Pullman CB60 Manual

Pullman CB60 Manual

60l wet & dry vacuum cleaner

Advertisement

Quick Links

IDEAL FOR:
Shops
Garages
Motels & Hotels
Restaurants & Cafes
CB60
60L WET & DRY
VACUUM CLEANER
2000W

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CB60 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Pullman CB60

  • Page 1 IDEAL FOR: Shops Garages Motels & Hotels Restaurants & Cafes CB60 60L WET & DRY VACUUM CLEANER 2000W...
  • Page 2 IMPORTANT Always switch off the cleaner and remove the plug from the electricity power supply before cleaning your appliance, when not in use, or attempting any maintenance task. The cleaner must only be connected to an AC power supply at the voltage shown on the rating label. This cleaner should only be used for its intended purpose as described in this instruction manual.
  • Page 3: Before You Begin

    This machine is equipped with a cord and plug. In the event that either of these parts get damaged, it must be repaired by a qualified technician. PULLMAN 60L WET & DRY CB60...
  • Page 4: Know Your Product

    8. Cord Holder 9. Connection Latches 10. 2 Piece Metal Tube 11. Carry Handles 12. Dry Pick Up Tool (hard floor only) 13. Wet Pick Up Tool 14. Crevice Tool 15. Dusting Brush Technical Information Model: CB60 220-240V ~ 50Hz/60Hz 2000W...
  • Page 5 1. Connect the 2-piece metal tube together. 2. Connect the handle on the hose to the tube. 3. Connect the tube to the desired cleaning accessory. 4. Connect the hose to the Pullman CB60. PULLMAN 60L WET & DRY CB60...
  • Page 6 ACCESSORIES Dry Pick Up Floor Tool The dry pick up floor tool is ideal for vacuuming hard floors. Do not use the dry pick up floor tool on carpets. Wet Pick Up Floor Tool The wet pick-up tool is ideal for wet applications. Fitting dusting brush and crevice tool To fit the accessories to the 2 piece metal tube, gently insert the tube into the top of the dusting...
  • Page 7: Operation

    OPERATION IMPORTANT: DISCONNECT THE CLEANER BEFORE CHANGING ACCESSORIES OR TO EMPTY THE CLEANER. Before turning on the Pullman CB60 Vacuum Cleaner, please check that the Drain Hose is secure to the tank Closed and the cap is fully closed. Dry Vacuum Cleaning 1.
  • Page 8: Wet Vacuum Cleaning

    OPERATION Wet Vacuum Cleaning 1. Ensure the cloth filter is removed before the cleaner is used. Remove 2. Turn the switch of the vacuum cleaner to position “I”. 3. You can determine the suction by using either 1 or 2 motors.
  • Page 9: Maintenance

    1. Release the connection latches to remove the canister lid. 2. Remove the cloth filter. 3. The cloth filter bag can be washed under luke warm water. 4. Dry by airing for at least 24 hours. PULLMAN 60L WET & DRY CB60...
  • Page 10: Specifications

    SPECIFICATIONS Voltage: 220V-240V 50Hz/60Hz Function: Wet & Dry Cooling Mode: Cycle Vacuum: 250mbar Volume: 60L Power: 2000W Airflow: 106L/S Barrel body diameter: 440mm Accessories: 40mm Cable: 8m Noise: <75DB Net Weight: 24.5KGS TROUBLESHOOTING TROUBLE POSSIBLE CAUSE REMEDY Suction weakens or Clogged filter Brush dirt from filter.
  • Page 11: Customer Care

    Hard Floor Squeegee Tool 31150014 Hard Floor Tool 31220267 Hose Assembly 31300392 2-Piece Chrome Tube 31130061 Dusting Brush 31120070 Crevice Tool 33701473 Float Cage 33400126 Cloth Filter 33101028 Pipe, Drain Assembly 33101026 Trolley Base PULLMAN 60L WET & DRY CB60...
  • Page 12: Conditions Of Warranty

    Conditions of warranty Your Pullman cleaner has a to repair or replace the cleaner, it will do so at its one year parts and labour own cost. warranty against product Electrical Home-Aids Pty Ltd is unable to accept defects and failures when the...
