Drawer Assembly - Mocka Eliza Coffee Table Manual

Eliza Coffee Table
Assembly Instructions
7
10
8
12
7
M
8
Slide panel [10] along the grooves between the side panels [8] and
[9] to form the base of the drawer. Attach panels [8], [9], [13] and
[11] as shown using 5x screws (M). Tighten with a screwdriver.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
9
9
11
12
7
8
I
9
E
7
12
Attach slide rail (I) and slide rail (H) to the underside of the side
panels as shown. Secure with 4x screws (E) and tighten with a
screwdriver. Attach handle (K) to panel [7]/[12] secure with 2x
screws (E). Tighten with a screwdriver.
8
H
E
E
K
12
7
