CHAPTER1 HARDWARE AND OPERATION MODE INSTRUCTION LED indicator Green: Power Indicator Blue: WiFi Indicator AP Interface RST: Reset Button, it make AP revert to default data after press it 15 seconds. WAN: WAN Port, connect with ADSL modem or Internet mainly. It will be LAN port under Wireless AP and WiFi Repeater operation mode LAN: LAN Port to end users LED: LED Indicator of WAN port and LAN port DC: DC power connector...
Page 5
The diagram of LAN cable connection showed as follow CHAPTER2 LOGIN 1. Connect the Ceiling AP with computer 2. Configure the PC’s local connection IP address as 192.168.188.X (X is number from 2 to 254), subnet mask is 255.255.255.0, follow next image to finish.
4. After login, then P7 Device Status will be showed; This page will show the AP’s default operation mode, channel, connection status, CPU usage, Wireless settings, LAN Setting, AP’s Location, CPE’s hardware/firmware version. CHAPTER3 WEB GUI INTERFACE SETTING Status After login, then P8 Device Status will be showed In this page, show the AP’s default operation mode is AP mode, channel is 9, end user QTY of this AP, connection status, CPU usage status.
Page 7
LAN Setting to configure the DHCP or Fix IP AP location setting: can mark where the AP set up, and AP name as next image.
Page 8
Wizard Configuration Click Wizard in Status page, will pop up following page to configure the operation mode: There are four operation mode of this ceiling wireless AP, and there are explanation for each operation mode for better application. 3.2.1 Gateway Mode Click Gateway mode, will pop up following pictures: Please choose the right WAN setting mode, then click next to continue.
Page 9
To make the AP in some clear channel, user can click wireless analyzer at first. Picture showed as below When click Next, then will complete the Gateway mode setting and show following picture...
Page 10
When return to Status, the page showed as follow 3.2.2 WiFi Repeater mode Click WiFi Repeater operation mode in Wizard, then following page will pop up, and choose the right SSID to bridge, then next to complete. Click Return button, will back to Status, show Repeater mode data, show fail or success, and user can configure this data in this page if required.
Page 11
In wifi repeater operation mode, the default is SSID disable. If want to enable SSID, then click Wireless Setting. Please note, when click wireless relay setting, following page will pop up, you can make change from here easy: 3.2.3 WISP Operation mode Click WISP operation mode in Wizard, then will pop up the configure page, pls set the WISP operation mode based on the stepes showed in picture...
Page 12
Configure the right WAN setting in WISP operation mode, then next to complete Then complete and back to status, will show the connection fail or success, then can configure the data based on request...
Page 13
Remark: When click WAN Setting, will pop up following picture: 3.2.4 AP Operation mode Set the wireless data, AP Location info as required, then click next to continue and enter into LAN setting. After LAN setting, com- plete the AP mode configuration and back to Status...
Page 14
Advanced setting In advanced setting, user can check the ceiling AP’s firmware version, working status, wireless, LAN Status, upgrade firmware, Reset. Let’s Click Advanced Setting in status page, will show return home, Setup Wizard which we showed before. Let’s shown mode in Device Status, Wireless, Network and Management.
Page 15
2.4G Wireless Setting: In this part, will show the Basic Setting, Virtual AP, Access control and Advanced Setting 2G Wireless Analyzer: Mainly to analyze the AP’s singal strength in some channel, to make user more easy to choose the right channel and avoid the wifi interface.
Page 16
Virtural AP: There are 3 virtural AP in 2.4G wireless, if need virtural SSID, then users can configure it showed in following picture 2.4G Access Control: Mainly show MAC allow or deny Advanced Settings: In this page, will show the regional, RF Power, Max user access...
Page 17
Network setting: In this page, mainly to show the LAN setting and VLAN as follow...
Page 18
Management: In this part, show the system time, Logs, upgrade firmware, system, user info. And we show System time, how to upgrade firmware and system page to users:...
CHAPTER4 SHARE INTERNET AND OBTAIN IP ADDRESS AUTOMATICALLY Set computer’s TPC/IP as Obtain an IP address automatically, Obtain DNS server address automatically as following picture showed. the computer will obtain the IP address from router or base station to get Internet. CHAPTER5 TROUBLE SHOOTING The Failure phenomenon and solution...
Page 20
5GHz 300Mbps 300Mbps WL-ICNAP24-053 WL-CPE5G24-059 IN CEILING OUTDOOR WIRELESS ACCESS POINT CPE/ACCESS POINT 2.4GHz 5GHz 300Mbps 450Mbps WL-IWNAP24-054 WL-ICNAP48F-060 ACCESS POINT IN CEILING 2.4GHz ACCESS POINT 300Mbps 2.4GHz 300Mbps WL-ICDBG48-050 IN CEILING DUAL BAND ACCESS POINT/ROUTER 5GHz / 2.4GHz 1200Mbps...
