Summary of Contents for Tiger WILDKAT JD6105-20E T4F
Page 1
JD6105-20E T4F WILDKAT BOOM TIGER REAR STOW SIDE BOOM MOWER Current as of 03/01/2021 PARTS LISTING WITH MOUNTING AND OPERATING INSTRUCTIONS Tiger Corporation 3301 N. Louise Ave. Sioux Falls, SD 57107 1-800-843-6849 1-605-336-7900 www.tigermowers.com 06011048...
Page 2
TO THE OWNER / OPERATOR / DEALER All implements with moving parts are potentially hazardous. There is no substitute for a cautious, safe-minded operator who recognizes the potential hazards and follows reasonable safety practices. The manufacturer has designed this implement to be used with all its safety equipment properly attached to minimize the chance of accidents.
Page 3
• Classify the problem • Hydraulic, electrical or mechanical - Read the trouble shooting section • Tractor or Truck chassis - Contact vehicle dealer • If unable to correct the problem yourself, contact your local Tiger Dealer after gathering: • Machine model _______________________ •...
PARTS SECTION______________________________________ COMMON PARTS SECTION____________________________ WARRANTY INFORMATION_____________________________ This symbol means: CAUTION – YOUR SAFETY IS AT RISK! When you see this symbol, read and follow the associated instructions carefully or personal injury or damage may result. Tiger is a registered trademark.
Page 8
SAFETY GENERAL SAFETY INSTRUCTIONS AND PRACTICES A careful operator is the best operator. Safety is of primary importance to the manufacturer and should be to the owner/operator. Most accidents can be avoided by being aware of your equipment, your surroundings, and observing certain precautions.
Page 9
SAFETY Operator Safety TO AVOID SERIOUS INJURY OR DEATH DO THE FOLLOWING: • READ, UNDERSTAND and FOLLOW Operator's Manual instructions, Warnings and Safety Messages. • WEAR SAFETY GLASSES, safety shoes, hard hat, hearing protection and gloves when operating or repairing equipment •...
Page 10
SAFETY CRUSHING HAZARDS TO AVOID SERIOUS INJURY OR DEATH FROM FALLING OFF TRACTOR, EQUIPMENT RUN OVER, ROLLOVER AND CRUSHING BY FALLING WING OR IMPLEMENT: • USE ROPS and SEAT BELT equipped tractors for mowing operations. • KEEP ROPS lock in up position. •...
Page 11
SAFETY CONNECTING OR DISCONNECTING IMPLEMENT SAFETY TO AVOID SERIOUS INJURY OR DEATH FROM BEING CRUSHED BY TRACTOR OR IMPLEMENT: WHEN connecting mower head to the boom • KEEP BYSTANDERS AWAY from tractor and mower. • Ensure there is enough room to lift and swing the boom with out hitting objects BEFORE connecting and disconnecting the mower head or boom: •...
Page 12
SAFETY THROWN OBJECTS HAZARDS ROTARY MOWERS CAN THROW OBJECTS 300 FEET OR MORE UNDER ADVERSE CONDITIONS. TO AVOID SERIOUS INJURY OR DEATH TO OPERATOR OR BYSTANDERS FROM THROWN OBJECTS: • KEEP bystanders 300 feet away STOP MOWING IF PASSERSBY ARE WITHIN 300 FEET UNLESS: •...
Page 13
SAFETY THROWN OBJECTS HAZARDS (Continued) MOWER OPERATION: • DO NOT exceed mower's rated Cutting Capacity or cut non-vegetative material. • USE ENCLOSED TRACTOR CABS when two or more mowers are operating in mowing area. • Do Not mow in areas where bees or insects may attack unless you WEAR PROTECTIVE CLOTHING or use enclosed tractor cab.
Page 14
SAFETY RUN OVER HAZARDS TO AVOID SERIOUS INJURY OR DEATH FROM FALLING OFF TRACTOR OR EQUIPMENT RUN OVER: • USE ROPS and SEAT BELT equipped tractors for mowing operations. • KEEP ROPS locked in UP position. • ONLY start tractor while seated in tractor seat. •...
Page 15
SAFETY PTO ENTANGLEMENT HAZARDS KEEP AWAY FROM ROTATING DRIVELINES AND ELEMENTS TO AVOID SERIOUS INJURY OR DEATH: hands, feet and body AWAY from rotating blades, drivelines and parts until all moving STAY AWAY KEEP elements have stopped. • STOP, LOOK and LISTEN before approaching the mower to make sure all rotating motion has stopped. •...
Page 16
SAFETY MOWER BLADE CONTACT HAZARDS KEEP AWAY FROM ROTATING BLADES TO AVOID SERIOUS INJURY OR DEATH FROM BLADE CONTACT: • STAY AWAY and KEEP HANDS, FEET and BODY AWAY from rotating blades, drivelines and parts until all moving elements have stopped. •...
Page 17
SAFETY HIGH PRESSURE OIL LEAK HAZARD TO AVOID SERIOUS INJURY OR DEATH FROM HIGH PRESSURE HYDRAULIC OIL LEAKS PENERATING SKIN: • DO NOT OPERATE equipment with oil or fuel leaks. • KEEP all hydraulic hoses, lines and connections in GOOD CONDITION and TIGHT before applying system pressure.
Page 18
SAFETY ELECTRICAL & FIRE HAZARDS TO AVOID SERIOUS INJURY OR DEATH FROM ELECTRICAL CONTACT WHEN WORKING AROUND ELECTRICAL POWER LINES, GAS LINES AND UTILITY LINES: • INSPECT mowing area for overhead or underground electrical power lines, obstructions, gas lines, cables and Utility, Municipal, or other type structure. •...
Page 19
SAFETY TRANSPORTING HAZARDS TO AVOID SERIOUS INJURY AND DEATH WHEN TOWING OR TRANSPORTING EQUIPMENT: • KEEP transport speed BELOW 20 mph to maintain control of equipment. • REDUCE SPEED on inclines, on turns and in poor towing conditions. • DO NOT TOW with trucks or other vehicles. •...
Page 20
SAFETY HAZARDS WITH MAINTENANCE OF IMPLEMENT AVOID SERIOUS INJURY OR DEATH FROM COMPONENT FAILURE BY KEEPING IMPLEMENT IN GOOD OPERATING CONDITION PERFORMING PROPER SERVICE, REPAIRS MAINTENANCE. BEFORE PERFORMING SERVICE, REPAIRS AND MAINTENANCE ON THE IMPLEMENT: STOP ENGINE AND PTO • , engage parking brake, lower implement, allow all moving parts to stop and remove key before dismounting from tractor.
Page 21
Tiger mowers use balanced and matched system components for blade carriers, blades, cuttershafts, knives, knife hangers, rollers, drivetrain components, and bearings. These parts are made and tested to Tiger specifications. Non-genuine "will fit" parts do not consistently meet these specifications. The use of “will fit”...
Page 22
SAFETY Decal Location NOTE: Tiger supplies safety decals on this product to promote safe operation. Damage to the decals may occur while in shipping, use, or reconditioning. Tiger cares about the safety of its customers, operators, and bystanders, and will replace the safety decals on this product in the field, free of charge (Some shipping and handling charges may apply).
Page 23
WARNING Blade Rotation LOGO Made in the USA LOGO Tiger Genuine Parts 22839 INSTRUCT Use Hand Grease Gun 32709 WARNING Use Genuine Tiger Parts 6T3221 INSTRUCT Lubrication Instructions SERIAL PLATE Serial Number Plate 06550058 INSTRUCT Blue Dot 06550057 INSTRUCT Red Dot...
Page 24
SAFETY 50”& 63” Flail ITEM PART NO. QTY. TYPE DESCRIPTION 24028 DANGER Thrown Object Hazard,Deflectors 32709 WARNING Use Genuine Tiger Parts 33224 DANGER Blades, Thrown Object D637 WARNING Disconnect Hydraulic Solenoid LOGO Tiger Logo 00758194 WARNING Pinch Point Hazard LOGO 50”...
Page 30
SAFETY Federal Laws and Regulations This section is intended to explain in broad terms the concept and effect of federal laws and regulations concerning employer and employee equipment operators. This section is not intended as a legal interpretation of the law and should not be considered as such.
JD6105-25E - REAR STOW SIDE ASSEMBLY SECTION Assembly Section 2-1...
Page 32
Always use a floor jack, hoist or fork lift to lift and raise heavy parts. Read and understand the entire Assembly Section instructions before attempting to mount your Tiger mower. Refer to the Parts Section of this manual for detailed illustrations to locate all parts.
Page 33
ASSEMBLY DRIVESHAFT AND FRONT PUMP MOUNTING Install driveshaft into the crankshaft adapter. Slide splined driveshaft coupler onto the pump driveshaft. Install the pump onto the mounting bracket. NOTE: the pump is offset to one direction and the pump should be installed with the offset side on top.
Page 34
ASSEMBLY APPLICATION OF LOCTITE 2047 MOWER MAINFRAME MOUNTING BOLTS All mower mainframe mounting bolts shall be secured utilizing Loctite 2047 and torqued per the Torque Chart in the maintenance section. Shake bottle for 60 seconds before use. To prevent clogging of nozzle, do not allow tip to touch metal surfaces during application.
Page 35
ASSEMBLY MAINFRAME INSTALLATION With an overhead hoist and / or jack-stands, raise one side of the frame up to the correctly matching mounting holes. Install capscrews and other hardware to secure the sides of the mainframe to the tractor casting, as shown on the tractor mount kit page in the Parts Section. DO NOT tighten at this time.
Page 36
ASSEMBLY SWITCHBOX WIRING Cover all wires with plastic wire wrap provided. Route the green wires along switchbox bracket and cab frame to the steering wheel console. Route the rest of the wires along the base of the right hand console and up to the rubber boot in the bottom right corner in the rear window of the cab.
Page 37
ASSEMBLY WEATHER-PACK / METRI-PACK ASSEMBLY These instructions apply to both Weather-Pack and Metri-Pack connectors. NOTE: Use the specific tool for the type of connector you are assembling. (ASM-C-0009) Assembly Section 2-7...
Page 38
ASSEMBLY JOYSTICK AND SWITCHBOX MOUNTING The switchbox is attached to the cross member on the front of the cab, to the right of the steering console. The joystick is attached to existing bolt holes in the door frame on the right side of the cab.
Page 39
ASSEMBLY VALVE MOUNTING BRACKET Attach the rear valve mounting bracket to the fender of the tractor by removing the two rear bolts on the left fender and the two rear bolts on the right fender. Use the hardware noted in the Parts Section to attach the valve mounting bracket to the tractor.
Page 40
ASSEMBLY CANBUS MODULE MOUNT Place the Canbus Controller mounting bracket (#06411524) on the floor of the cab, 4.5 inches from the right side console and 2.5 inches from the right side door. Drill a 3/8” hole through the floor and secure the bracket using a 3/8” bolt (#21637), spacer (#27082B) and 3/8” nylock nut (#21627).
Page 41
ASSEMBLY HOSE AND WIRE ROUTING Attach two clamps to the right rear wheel well for proper hose/wire routing. Drill one hole for each clamp. Use the lower rear corner of the wheel well as an origin for measuring. The holes should be 10mm or 3/8” reamed to accept 3/8” hardware. Measure along the back edge of the wheel well 10-1/2”...
Page 42
ASSEMBLY EFS ADAPTER HARNESS The EFS Canbus electronic lift valve used with the Tiger WildKat boom requires an addition to the wire harness used. The short adapter harness (Part # 06510313) is connected as shown in the photo below. See the Parts Section for more information on the lift valve used.
Page 43
ASSEMBLY CANBUS BOOM JOYSTICK CONTROL This electronic control valve is equipped with high-resolution actuators on Boom, Side Shift, Deck Roll, and Boom Swivel functions. These actuators have active fault monitoring. The Deck Shield section does not have active fault monitoring. The joystick provides a signal to the Plus-1 Module and the Module provides a ratio-metric voltage signal.
Page 44
ASSEMBLY CONTINUOUS DUTY SOLENOID SWITCH To mount the solenoid switch, use the existing holes in location shown below. The bottom hole may need to be ground to obtain the correct hole spacing to match the solenoid switch mount. Secure with provided 5/16” x 1” capscrews, lockwashers, and hex nuts. Route wires to and from the Continuous Duty Solenoid Switch as shown below.
Page 45
ASSEMBLY REAR STOW SIDE FLAIL HOSE ROUTING WARNING NOTE: The sudden release of hydraulic pressure could cause the sudden movement of very heavy parts. Anyone in the way of these parts could be severely hurt or killed. In order to prevent hydraulic failure, DO NOT ALLOW these hydraulic hoses to BREAK or BURST.
Page 46
(ASM-C-0023 RSS CANBUS EFS) FILLING HYDRAULIC RESERVOIR Refer to the Maintenance Section for filling specifications and hydraulic oil requirements. NOTE: Starting or running your Tiger mower before filling reservoir will cause serious damage to the hydraulic pump. (ASM-C-0004hydro resrv) Assembly Section 2-16...
Page 47
ASSEMBLY WHEEL WELL HYDRAULIC TANK INSTALLATION Install all fittings and tubes into tank and tank filter as shown in the Parts Section illustration. Insert tank sight glass onto the tractor side of the tank. Place the tank in the mounting bracket on the axle brace as shown in the Parts Section. Secure the tank with the hardware provided.
Page 48
ASSEMBLY WHEEL WEIGHT MOUNTING For all tractors using a boom mower, a wheel weight will be required for the rear left side wheel. It will be necessary to mount the weight in the wheel using the long capscrews, lockwashers, flatwashers, spacers (if applicable), and hex nuts per the diagram in the Parts Section.
Page 49
ASSEMBLY SINGLE COLUMN BOOMREST MOUNTING Carefully lower the boomrest and align the holes with those of the axle brace. Now install all attaching hardware, as shown in the Parts Section, loosely, to allow for the alignment with the axle brace. Tighten / torque all hardware on the axle brace and the boomrest.. (ASM-JD-0251 rss bmrst) MAIN BOOM INSTALLATION Using a hoist, install the boom swivel into the mainframe as shown in the Parts Section.
Page 50
ASSEMBLY FINAL PREPARATION FOR OPERATION Place operator’s safety and operation decals on the steering column and side console where they are clearly visible to the operator. These decals should be understood by each operator of the machine in conjunction with the Safety and Operation Sections of this book. The decals are to be maintained in good condition as a reminder to the operator, and should be replaced if damaged.
Page 52
TIGER BOOM MOWER OPERATING INSTRUCTIONS Tiger Booms are manufactured with quality material by skilled workers. The Boom is designed to attach to a tractor and operate various heads for a wide range of vegetative maintenance applications. The boom and heads are equipped with safety warning decals, protective deflectors, shields, and other safety features to provide operator and passerby protection, however, no shielding is 100% accurate.
Page 53
OPERATION 1.OPERATOR REQUIREMENTS Safe operation of the unit is the responsibility of a qualified operator. A qualified operator has read and understands the implement and tractor Operator’s Manuals and is experienced in implement and tractor operation and all associated safety practices. In addition to the safety messages contained in this manual, safety signs are affixed to the implement and tractor.
Page 54
OPERATION 2.TRACTOR REQUIREMENTS In addition to tractor horsepower and size required to operate the boom unit, the tractor must also be properly equipped to provide operator protection, to alert approaching vehicle drivers of the tractor’s presence, and to ensure tractor stability when mowing with the boom fully extended. Tractor Requirements and Capabilities •...
Page 55
OPERATION Never operate the Tractor and Mower Unit without an OPS (Operators Protective Structure) or Cab to prevent injury from objects thrown from ground or from overhead trimming. Stop mowing if workers or passersby are within 300 feet. (SBM-9) 2.3 Tractor Lighting and SMV Emblem If the tractor will be operated near or traveled on a public roadway it must be equipped with proper warning lighting and a Slow Moving Vehicle (SMV)
Page 56
OPERATION 2.4 Tractor Ballast To ensure tractor stability when operating on flat surfaces the left rear tractor tire MUST exert a minimum down force (weight) of 1500 lbs. on the ground when the tractor is on level ground, its boom is fully extended and the mower head is horizontal and two feet above the ground.
Page 57
OPERATION 3.1 Boarding the Tractor Use both hands and equipped handrails and steps for support when boarding the tractor. Never use control levers for support when mounting the tractor. Seat yourself in the operator’s seat and secure the seat belt around you.
Page 58
OPERATION 4.STARTING THE TRACTOR The operator must have a complete understanding of the placement, function, and operational use of all tractor controls before starting the tractor. Review the tractor operator’s manual and consult an authorized dealer for tractor operation instructions if needed. Essential Tractor Controls: •...
Page 59
OPERATION 5.CONNECTING ATTACHING HEADS TO THE BOOM 1. Start by attaching the pivot bracket(3) to the boom(1) using pin(5) and hardware. Next attach the cylinder to the pivot bracket(3) using pin(8) and roll pins. 2. Then attach the dogleg(4) to the mower(2) using pin(7) and hardware.
Page 60
OPERATION Periodically inspect all moving parts for wear and replace when necessary with authorized service parts. Look for loose fasteners, worn or broken parts, and leaky or loose fittings. Make sure all pins have attaching hardware. Serious injury may occur from not maintaining this machine in good working order.
Page 61
OPERATION 6.2 Boom Unit Pre-Operation Inspection and Service Inspect and service the boom arm and head prior to operation. Damaged and/or broken parts should be repaired and/or replaced immediately. To ensure the unit is ready for operation, conduct the following: OPS-B- 0020 Periodically inspect all moving parts for wear and replace when necessary with authorized service parts.
Page 62
OPERATION Relieve hydraulic pressure prior to doing any maintenance or repair work on the Implement. Place the Mower Head on the ground or securely supported on blocks or stands, disengage the PTO, and turn off the engine. Push and pull the control Levers or Joystick several times to relieve pressure prior to starting any maintenance or repair work.
Page 63
OPERATION Do not operate this Equipment with hydraulic oil or fuel leaking. Oil and fuel are explosive and their presence could present a hazard. Do not check for leaks with your hand! High-pressure oil streams from breaks in the line could penetrate the skin and cause tissue damage including gangrene.
Page 64
OPERATION ROTARY HEAD INSPECTION • Inspect blades and blade bolts for looseness and excessive wear. Rotate to 90° to make for checking easier. Replace damaged, worn, and missing blades as complete sets to maintain rotary balance. • Ensure motor bolts and nuts are tightened to the appropriate torque.
Page 65
OPERATION FLAIL HEAD INSPECTION • Inspect blades and blade bolts for looseness and excessive wear. Rotate to 90° to make for checking easier. Replace damaged, worn, and missing blades as complete sets to maintain cuttershaft balance. • Ensure rubber deflectors are in position and not damaged.
Page 66
OPERATION 6.3 Cutting Component Inspection Inspect blade pan and blade assembly for the following: OPS-U-0031 Inspect the Blades daily for abnormal wear. REPLACE BOTH BLADES on that carrier IMMEDIATELY if either blade has: • Become bent or deformed from it’s original shape or •...
Page 67
OPERATION Tractor PRE-OPERATION Inspection Mower ID#________________ Make ____________________ Date: ________________ Shift ____________________ Before conducting the inspection, make sure the tractor engine is off, all rotation has stopped and the tractor is in park with the parking brake engaged. Make sure the mower is resting on the ground or securely blocked up and all hydraulic pressure has been relieved.
Page 68
OPERATION Boom PRE-OPERATION Inspection Mower ID#________________ Make ____________________ Date: ________________ Shift ____________________ Before conducting the inspection, make sure the tractor engine is off, all rotation has stopped and the tractor is in park with the parking brake engaged. Make sure the mower is resting on the ground or securely blocked up and all hydraulic pressure has been relieved.
Page 69
A control lever decal similar to the one shown below should be near the control valve to remind the operator of the lever functions. The main control valve on the Tiger Boom Mower has four sections with tapered spools, located near the right side of the steering wheel.
Page 70
OPERATION 6.4 Switchbox The Safety Shield lever opens and closes the shield located on the front of the cutter head. When moving at or near the ground, always have the shield in th closed position. When mowing in the brush or in trees above ground level the shield may be opened for easier cutting.
Page 73
Install the manual valve handle onto valve and operate the functions individually to stow boom. After boom is stowed in rest, transport the unit to the maintenance facility and contact your Tiger dealer for assistance. DO NOT attempt to operate the valve manually for mowing operations! Note: Pushing manual valve handles “out”...
Page 74
OPERATION 7.1 Switch Box and Joystick Control The diagrams below and on the next page show the functions that are performed through the use of the joystick controller. The Safety Shield switch opens and closes the shield located on the front of the cutter head. When moving at or near the ground, always have the shield in the closed position.
Page 77
OPERATION RIGHT JOYSTICK ROLLER WHILE PRESSING BUTTON MOVES BOOM KNUCKLE ON A LEGAL REAR STOW BOOM SHIELD SWITCH(on switch box) OPERATES SAFETY SHIELD 8.DRIVING THE TRACTOR AND IMPLEMENT Safe tractor transport requires the operator to possess a thorough knowledge of the model being operated and precautions to take while driving with an attached implement.
Page 78
OPERATION Never operate the Tractor or Implement until you have read and completely understand this Manual, the Tractor Operator’s Manual, and each of the Safety Messages found in the Manual or on the Tractor and Implement. Learn how to stop the tractor engine suddenly in an emergency.
Page 79
OPERATION Transport only at speeds where you can maintain control of the equipment. Serious accidents and injuries can result from operating this equipment at high speeds. Understand the Tractor and Implement and how it handles before transporting on streets and highways. Make sure the Tractor steering and brakes are in good condition and operate properly.
Page 80
OPERATION 8.2 Brake and Differential Lock Setting Make sure the tractor brakes are in good operating condition. Tractor brakes can be set to operate independently allowing single rear wheel braking action or locked together to provide simultaneous rear wheel braking. FOR MOST DRIVING AND OPERATING CONDITIONS, THE BRAKE PEDALS SHOULD BE LOCKED TOGETHER TO PROVIDE THE MOST EFFECTIVE BRAKING ACTION.
Page 81
OPERATION 8.3 Driving the Tractor and Boom Start off driving at a slow speed and gradually increase your speed while maintaining complete control of the tractor. Never operate the tractor at speeds that cannot be safely handled or which will prevent the operator from stopping quickly during an emergency.
Page 82
OPERATION Never Leave the mower unattended while the head is in the raised position. The mower could fall causing serious injury to anyone who might inadvertently be under the mower . (SBM-4) Always keep a careful lookout and use extreme care when working around overhead obstructions.
Page 83
OPERATION Avoid mowing in reverse direction when possible. Check to make sure there are no persons behind the mower and use extreme care when mowing in reverse. Mow only at a slow ground speed where you can safely operate and control the tractor and mower. Never mow an area that you have not inspected and removed debris or foreign material.
Page 84
OPERATION Mow at the speed that you can safely operate and control the tractor and mower. The correct mowing speed depends on terrain condition and grass type, density, and height of cut. Normal ground speed range is from 2 to 5 mph(3-8 kph). Use slow mowing speeds when operating on or near steep slopes, ditches, drop-offs, overhead obstructions, power lines, or when debris and foreign objects are to be avoided.
Page 85
OPERATION 9.4 Mower Operation The rotating parts in this machine have been designed and tested for rugged use. However, they could fail upon impact with heavy solid objects-such as steel guard rails, concrete abutments,etc., causing them to be thrown at a very high velocity. Never allow cutter head to contact such objects. Inspecting the cutting area for such objects and removing them prior to mowing can help eliminate these potiential hazards.
Page 86
OPERATION For cutting brush, it is usually best to stop the tractor and swivel the boom and mower into foilage. The horizontal positioning action of the boom is designed to position the cutting head and provide a limited pressure relief when excessive pressure is applied to the boom. DO NOT use excessive force when positioning cutting head into heavy branches or stumps.
Page 87
OPERATION When cutting trees and brush approach material to be cut with the head perpendicular to material. The cutting edge of the blades should be the only elements in contact with material. The blade bar should not contact with material. The mower head blades should...
Page 88
OPERATION Do not allow knives to cut down to the ground. Position ground roller to maintain knife arc at a minimum of 2 inches above the ground. Knife contact or lug contact with ground will cause permanent damage to cutter shaft, knives, and knife attachment parts. 9.7 63”...
Page 89
OPERATION 9.8 Shutting Down the Attached Head- For Standard Equipment To shut down attached mower head, first bring the tractor to a complete stop. Decrease engine RPM to idle then disengage cutterhead. The mower head will come to a complete stop within a suitable amount of time.
Page 90
OPERATION 10.TRACTOR, BOOM, AND ATTACHED HEAD STORAGE Properly preparing and storing the unit at the end of the season is critical to maintaining its appearance and to help ensure years of dependable service. The following are suggested storage procedures: • Thoroughly clean all debris from boom and head to prevent damage from rotting grass and standing water.
Page 91
OPERATION 11.1 Placing Boom Arm on Boom Arm Rest - For Standard Equipment Before transporting tractor between locations, idle the tractor engine, disengage the attached head, and wait for all head motion to come to a complete stop. Place the boom in its storage cradle rest support and then turn the joystick master switch to the OFF position.
Page 92
OPERATION 11.2 Transporting on Public Roadways Extreme caution should be used when transporting the tractor and mower on public roadways. The tractor must be equipped with all required safety warning features including a SMV emblem and flashing warning lights to alert drivers of the tractor’s presence. Remember that roadways are primarily designed for automotive drivers and most drivers will not be looking out for you, therefore, you must look out for them.
Page 93
OPERATION When operating public roads, have consideration for other road users. Pull to the side of the road occasionally to allow all following traffic to pass. Do not exceed the legal speed limit set in your state or municipality for agricultural tractors. Always stay alert when transporting the tractor and mower on public roads.
Page 94
OPERATION 11.3 Hauling the Tractor and Implement Before transporting a loaded tractor and implement, measure the height and width dimensions and gross weight of the complete loaded unit. Ensure that the load will be in compliance with the legal limits set for the areas that will be traveled through.
Page 98
Regular maintenance at the intervals mentioned will result in the maximum efficency and long life of the Tiger Mower. When you purchase a Tiger Mower you also acquire another valuable asset, Tiger’s parts organization. Our rapid and efficent service has guaranteed the customer satisfaction for many years.
Page 99
MAINTENANCE Relieve hydraulic pressure prior to doing any maintenance or repair work on the Implement. Place the Mower Head on the ground or securely supported on blocks or stands, disengage the PTO, and turn off the engine. Push and pull the control Levers or Joystick several times to relieve pressure prior to starting any maintenance or repair work.
Page 100
MAINTENANCE Regular Maintenance The intervals at which regular servicing should be done are based on hours of operation. Use the tractors hour meter to determine when regular servicing is required. Refer to the Det ailed Maintenance section for futher instructions on greasing. Copy and use the Daily Maintenance sheet located at the end of this section.
Page 101
MAINTENANCE WEEKLY OR EVERY 40 HOURS ITEM SERVICE COMMENTS Rotary Spindle Lubricate Every 40 hours or weekly WEEKLY OR EVERY 50 HOURS ITEM SERVICE COMMENTS In Tank Hyd. Fluid Change Change after first 50 Filter hours only, then every 500 hours or yearly 10 micron filter) In-Line High Pressure Change...
Page 102
MAINTENANCE TROUBLESHOOTING SYMPTOMS CAUSE REMEDY 1. Loose Bolts 1. Check all bolts and tighten to Vibration recommended torque specs. 2. Cutter assembly 2a. Check for damage blades, disc Unbalanced or cutter shaft. Replace if needed. 2b. Check for wire, rope, etc. entangled in the cutter assembly 1.
Page 103
MAINTENANCE TROUBLESHOOTING (CONTINUED) SYMPTOMS CAUSE REMEDY 1. Belts Inspect belts and pulleys. Replace Motor runs but belts and repair as needed. will not cut. 2. Tensioner Adjust tensioner nuts tension should be 106 freq cyl/sec. 1. Contaminants Remove large nut on side of large Mower turns slowly restricting spool valve block.
Page 106
MAINTENANCE GRAFFITI REMOVAL Butyl cellosolve (for removal of paints, marking pen inks, lipstick, etc.) The use of masking tape, adhesive tape or lint removal tools work well for lifting off old weathered paints. To remove labels, stickers, etc., the use of kerosene or VM&P na phtha are generally effective. When the solvent will not penetrate sticker material, apply heat (hair dryer) to soften the adhesive and promote removal.
Page 107
MAINTENANCE DETAILED MAINTENANCE REPLACING HIGH PRESSURE HYDRAULIC FILTER ELEMENT: Ensure the system has been shut down and de- pressurized. Locate High Pressure Filter housing. Confirm that the element that is a bout to be installed matches the element p/n on the filter model tag.
Page 108
MAINTENANCE GREASING GROUND ROLLER SHAFT-FLAIL Locate grease zerks on eack end of roller tube at lower end of head. Normal conditions require one or two pumps in each bearing, using Lithium-Complex Extreme Pressure grease conforming to NLGI2-ISO 320 specifications. This is to be do ne with a standard grease gun daily or at 8 hour intervals.
Page 109
Inject Lithium-Complex Extreme Pressure grease conforming to NLGI2-ISO 320 specifications until grease begins to protrude from ends. GREASING SPINDLE Locate grease fitting o n inside of deck hou sing. Inject Tiger Spindle Lubricant, part number 06540000 into s pindle housing. Fill with lubricant until lubricant weeps out of to p spindle seal.
Page 110
MAINTENANCE TIGHTENING SPINDLE BOLTS The spindle mounting bolts should be checked and retorqued daily or every 8 hours of service. Torque the (6) bolts shown below to 357 dry or 315 ft. lbs. lubricated. GREASING PUMP DRIVE SHAFT COUPLER With engine stopped, ensure drive shaft alignment by grasping coupler and sliding back and forth.
Page 111
MAINTENANCE DRIVE SHAFT YOKE, U-JOINT STUB SHAFT WIth engine stopped, inject Lithium-Complex extreme pressure grease confirming to NLGI2-ISO 320 specifications into universal joints and slip yoke until grease appears at the seal. Grease them daily or every 8 hours. GREASING THE BOOM SWIVEL Locate the zerks on the main swivel boss (if applicable), main boom pivot boss (if ap plicable) and on both ends of th e boom swivel cyl inder.
Page 112
MAINTENANCE GREASING BOOM CYLINDER(S) PIVOT POINTS Locate the zerk on the butt end tang of cylinder and on rod end tang. Inject Lithium-Complex Extreme Pressure grease confirming to NLGI2- ISO 320 specifications until grease begins to protrude from ends. This procedure is to be used on the main boom cylinder, secondary boom cylinder, deck pivot, and swivel cylinders daily or at 8 hour...
Page 113
MAINTENANCE BELT TENSION ADJUSTMENT Locate the tensioning rod for the flail. Loosen the top tension adjustment nut. To tighten the belt, turn the bottom tension nut to compress the spring. To loosen the belt tension, turn the tension nut up to relax the spring.
Page 114
MAINTENANCE REVERSING MOWER ROTATION OF RSS FLAIL MOWERS To reverse the rotation of the Rear Side Stow flail, you need to switch the pressure and return motor hoses at the brake valve. Make sure the tractor is shut off and the ball valve is closed. Relieve the hydraulic pressure in the system first before removing any hoses.
Page 115
MAINTENANCE Blades Check the Blades for cracks and wear and Blade Bolts for tightness, daily. Blades should be replaced when they are worn excessively, bent, deformed, or out of balance. Blades should always be replaced in pairs. Blades of different weights can cause serious imbalance and damage to the machine and personnel.
Page 116
MAINTENANCE ROTARY KNIFE REPLACEMENT Be sure you have a complete matching set of new knives for replacement. Remove knives and inspect holes for damage. Also watch for cracks in the disk (if applicable) around the holes. Lube threads with anti-seize. Install bolts through knife and disk from bottom side of disk/blade bar. Install new self-locking nuts and torque them to 800 ft.
Page 117
MAINTENANCE Flail Blades Inspection Inspect the Blades daily for ab normal wear. REPLACE ALL BLADES on the carrier IMMEDIATELY if any blades have: • Become bent or deformed from its original shape, or • Wear inside the blade bolt hole, or •...
Page 118
MAINTENANCE Blade Pins and D-Ring Inspection Inspect Blade Pins and D-Rings daily for wear or damage as follows: Inspect the Blade pins and D-Rings daily for abnormal wear. Make sure the cotter pins are in place and properly spread. REPLACE BLADE Pins and D-Rings IMMEDIATELY if they have: •...
Page 119
MAINTENANCE BOOM FLAIL KNIFE REPLACEMENT If knives are damaged or badly worn, they will need to be replaced as a set. Replacing a single knife can cause severe vibration and possible damage to the mower. Assemble knives, clevis, bolts and nuts as shown in part section of manual. Install locking hex nut so that the flat face of nut is towards the knife.
Page 121
Position the spindle housing horizontally with the drain hole oriented “up”. Grease through the zerk with Tiger Spindle Lubricant (part number 06540000) until the grease purges from the drain hole. Install the plug into the drain hole. BEARING ADJUSTMENT...
Page 122
MAINTENANCE Boom Cylinder Removal and Replacement Instructions Clear the area of all personnel before lowering the boom mower head. From the tractor seat with your seat belt fastened around you, Lower the boom mower head to the ground. Extend the boom to the furthest reach and lower the mower head flat on the ground. DO NOT attempt to replace the cylinders with the boom in the raised or transport position.
Page 123
MAINTENANCE CUTTERSHAFT BEARING REPLACEMENT Remove existing cuttershaft, bearings and string guards. Make sure that the end knives on each end of the cuttershaft are oriented as shown. Apply anti-seize on cuttershaft as shown on next page. Before installation the bearings must be fully greased per the following protocol: 1.Add 2 or 3 pumps of grease, 2.
Page 125
MAINTENANCE GROUND ROLLER BEARING REPLACEMENT Remove existing ground roller brackets, bearings, and ground roller. Remove bearings from stub shafts and ground roller brackets. Clean stub shafts thoroughly, and apply anti-seize to O.D. of outer end. Before installation, bearings must be fully greased per the following protocol: 1.Add 2 or 3 pumps of grease, 2.
Page 126
MAINTENANCE DAILY MAINTENANCE SCHEDULE The following services should be performed daily or every 8 hours of service, following the detailed maintenance instructions in the operator’s manual. _______ Pump driveshaft: If required with drive shaft/coupler check for end play and lubricate at zerks. _______ Crankshaft adapter: If equipped with rubber grommets check condition, replace if missing or damaged.
Page 155
COMMON REAR STOW SIDE PARTS SECTION Common Section 6-1...
Page 156
PART NAME INDEX PARTS ORDERING GUIDE ..................................4 BOOM MOUNT KIT..................................... 5 NOTES 2........................................7 BOOM ASSEMBLY - FLAIL..................................8 BOOM ASSEMBLY - ROTARY................................10 60IN ROTARY MOWER.................................... 12 60IN ROTARY DISK AND KNIVES................................. 14 60IN BLADE BAR AND KNIVES................................16 NOTES.........................................
Page 157
PART NAME INDEX FIRE SUPPRESSION FRONT MOUNT..............................60 FIRE SUPPRESSION SYSTEM ELECTRICAL SCHEMATIC........................ 62 WETCUT........................................63 WETCUT 50 GALLON TANK - 3PNT MOUNT............................64 WETCUT 100 OR 150 GALLON TANK - 3PNT MOUNT........................65 WETCUT 3PNT PLUMBING - 50IN MOWERS............................66 WETCUT 3PNT PLUMBING - LARGE MOWERS..........................
Page 163
BOOM ASSEMBLY - FLAIL Continued... ITEM PART NO. QTY. DESCRIPTION ------ SWIVEL ASSY *REFER TO BOOM MOUNT KIT PAGE 6T3211 GREASE ZERK,1/8" 32321 BEARING 06500723 HOSE,1/4" X 52" 06500724 HOSE,1/4" X 70" ------ HOSE *REFER TO TRACTOR SPECIFIC PARTS ------ HOSE *REFER TO TRACTOR SPECIFIC PARTS 06505116 HOSE CLAMP...
Page 165
BOOM ASSEMBLY - ROTARY Continued... ITEM PART NO. QTY. DESCRIPTION ------ SWIVEL ASSY *REFER TO BOOM MOUNT KIT PAGE 6T3211 GREASE ZERK,1/8" 32321 BEARING 06500723 HOSE,1/4" X 52" 06500724 HOSE,1/4" X 70" ------ HOSE *REFER TO TRACTOR SPECIFIC PARTS ------ HOSE *REFER TO TRACTOR SPECIFIC PARTS 06505116 HOSE CLAMP...
Page 179
FLAIL DRIVE ASSEMBLY Continued... ITEM PART NO. QTY. DESCRIPTION ------ BONNET *REFER TO HEAD PARTS 32287 MOTOR CHANNEL 21700 HEX NUT,1/2",NF TF3620A SPRING,TENSIONER 27938 BUSHING,MACH,1"OD X 1/2"ID X 14GA. 40496 ROD,THREADED,1/2"NF X 8" PT3611A CLEVIS,6" 06504013 MOTOR TF3044 SHEAVE,8.0" TF3013 BUSHING,QD,SK 1-1/4",1/4"...
All Tiger obligation under this warranty shall be terminated if the equipment is modified or altered in ways not approved in writing by Tiger, if repair parts other than genuine Tiger repair parts have been used, or if the equipment has been subject to misuse, neglect, accident, improper maintenance or improper operation.
Page 236
. Common sense should play a large role in the operation of this machine. Since we at Tiger Corporation are constantly striving to improve out products, we reserve the right to change specifications or design at any time.
Page 237
TO THE OWNER / OPERATOR / DEALER To keep your implement running efficiently and safely, read your manual thoroughly and follow these directions and the Safety Messages in this manual and on the machine. The table of contents clearly identifies each section where you can easily find the information you need. The Occupational Safety and Health Act (OSHA 1928.51 subpart C) makes the following minimum requirements for tractor operators.
