Advantech PCM-4825 Startup Manual

PCM-4825/4825L 486 SBC with VGA/LCD
and Audio
Startup Manual
Packing List Packing List
Packing List Packing List Packing List
Before you begin installing your card, please make
sure that the following materials have been shipped:
• 1 PCM-4825/4825L all-in-one single board computer
• 1 start-up manual
• 1 audio cable (PCM-4825 only)
• 1 3.5" IDE flat cable
• 1 keyboard/mouse cable
• 1 secondary serial port cable (RS-232/422/485)
• 1 parallel cable
• 1 floppy cable
• CD-ROM or disks for utility, drivers, and manual (in
PDF format)
If any of these items are missing or damaged, contact your
distributor or sales representative immediately.
Note: For detailed information on the
PCM-4825/4825L, please refer to the
enclosed CD-ROM or disk (in PDF format).
Specifications Specifications
Specifications Specifications Specifications
Standard SBC Functions
• CPU: Embedded AMD 5x86-133 (DX5-133)
processor
• BIOS: Award 128 KB Flash memory
• Chipset: VIA VT82C496G
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/epc
For technical support and service, please visit our
support website at:
http://support.advantech.com
This manual is for the PCM-4825/4825L Rev. A1 or
higher.
Part No. 2006482501
Printed in Taiwan
• System memory: One 72-pin SIMM sockets
(accepts 1/2/4/8/16/32 MB) and supports FPM or
EDO DRAM 1 ~ 32 MB
• Enhanced IDE hard disk drive interface: Supports
up to two IDE (VL-bus) hard disks. BIOS auto-
detect and PIO Mode 3 transfer protocol
• Serial ports: One serial RS-232 port, one serial RS-
232/422/485 port. Two 16550 serial UARTs
• Parallel port: One parallel port, supports SPP/EPP/
ECP mode
• Infrared port: Shared with COM2. Transfer rate up
to 115 Kbps
• Keyboard/mouse connector: Mini-DIN connector
supports a standard PC/AT keyboard and a PS/2
mouse
• Power management: Supports power saving modes
including Normal/Standby/Suspend modes. APM 1.1
compliant
Local-bus Flat Panel/VGA Interface
• Chipset: C&T 65550
• Display memory: 1 MB DRAM
• Display type: Supports CRT and flat panel (EL,
LCD, and gas plasma flat panel) displays.
Simultaneous display of CRT and flat panel possible
• Flat panel display mode: Up to 800 x 600 @ 256
colors
• CRT display mode: Non-interlaced CRT monitors
resolutions up to 1280 x 1024 @16 colors
Audio Function (PCM-4825 only)
• Chipset: ESS 1868/1869
• Audio controller: 16-bit Sound Blaster Pro
compatible
• Stereo sound: Full-duplex, integrated 3D audio
• Audio interface: Mic in, Line in, CD audio in, Line
out, Stereo speaker out
Mechanical and Environmental
• Dimension (L x W): 145 mm x 102 mm (5.9" x 4.2")
• Power supply voltage: +5 V (4.75 ~ 5.25 V)
• Power requirements: +5 V @ 2 A (typical)
• Operating temperature: 0 ~ 60° C (32° ~ 140° F)
• Weight: 0.65 kg (weight of total package)
1st edition
Aug. 1999
PCM-4825/4825L Startup Manual 1
