2. Technical data

2.1 General
• Product
• Type
• Catalogue numbers
2.2 Electrical data 12 Volt
• Torque (max.)
• Voltage
• Current
• Power consumption (max.)
• Number of revolutions
• Recommended cable
• Recommended fuse
• Grounding
2.2 Electrical data 24 Volt
• Torque (max.)
• Voltage
• Current
• Power consumption (max.)
• Number of revolutions
• Recommended cable
• Recommended fuse
• Grounding

2.3 Mechanical data

• Dimensions
• Shaft diameters
• Mounting
• Bearing
• Wiper arms
• Wiper blades
• Wipe arc
• Weight
Exalto type 223BDS
MANUAL WIPER SYSTEMS
Exalto windscreen wiper
223BDS (Bulkhead fi tting, Disc adjustable, Open
housing)
XA2165.30 /-.32/-.35/-.40/-.45/-.50 (12V)
XA2166.30/-.32/-.35/-.40/-.45/-.50 (24V)
23 Nm
12 Volt
3 A
36 W
Low speed 40 rpm, high speed 60 rpm
5 wires, 1½ mm² (16 g) or 2½ mm² (14 g) up to 10 m
long
6 A slow blow
Insulated earth return
25 Nm
24 Volt
1,5 A
36 W
Low speed 40 rpm, high speed 60 rpm
5 wires, 1½ mm² (16 g) or 2½ mm² (14 g) up to 10 m
long
4 A slow blow
Insulated earth return
L x w x h = 174 x 107 x 103 mm
Drive shaft Ø 20 mm no support shaft
In bulkhead or glass (20, 35, 55, 75, 100 or 125 mm)
Bronze housing, self-lubricating
Model MD1 (Pendulum) up to 750 mm
Up to 750 mm
40°-90°, adjustable per 5° increments
Approx. 2,30 kg
