MANUAL WIPER SYSTEMS
Switch panel 210321224-210351224:
PUMPS / HEATERS OUTPUT
--
+
Additional relay
box for heated
window operation
Additional relay box for pumps/heaters is not supplied in standard equipment.
Function Polarity
High speed
Low speed
Negative
Stop - self park
Positive
26
-- +
Motorcode Switch code
+ 53b
+ 53
- 31
31b
+ 53a
RELAY BOX
SRM2P
-M F S P -M F S P
W.
- - +
P.
CAN BUS CABLE
CAVOT8XX05
L = 5 mt.
WASH
PUMP
POWER
SUPPLY
Cable
H White
L Yellow
Black
P Blue
B Red
-M F S P
CONTROL
210321224
1 2
