Type &
Object name
Instance
Humidity Input Low
Value
AV 39
Humidity Input High
Value
AV 40
Minimum Fan
Output
AV 41
Maximum Fan
Output
AV 42
Low Fan Speed
AV 43
Setting
Med. Fan Speed
Setting
AV 44
Hi Fan Speed
AV 45
Setting
Minimum Off
Time
Minimum On Time
Stroke Time
AV 48
Set Point for
Humidity
AV 49
Dew Point Set
Point
AV 50
Occupancy Status
BI 0
Window-Door Status
BI 1
Cooling-heating
Status
BI 2
Relay 1 Status
BI 3
Relay 2 Status
BI 4
Relay 3 Status
BI 5
Relay 4 Status
BI 6
Relay 5 Status
BI 7
Relay 6 Status
BI 8
UM-15090500-AA1
Readable/
Writable
R/W
R/W
R/W
R/W
R/W
R/W
R/W
AV 46 R/W
AV 47 R/W
R/W
R/W
R/W
R
R
R
R
R
R
R
R
R
Description
Humidity Input Low Value
Humidity Input High Value
Minimum Fan Output at Auto
Fan Mode (for Modulating
Fan Application)
Maximum Fan Output at
Auto Fan Mode (for
Modulating Fan Application)
Low Fan Speed Setting (for
Modulating Fan Application)
Med. Fan Speed Setting (for
Modulating Fan
Application)
Hi Fan Speed Setting(For
Modulating Fan Application)
Minimum Off Time
Minimum On Time
Stroke time
Set Point for Humidity
Control
Dew Point Temperature
Set Point
Status of Occupancy
Window/ Door Status
Status of Cooling/Heating
Control
Output
Status of Relay 1
(Cooling Stage 1)
Status of Relay 2
(Cooling Stage 2)
Status of Relay 3
(Heating Stage 1)
Status of Relay 4
(Heating Stage 2)
Status of Relay 5
Status of Relay 6
Range and Definition
0~1000 (0.0～100.0
%RH)
0~1000 (0.0～100.0%RH)
0%~Reg 51
Reg 50~100%
0%~Reg 53
Reg 52~Reg54
Reg 53~100%
0~600 seconds
0~600 seconds
10~1600 sec.
0~1000 (0.0～100.0
%RH)
℃/°F
-999~9999: -99.9～999.9
0: Room Occupied
1: Room Unoccupied
0: Door/Window Closed
1: Door/Window Open
0: Close & Off 1: Open & On
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
