• The wipe arc-line closest to the intersection, shows the wipe arc;
• Find in the table below the vertical displacement of the blade (H);
Armlength (L)
Units in mm
Now the wiper blade length can be calculated: Length of wiper blade = 0.9 * 2 * (E-H).
3.
Determine the place where the wiper is to be installed. The dimensions are shown
below. The wiper can be installed in any position above or below the window.
Glass or Bulkhead
4.
Place the windscreen wiper in the pre-drilled holes of the bulkhead (see fi gure). A rubber sealing
Hexagon nut
tightening torque 26Nm/19ft. lbs
gasket must be placed at both sides of the bulkhead. For pendulum system please make
secondary fi xing with hole at opposite end of housing.
Exalto type 223BDS
Determining the vertical displacement of the wiper blade
300
350
400
450 500 550 600
40°
19
21
25
26
30
34
45°
23
27
30
35
38
42
50°
26
33
36
43
47
52
55°
34
40
45
51
57
62
60°
40
47
54
60
67
74
65°
47
55
63
71
79
86
70°
55
63
73
81
90 100 109
75°
62
73
83
93 104 114 124
80°
70
82
94
105 117 129 140
85°
79
92
105
119 132 145 158
90° 86 103 117 132 146 161 176 190 205 220 234 249 264 278 293
Vertical displacement of the blade (H)
A ention!
When installing the wiper, reserve space for a housing or cover.
Glass or Bulkhead
Rubber sealing plate
Glass or Bulkhead
Rubber sealing plate
MANUAL WIPER SYSTEMS
650
700
750
800 850 900 950 1000
37
40
43
45
48
51
46
50
53
57
61
65
56
61
66
70
75
80
66
74
79
85
90
96 102 107 113
80
87
94
100
107 114 121 127 134
94
102
110
117
125 133 141 149 157
118
127
136
145 154 163 172 181
135
145
155
165 176 186 196 207
152
164
175
187 199 211 222 234
171
184
197
210 223 236
Stainless steel sealing plate
M8 washer
Nut M8
tightening torque 16.3/12ft. lbs
Hexagon locking nut
tightening torque 16.3Nm/12ft. lbs
Rubber weathercap
54
57
60
68
72
76
84
89
94
250
263
