American Standard Dupont Corian 4834.LSW Specifications

SHOWER WALLS FOR ALCOVE INSTALLATION
Product Features:
• Dupont Corian surface
®
• High gloss surface finish
• Simulated grout lines for luxurious tile
appearance
• Finished edge treatment
• Concealed corner and wall seams
• Premium wall height
• Installs over bath grade water proof
dry wall
❏ 4834.LSW
❏ 6034.LSW
To Be Specified - Required:
❏ Color: (see below)
To Be Specified - Optional:
❏ Soap Dish: 9030.000 (specify color - see below)
COLOR
SOLIDS
GLACIER WHITE
PATTERNS
AURORA
DUSK
VENARO WHITE
© 2008 AS America Inc.
ABBREV. CODE
GLW 950
AUR 996
SDK 998
VEW 965
FOR ALCOVE INSTALLATION
4834.ST
Shown with
Shower Enclosure (not included)
Side Panels
Model No.
(2 ea.)
6034.LSW 32-3/4 W x 76 H
(832 x 1930mm)
4834.LSW 32-3/4 W x 76 H
(832 x 1930mm)
NOTES:
REFER TO INSTALLATION INSTRUCTIONS SUPPLIED WITH SHOWER
WALLS FOR ADDITIONAL INFORMATION.
OPTIONAL SOAP DISH 9030.000 AVAILABLE AND MUST BE ORDERED
SEPARATELY.
IMPORTANT: Dimensions of fixtures are nominal and may vary within the
range of tolerances established by ANSI Standard Z124.3.
These measurements are subject to change or cancellation. No responsibility
is assumed for use of superseded or voided leaflet.
H145
SHOWER WALLS
DUPONT CORIAN
4834.STE2
Shower Base and
Backwall Panel (1 ea.)
Corner Panels
(2 ea.)
Upper (tongue) Lower (groove)
1-1/2 x 1-1/2 x 76 H 57-1/2 W x 29 H 57-1/2 W x 47 H
(38 x 38 x 1930mm) (1461 x 737mm) (1461 x 1194mm)
1-1/2 x 1-1/2 x 76 H 45-1/2 W x 28 H 45-1/2 W x 48-1/8 H
(38 x 38 x 1930mm) (1156 x 711mm) (1156 x 1222mm)
Revised 4/04
®
