is DHCP.
Page 17
CHAPTER 5 MANAGEMENT System Backup: Save the configuration files to your computer Restore: Using the saved configuration file recovery configuration Restore default: Restore the factory default settings, please press this button Reboot: Reboot the system User User Name: Reset new log-in user name Password: Reset new log-in password...
Confirm Password: Comparison to new password, to confirm user input password correctly in two times; Status: Enable or Disable to show wireless AP’s working log Remote Log Service: To decide whether send this log into some pointed remote server synchronously Upgrade firmware Browse and choose the firmware should upgrade from above picture, then click upgrade.
System Time Synchronization with the host: Synchronization time with connected PC and router Status: Enable or Disable NTP NTP Server: Select the server time synchronization Custom NTP Server: Setting user-defined synchronization server IP address Time Zone: Setting the router’s time zone...
Page 20
Mach Power ® is a registered trademark All Rights Reserved > www.machpower.it visit our website...
