Ovation
5-piece Shower Wall Set
®
❑
2968SWT60 Bath Wall Set
• Glue-up installation
• Pre-measured walls adhere directly to greenboard
• Measures 60" (1524mm) W x 32" (813mm) D x
72" (1829mm) H
• Walls can easily be trimmed to fit 48-60" widths
(1219-1524mm) and 30-32" depths (762-813mm)
• 5-piece wall set (3 flat walls and 2 corner caddies)
for easy maneuverability and installation
• Durable, high gloss, acrylic; easy soap and water
clean-up
• Adhesive not included
• 10 Year Residential Limited Warranty
Nominal Dimensions:
60" wide x 32" deep x 72" height
(1524 x 813 x 1829 mm)
To Be Specified - Required:
.366 Silver Celestial
.367 Beige Parchment
.368 Sand Travertine
.369 Celestial Marble
.252 White Marble
To Be Specified - Optional:
2698.ST3R.011 60" (1524mm) RH drain Shower Base
2698.ST3L.011 60" (1524mm) LH drain Shower Base
2602.ST3.011 48" (1219mm) Center Drain Shower Base
AM00560.400.295 60" (1524mm) Shower Doors
AM00548.400.295 48" (1219mm) Shower Door
Ovation
Accommodates standard 48-60" x 30-32" x 72" alcoves
8"
(203mm)
32"
(813mm)
24"
(610mm)
72"
(1829mm)
HD-S10
5-Piece Shower Wall Set
®
42"
(1067mm)
60"
(1524mm)
55"
(1397mm)
42"
(1067mm)
29"
(737mm)
spec_2968SWT60 Ovation Bath Wall Set 1/20
Glue-up installation
8"
(203mm)
© 2020 AS America, Inc.
