CAN/LIN/J2602 PICtail
FIGURE 1-1:
FIGURE 1-2:
DS70319B-page 12
™
(Plus) Daughter Board User's Guide
CAN/LIN/J2602 PICtail
CONNECTED TO EXPLORER 16 DEVELOPMENT BOARD
CAN/LIN/J2602 PICtail
Daughter Board
dsPIC33F or PIC24
Plug In Module
Explorer 16 Development
Board
CAN/LIN/J2602 PICtail
CONNECTED TO PIC18 EXPLORER DEVELOPMENT BOARD
PIC18 Explorer
Development Board
PIC18 Plug In
Module
™
(Plus) DAUGHTER BOARD
™
(Plus)
™
(Plus) DAUGHTER BOARD
™
CAN/LIN/J2602 PICtail
(Plus)
Daughter Board
2011 Microchip Technology Inc.
