User Mode Thermostat Operation
# Item
1 Normal Display
2 Temperature
Setpoint
Setting using
Up/Down
Arrows
3 Mode Select
4
Fan Auto/
Continuo
us
5 Occupancy
Setting
UM-15090500-AA1
Description
Display current room or set-point
temperature
Set the desired temperature
Select the working mode:
Cooling ( ), Heating (
Ventilating ( .
)
Change the Fan mode between
Auto or Continuous.
Press SET, Used UP and DOWN
arrows to toggle between the
Occupied and Unoccupied setting.
Use MODE or SET buttons to
apply.
Remarks
Use the (SP) parameter in
the Engineering Menu or
[MSV6] Display Option for
BW2 or [MSV7] Display
Option for B2 model to
choose Current room or Set-
point temperature on display.
The [AV0] / [AV3] Cool / Heat
Occupied and [AV8] / [AV9]
Unoccupied Cool / Heat
temperature setpoints BACnet
objects can be used to write or
force the setpoint to a desired
value from BACnet supervisor.
After pressing the MODE
button, press the UP/ DOWN
, or
)
button to rotate the selections.
Dependent on Control Type.
When AUTO is displayed, the
fan is handled automatically.
When AUTO is flashing, the
fan is working under a delay
timer. When FAN icon is
spinning but AUTO is not
displayed, the fan will run
continuously until commanded
off.
The SET button could be
locked for applications
forbidding user occupancy
state control.
