Motherboard User's Guide
Integrated A.G.P. Compliant Target/66Mhz Host-to-PCI Bridge:
•
Universal AGP v3.5 Compliant and Support 1.5V AGP Interface Only
High Performance & High Quality 3D Graphics Accelerator: Built-in a
•
high performance 256-bit 3D engine
Complete TV-OUT/Digital Flat Panel Solution: Built-in secondary CRT
•
controller to support independent display of secondary CRT, LCD and
TV-out
PCI 2.3 Specification Compliance
•
Integrated Multithreaded I/O Link Mastering
•
Multithreaded I/O Link Mastering with Read/Write Concurrent
•
transaction
Memory Support
Two 184-pin DIMM sockets for DDR SDRAM memory modules
•
Supports DDR400 memory bus
•
Maximum installed memory is 2GB
•
Expansion Slots
Two 32-bit PCI slots
•
One 8X AGP slot
•
One CNR slot
•
Onboard IDE channels
Two IDE connectors
•
Supports PIO (Programmable Input/Output) and DMA (Direct Memory
•
Access) modes
Supports IDE Ultra DMA bus mastering with transfer rates of 133/100/
•
66 MB/sec
VGA
High Performance & High Quality 3D Graphics Accelerator: built-in a
•
high performance 256-bit 3D engine
High Performance 2D Graphics Accelerator: maximum 64MB frame
•
buffer with linear addressing
MPEG-2/1 Video Decoder: MPEG-2 ISO/IEC 13818-2 MP@HL and
•
MPEG-1 ISO/IEC 11172-2 standards compliant
AC'97 Audio Codec
Compliant with AC'97 2.3 specification
•
16-bit Stereo full-duplex CODEC with independent and variable
•
sampling rate
Support for 3.3v digital, 5v analog power supply and low power
•
consumption management
Two analog line-level stereo inputs with 5-bit volume control: LINE_IN,
•
CD
Standard 48-Pin LQFP
•
2
