When the system power is on, the power LED will remain blue.
When the power LED is RED, it indicates a power supply failure. To stop the alarm,
press the Alarm Reset button. Examine the power supply right away and replace the
failed power supply with a new one.
When the fan LED is red, it indicates a failed system fan, and the alarm is activated.
When the fan LED is pink, it indicates a failed CPU cooler and the alarm is also acti-
vated. To stop the alarm press the Alarm Reset button and then replace the failed
fan with a functioning one immediately.
If the temperature LED is red, it means that it has overheated inside the chassis
(more than 55 °C;131 °F). And if the temperature LED is pink, it means that it is over-
heated on the CPU card (more than 70 °C/158 °F). An audible alarm will be acti-
vated. To stop the alarm from beeping, press the Alarm Reset button. Inspect the fan
filter or temperature of the CPU card and the upper section of the chassis immedi-
ately. Make sure the airflow inside the chassis is smooth and not blocked by dust or
other particles.
Note! The detectability of the CPU cooler or CPU temperature depends on the
design of the individual CPU cards.
When the HDD LED is blinking, it indicates the data access from HDD. And when
HDD LED is turned off, it indicates no activity from HDD.
系统电源接通时，电源 LED 的蓝灯恒亮。
电源 LED 红灯亮时，表示电源模块发生故障。按下报警复位按钮即可停止报警声。用
户需立即检查电源模块并以完好模块替换故障模块。
当风扇 LED 红灯亮时，表示系统风扇发生故障。此时，报警器将被启动。当风扇 LED
粉灯亮时，表示 CPU 冷却器发生故障。此时，报警器将被启动。按下报警复位按钮即
可停止报警声。用户需立即以完好风扇替换故障风扇。
温度 LED 红灯亮时，表示机箱内部温度过高 （高于 55°
CPU 温度过高（高于 70°
报警声。用户需立即检查风扇滤网或 CPU 卡的温度以及机箱上部，确认机箱内的空气
流通良好、没有被灰尘等颗粒物阻塞。
注！ CPU 冷却器或 CPU 温度是否可检测取决于 CPU 卡的设计。
HDD LED 闪烁时，表示 HDD 数据正在被访问。HDD LED 不亮时，表示 HDD 未活动。
IPC-5122 User Manual/ 用户手册
） 。此时，声音报警器将被启动。按下报警复位按钮即可停止
C
20
） 。温度 LED 粉灯亮时，表示
C
