CAN/LIN/J2602 PICtail
Table 2-1:
Header
J18
J18
J18
J18
J18
J18
J18
J18
J18
J18
J18
J18
J18
J18
J18
J18
J18
J18
J18
DS70319B-page 20
™
(Plus) Daughter Board User's Guide
PINOUT MAP FOR MICROCONTROLLERS TO DEBUG HEADERS (Continued)
Pin # on Name of Pin on
Header Header
8 DEBUG38
9 DEBUG39
10 DEBUG40
11 DEBUG41
12 DEBUG42
13 DEBUG43
14 DEBUG44
15 CAN1TX
16 CAN1RX
17 CAN2TX
18 CAN2RX
19 LIN1TX
20 LIN1RX
21 LIN1CS
22 LIN1TXE
23 LIN2TX
24 LIN2RX
25 LIN2CS
26 LIN2TXE
PIC18 Explorer Pin Explorer 16 Pin
RF6
NC
NC
NC
NC
NC
NC
RB2
RB3
RC6 or RE5 (see J15)
RC7 or RE4 (see J16)
RC6 or RG3 (see J8)
RC7 or RG0 (see J4)
RB1
RC2
RD6 or RD7 (see J14)
RD7 or RE6 (see J13)
RB4
Must be connected to
either 5V or unused
PIC18 pin on the J18
header
 2011 Microchip Technology Inc.
RB7
RB5
RB10
RB11
RB12
RB13
RB14
RF1
RF2
RG1
RG0
RF3
RF2
RE8
RD15
RF5
RF4
RA14
RF13
