Tiger WILDKAT JD61 M/R Series Manual

page of 258

/ 258
Bookmarks

Quick Links

Download this manual

PARTS LISTING WITH

MOUNTING AND OPERATING

INSTRUCTIONS

WILDKAT BOOM

INDEPENDENT HYDRAULICS

Current as of 03/30/2021

Tiger Corporation

3301 N. Louise Ave.

Sioux Falls, SD 57107

1-800-843-6849

1-605-336-7900

www.tigermowers.com

JD61xxM/R

WITH

06011055

Need help?

Do you have a question about the WILDKAT JD61 M/R Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Tiger WILDKAT JD61 M/R Series

Page 1 JD61xxM/R WILDKAT BOOM WITH INDEPENDENT HYDRAULICS Current as of 03/30/2021 PARTS LISTING WITH MOUNTING AND OPERATING INSTRUCTIONS Tiger Corporation 3301 N. Louise Ave. Sioux Falls, SD 57107 1-800-843-6849 1-605-336-7900 www.tigermowers.com 06011055...
Page 2 TO THE OWNER / OPERATOR / DEALER All implements with moving parts are potentially hazardous. There is no substitute for a cautious, safe-minded operator who recognizes the potential hazards and follows reasonable safety practices. The manufacturer has designed this implement to be used with all its safety equipment properly attached to minimize the chance of accidents.
Page 3 • Classify the problem • Hydraulic, electrical or mechanical - Read the trouble shooting section • Tractor or Truck chassis - Contact vehicle dealer • If unable to correct the problem yourself, contact your local Tiger Dealer after gathering: • Machine model _______________________ •...
Page 5: Table Of Contents
PARTS SECTION______________________________________ COMMON PARTS SECTION____________________________ WARRANTY INFORMATION_____________________________ This symbol means: CAUTION – YOUR SAFETY IS AT RISK! When you see this symbol, read and follow the associated instructions carefully or personal injury or damage may result. Tiger is a registered trademark.
Page 7: Safety Section
SAFETY SAFETY SECTION Bengal Boom Safety Section 1-1...
Page 8 SAFETY General Safety Instructions and Practices A safe and careful operator is the best operator. Safety is of primary importance to the manufacturer and should be to the owner / operator. Most accidents can be avoided by being aware of your equipment, your surroundings, and observing certain precautions. The first section of this manual includes a list of Safety Messages that, if followed, will help protect the operator and bystanders from injury or death.
Page 9 SAFETY PELIGRO! Si no lee Ingles, pida ayuda a alguien que LEA EL si lo lea para que le traduzca las medidas INSTRUCTIVO! de seguridad. (SG-3) Never operate the Tractor or Implement until you have read and DANGER! completely understand this Manual, the Tractor Operator’s Manual, and each of the Safety Messages found in the Manual or on the Tractor and Implement.
Page 10 SAFETY DANGER! Never allow children or other persons to ride on the Tractor or Implement. Falling off can result in serious injury or death. (SG-10) DANGER! Never allow children to operate or ride on the Tractor or Implement. (SG-11) WARNING! Do not mount the Tractor while the tractor is moving.
Page 11 SAFETY WARNING! The operator and all support personnel should wear hard hats, safety shoes, safety glasses, and proper hearing protection at all times for protection from injury including injury from items thrown by the equipment. (SG-16) CAUTION! PROLONGED EXPOSURE TO LOUD NOISE MAY CAUSE PERMA- NENT HEARING LOSS! Tractors with or without an Implement at- tached can often be noisy enough to cause permanent hearing loss.
Page 12 SAFETY WARNING! Never attempt to lubricate, adjust, or remove material from the Implement while it is in motion or while tractor engine is running. Make sure the tractor engine is off before working on the Implement. (SG-20) WARNING! Periodically inspect all moving parts for wear and replace when necessary with authorized service parts.
Page 13 SAFETY DANGER! NEVER use drugs or alcohol immediately before or while operating the Tractor and Implement. Drugs and alcohol will affect an operator’s alertness and coordination and therefore affect the operator’s ability to operate the equipment safely. Before operating the Tractor or Imple- ment, an operator on prescription or over-the-counter medication must consult a medical professional regarding any side effects of the medi- cation that would hinder their ability to operate the Equipment safely.
Page 14 SAFETY DANGER! The rotating parts of this machine have been designed and tested for rugged use. However, the blades could fail upon impact with heavy, solid objects such as metal guard rails and concrete structures. Such impact could cause the broken objects to be thrown outward at very high velocities.
Page 15 SAFETY WARNING! Do not mow with two machines in the same area except with Cab tractors with the windows closed. (SGM-11) Rotary and Flail Mowers are capable under adverse conditions of DANGER! throwing objects for great distances (100 yards or more) and causing serious injury or death.
Page 16 SAFETY Relieve hydraulic pressure prior to doing any maintenance or repair work on the Implement. Place the Mower Head on the ground or securely supported on blocks or stands, disengage the PTO, and turn off the engine. Push and pull the control Levers or Joystick several times to relieve pressure prior to starting any maintenance or repair work.
Page 17 These parts are made and tested to Tiger specifications. Non-genuine “will fit” parts do not consistently meet these specifications. The use of “will fit” parts may reduce mower performance, void mower warranties and present a safety hazard.
Page 18 SAFETY PART NO. LOCATION 002369 HYDRAULIC TANK 00725746 INSIDE OF CAB 00769737 MOWER DECK Bengal Boom Safety Section 1-12...
Page 19 SAFETY PART NO. LOCATION 00758194 MOWER DECK 02962764 MAIN BOOM, SECONDARY BOOM, MAIN FRAME 02962765 MAIN FRAME 02965262 HYDRAULIC TANK Bengal Boom Safety Section 1-13...
Page 20 SAFETY PART NO. LOCATION 02967668 MOWER DECK 02971123 HYDRAULIC TANK 03200285 OUTSIDE OF CAB 22645 INSIDE OF CAB 22839 MOWER DECK Bengal Boom Safety Section 1-14...
Page 21 SAFETY PART NO. LOCATION 22840 INSIDE OF CAB 24028 MOWER DECK 25387 INSIDE OF CAB 10” x 5.5” 31522 MOWER DECK, MAIN BOOM 18.25” x 10” 31523 HYDRAULIC TANK Bengal Boom Safety Section 1-15...
Page 22 SAFETY PART NO. LOCATION 27001 INSIDE OF CAB 31935 INSIDE OF CAB 32707 HYDRAULIC TANK 42350 MOWER DECK Bengal Boom Safety Section 1-16...
Page 23 SAFETY PART NO. LOCATION 32708 HYDRAULIC TANK 32709 INSIDE OF CAB 33224 MOWER DECK 33438 MAIN BOOM Bengal Boom Safety Section 1-17...
Page 24 SAFETY PART NO. LOCATION 33302 INSIDE OF CAB 33743 INSIDE OF CAB Bengal Boom Safety Section 1-18...
Page 25 SAFETY PART NO. LOCATION 42399 REFLECTIVE TAPE MOWER DECK AMBER 42400 REFLECTIVE TAPE MOWER DECK 6T3217 MOWER DECK 6T3219 INSIDE OF CAB 6T3220 FRONT PUMP MOUNT Bengal Boom Safety Section 1-19...
Page 26 SAFETY PART NO. LOCATION 6T3221 INSIDE OF CAB 6T3222 INSIDE OF CAB 6T3224 MOWER DECK 6T3225 INSIDE OF CAB Bengal Boom Safety Section 1-20...
Page 27 SAFETY PART NO. LOCATION 6T3230 INSIDE OF CAB 6T3231 INSIDE OF CAB 6T3233 HYDRAULIC TANK 6T3234 INSIDE OF CAB 6T3236 MOWER DECK Bengal Boom Safety Section 1-21...
Page 28 SAFETY PART NO. LOCATION 6T3237 INSIDE OF CAB 6T3241 INSIDE OF CAB 34206 INSIDE OF CAB 6T3243 INSIDE OF CAB 6T3249A MOWER DECK 6T3261 MOWER DECK Bengal Boom Safety Section 1-22...
Page 29 SAFETY TB1011 MOWER DECK 34852 HYDRAULIC TANK Bengal Boom Safety Section 1-23...
Page 30 SAFETY ITEM PART NO. QTY. DESCRIPTION 50023 AVAIL MANUAL CANISTER COMPLETE 00776031 ROUND MANUAL CANISTER 33997 DECAL, SHEET, MANUAL CANISTER DECAL DECAL DECAL AVAIL SPECIFIC PRODUCT MANUAL 33753 E M I SAFETY MANUAL 34296 FRONT ADHESIVE PAD 34297 REAR ADHESIVE PAD 6T1823 ZIP TIE 14”...
Page 31 SAFETY FEDERAL LAWS AND REGULATIONS This section is intended to explain in broad terms the concept and effect of federal laws and regulations concerning employer and employee equipment operators. This section is not intended as a legal interpretation of the law and should not be considered as such. Employer-Employee Operator Regulations U.S.
Page 32 SAFETY Bengal Boom Safety Section 1-26...
Page 33: Assembly / Mounting Section
JD6110-20M/R - WILDKAT T4F W/ INDEPENDENT HYDRAULICS ASSEMBLY SECTION Assembly Section 2-1...
Page 34 Always use a floor jack, hoist or fork lift to lift and raise heavy parts. Read and understand the entire Assembly Section instructions before attempting to mount your Tiger mower. Refer to the Parts Section of this manual for detailed illustrations to locate all parts.
Page 35 ASSEMBLY FRONT CRANKSHAFT PULLEY Tiger has found that the front crankshaft pulley used by John Deere will not allow for the installation of a front drive system. You will need to order a different pulley, washer and bolt from John Deere to allow for a front drive to be installed on your tractor.
Page 36 ASSEMBLY DRIVESHAFT AND FRONT PUMP MOUNTING Install spacer plate on tractor engine using bolts and lockwashers as shown in Parts Section. Grease sleeve section of the driveshaft and install from the side of the engine compartment. Once you have the sleeve section in place, bolt to spacer plate using bolts and lockwashers as shown in Parts Section.
Page 37 ASSEMBLY POLYCARBONATE SAFETY WINDOW NOTE: Installing a boom mower requires that all of the right side windows be replaced or protected with a polycarbonate window. This should be done before mounting the mainframe. 1. Disconnect gas shock at door. Remove the right side cab door/window glass from tractor cab by removing hinge pins.
Page 38 ASSEMBLY APPLICATION OF LOCTITE 2047 MOWER MAINFRAME MOUNTING BOLTS All mower mainframe mounting bolts shall be secured utilizing Loctite 2047 and torqued per the Torque Chart in the maintenance section. Shake bottle for 60 seconds before use. To prevent clogging of nozzle, do not allow tip to touch metal surfaces during application.
Page 39 This is necessary for the mainframe to be installed without damaging the tubes. Remove the John Deere part and replace it with the Tiger part using two provided bolts #06530005. After replacing the John Deere tube guide with the Tiger part, replace the exhaust heat shield.
Page 40 ASSEMBLY CONTINUOUS DUTY SOLENOID SWITCH The solenoid switch is mounted behind the battery on the right side of the tractor.(see photo below). Secure with hardware provided. (ASM-JD-0083d) . Route wires to and from the Continuous Duty Solenoid Switch as shown below. A.) ORANGE 10 GA.
Page 41 ASSEMBLY SWITCHBOX WIRING Power for the switchbox is accessed through the port located on the right rear of the cab. A John Deere plug is used, part number RE67651. DO NOT connect the plug to the cab port until the wiring is completed. The wires in the plug are colored RED, BLACK and ORANGE. IMPORTANT: The hot wire will be the RED wire or the ORANGE wire.
Page 42 ASSEMBLY CANBUS MODULE MOUNT Place the Canbus Controller mounting bracket (#06411524) on the floor of the cab, 4.5 inches from the right side console and 2.5 inches from the right side door. Drill a 3/8” hole through the floor and secure the bracket using a 3/8” bolt (#21637), spacer (#27082B) and 3/8” nylock nut (#21627).
Page 43 ASSEMBLY ELECTRONIC CANBUS LIFT VALVE (ASM-C-0089 rss) 6110-30M/R VALVE MOUNTING The mounting bracket for JD 6110-30M/R series tractors features two long legs which need to be attached as shown in the photo below. Secure the bracket to the tractor with hardware shown in the Parts Section of the manual.
Page 44 ASSEMBLY JOYSTICK SWITCHBOX MOUNTING Locate the two holes in the right front corner of the cab frame. These will be the mounting holes for the two mounting bolts of the switchbox bracket. See picture below. Mount the bracket using the hardware supplied, as noted in the Parts Section. (ASM-JD-0081) Assembly Section 2-12...
Page 45 ASSEMBLY JOYSTICK CONTROL MOUNTING Mounting the adjustable joystick control requires that the right armrest be modified and an additional bracket attached. The armrest must be removed by sliding off the plastic cover and removing the capscrew from the lower right side of the seat. This will leave the armrest loose so it can be removed.
Page 46 ASSEMBLY CANBUS BOOM JOYSTICK CONTROL This electronic control valve is equipped with high-resolution actuators on Boom, Side Shift, Deck Roll, and Boom Swivel functions. These actuators have active fault monitoring. The Deck Shield section does not have active fault monitoring. The joystick provides a signal to the Plus-1 Module and the Module provides a ratio-metric voltage signal.
Page 47 ASSEMBLY COOLER LOCATION The cooler mount and cooler are located on the left side of the tractor, and attached to the left hand cab framework. See the Parts Section for details. (ASM-JD6110M NEW SIDE COOLER Assembly Section 2-15...
Page 48 ASSEMBLY (ASM-C-0023) WHEEL WELL HYDRAULIC TANK INSTALLATION Install all fittings and tubes into tank and tank filter as shown in the Parts Section illustration. Insert tank sight glass onto the tractor side of the tank. Place the tank in the mounting bracket on the axle brace as shown in the Parts Section. Secure the tank with the hardware provided.
Page 49 ASSEMBLY FILLING HYDRAULIC RESERVOIR Refer to the Maintenance Section for filling specifications and hydraulic oil requirements. NOTE: Starting or running your Tiger mower before filling reservoir will cause serious damage to the hydraulic pump. (ASM-C-0004hydro resrv) INSTALLING O-RING FITTINGS Installing straight, 45º and 90º O-rings requires that the O-ring and washer be up against the swivel body.
Page 50 ASSEMBLY WHEEL WELL HOSE ROUTING Hoses travel along the right hand wheel well from the lift valve to the mainframe and boom. Hose clamps #06520536 are used to route the hoses as shown below. Clamps 1 and 2 (near the lift valve) use 1/4”...
Page 51 ASSEMBLY HOSE COVERING Secure hoses together with zip ties wherever loose. Wrap the hoses between the swivel and main boom with the hose cover provided. Wrap the hoses between the main boom and secondary boom with the hose cover provided. Where hoses may contact the frame or other edges, wrap with split hose and secure with hose clamps or zip ties.
Page 52 ASSEMBLY WHEEL WEIGHT MOUNTING For all tractors using a boom mower, a wheel weight will be required for the rear left side wheel. It will be necessary to mount the weight in the wheel using the long capscrews, lockwashers, flatwashers, spacers (if applicable), and hex nuts per the diagram in the Parts Section.
Page 53 ASSEMBLY REAR STOW SIDE SLIDE ASSEMBLY See the Slide Assembly page in the Common Parts Section for parts numbers and additional detail. (ASM-RSS SLIDE ASSEMBLY 2017) Assembly Section 2-21...
Page 54 ASSEMBLY MAIN BOOM INSTALLATION Using a hoist, install the boom swivel into the mainframe as shown in the Parts Section. Line up holes in swivel and mainframe for large swivel pin and insert pin. Secure with hardware as shown. Attach the inner end of the main boom to the swivel bracket with the cylinder anchors positioned upward, and at a right angle to the tractor.
Page 55 ASSEMBLY FINAL PREPARATION FOR OPERATION Place operator’s safety and operation decals on the steering column and side console where they are clearly visible to the operator. These decals should be understood by each operator of the machine in conjunction with the Safety and Operation Sections of this book. The decals are to be maintained in good condition as a reminder to the operator, and should be replaced if damaged.
Page 56 ASSEMBLY Assembly Section 2-24...
Page 58 TIGER BOOM MOWER OPERATING INSTRUCTIONS Tiger Booms are manufactured with quality material by skilled workers. The Boom is designed to attach to a tractor and operate various heads for a wide range of vegetative maintenance applications. The boom and heads are equipped with safety warning decals, protective deflectors, shields, and other safety features to provide operator and passerby protection, however, no shielding is 100% accurate.
Page 59 OPERATION 1.OPERATOR REQUIREMENTS Safe operation of the unit is the responsibility of a qualified operator. A qualified operator has read and understands the implement and tractor Operator’s Manuals and is experienced in implement and tractor operation and all associated safety practices. In addition to the safety messages contained in this manual, safety signs are affixed to the implement and tractor.
Page 60 OPERATION 2.TRACTOR REQUIREMENTS In addition to tractor horsepower and size required to operate the boom unit, the tractor must also be properly equipped to provide operator protection, to alert approaching vehicle drivers of the tractor’s presence, and to ensure tractor stability when mowing with the boom fully extended. Tractor Requirements and Capabilities •...
Page 61 OPERATION Never operate the Tractor and Mower Unit without an OPS (Operators Protective Structure) or Cab to prevent injury from objects thrown from ground or from overhead trimming. Stop mowing if workers or passersby are within 300 feet. (SBM-9) 2.3 Tractor Lighting and SMV Emblem If the tractor will be operated near or traveled on a public roadway it must be equipped with proper warning lighting and a Slow Moving Vehicle (SMV)
Page 62 OPERATION 2.4 Tractor Ballast To ensure tractor stability when operating on flat surfaces the left rear tractor tire MUST exert a minimum down force (weight) of 1500 lbs. on the ground when the tractor is on level ground, its boom is fully extended and the mower head is horizontal and two feet above the ground.
Page 63 OPERATION 3.1 Boarding the Tractor Use both hands and equipped handrails and steps for support when boarding the tractor. Never use control levers for support when mounting the tractor. Seat yourself in the operator’s seat and secure the seat belt around you.
Page 64 OPERATION 4.STARTING THE TRACTOR The operator must have a complete understanding of the placement, function, and operational use of all tractor controls before starting the tractor. Review the tractor operator’s manual and consult an authorized dealer for tractor operation instructions if needed. Essential Tractor Controls: •...
Page 65 OPERATION 5.CONNECTING ATTACHING HEADS TO THE BOOM 1. Start by attaching the pivot bracket(3) to the boom(1) using pin(5) and hardware. Next attach the cylinder to the pivot bracket(3) using pin(8) and roll pins. 2. Then attach the dogleg(4) to the mower(2) using pin(7) and hardware.
Page 66 OPERATION Periodically inspect all moving parts for wear and replace when necessary with authorized service parts. Look for loose fasteners, worn or broken parts, and leaky or loose fittings. Make sure all pins have attaching hardware. Serious injury may occur from not maintaining this machine in good working order.
Page 67 OPERATION 6.2 Boom Unit Pre-Operation Inspection and Service Inspect and service the boom arm and head prior to operation. Damaged and/or broken parts should be repaired and/or replaced immediately. To ensure the unit is ready for operation, conduct the following: OPS-B- 0020 Periodically inspect all moving parts for wear and replace when necessary with authorized service parts.
Page 68 OPERATION Relieve hydraulic pressure prior to doing any maintenance or repair work on the Implement. Place the Mower Head on the ground or securely supported on blocks or stands, disengage the PTO, and turn off the engine. Push and pull the control Levers or Joystick several times to relieve pressure prior to starting any maintenance or repair work.
Page 69 OPERATION Do not operate this Equipment with hydraulic oil or fuel leaking. Oil and fuel are explosive and their presence could present a hazard. Do not check for leaks with your hand! High-pressure oil streams from breaks in the line could penetrate the skin and cause tissue damage including gangrene.
Page 70 OPERATION ROTARY HEAD INSPECTION • Inspect blades and blade bolts for looseness and excessive wear. Rotate to 90° to make for checking easier. Replace damaged, worn, and missing blades as complete sets to maintain rotary balance. • Ensure motor bolts and nuts are tightened to the appropriate torque.
Page 71 OPERATION FLAIL HEAD INSPECTION • Inspect blades and blade bolts for looseness and excessive wear. Rotate to 90° to make for checking easier. Replace damaged, worn, and missing blades as complete sets to maintain cuttershaft balance. • Ensure rubber deflectors are in position and not damaged.
Page 72 OPERATION 6.3 Cutting Component Inspection Inspect blade pan and blade assembly for the following: OPS-U-0031 Inspect the Blades daily for abnormal wear. REPLACE BOTH BLADES on that carrier IMMEDIATELY if either blade has: • Become bent or deformed from it’s original shape or •...
Page 73 OPERATION Tractor PRE-OPERATION Inspection Mower ID#________________ Make ____________________ Date: ________________ Shift ____________________ Before conducting the inspection, make sure the tractor engine is off, all rotation has stopped and the tractor is in park with the parking brake engaged. Make sure the mower is resting on the ground or securely blocked up and all hydraulic pressure has been relieved.
Page 74 OPERATION Boom PRE-OPERATION Inspection Mower ID#________________ Make ____________________ Date: ________________ Shift ____________________ Before conducting the inspection, make sure the tractor engine is off, all rotation has stopped and the tractor is in park with the parking brake engaged. Make sure the mower is resting on the ground or securely blocked up and all hydraulic pressure has been relieved.
Page 75 A control lever decal similar to the one shown below should be near the control valve to remind the operator of the lever functions. The main control valve on the Tiger Boom Mower has four sections with tapered spools, located near the right side of the steering wheel.
Page 76 OPERATION 6.4 Switchbox The Safety Shield lever opens and closes the shield located on the front of the cutter head. When moving at or near the ground, always have the shield in th closed position. When mowing in the brush or in trees above ground level the shield may be opened for easier cutting.
Page 77 OPERATION LEVER #1 MAIN BOOM LEVER #2 SECONDARY BOOM LEVER #3 DECK ROLL Boom Operation Section 3-21 ©2013 Alamo Group Inc.
Page 79 Install the manual valve handle onto valve and operate the functions individually to stow boom. After boom is stowed in rest, transport the unit to the maintenance facility and contact your Tiger dealer for assistance. DO NOT attempt to operate the valve manually for mowing operations! Note: Pushing manual valve handles “out”...
Page 80 OPERATION 7.1 Switch Box and Joystick Control The diagrams below and on the next page show the functions that are performed through the use of the joystick controller. The Safety Shield switch opens and closes the shield located on the front of the cutter head. When moving at or near the ground, always have the shield in the closed position.
Page 82 OPERATION JOYSTICK LEFT/RIGHT MOVES SECONDARY BOOM LEFT JOYSTICK ROLLER MOVES DECK ROLL RIGHT JOYSTICK ROLLER MOVES BOOM SWIVEL Boom Operation Section 3-26 ©2013 Alamo Group Inc.
Page 83 OPERATION RIGHT JOYSTICK ROLLER WHILE PRESSING BUTTON MOVES BOOM KNUCKLE ON A LEGAL REAR STOW BOOM SHIELD SWITCH(on switch box) OPERATES SAFETY SHIELD 8.DRIVING THE TRACTOR AND IMPLEMENT Safe tractor transport requires the operator to possess a thorough knowledge of the model being operated and precautions to take while driving with an attached implement.
Page 84 OPERATION Never operate the Tractor or Implement until you have read and completely understand this Manual, the Tractor Operator’s Manual, and each of the Safety Messages found in the Manual or on the Tractor and Implement. Learn how to stop the tractor engine suddenly in an emergency.
Page 85 OPERATION Transport only at speeds where you can maintain control of the equipment. Serious accidents and injuries can result from operating this equipment at high speeds. Understand the Tractor and Implement and how it handles before transporting on streets and highways. Make sure the Tractor steering and brakes are in good condition and operate properly.
Page 86 OPERATION 8.2 Brake and Differential Lock Setting Make sure the tractor brakes are in good operating condition. Tractor brakes can be set to operate independently allowing single rear wheel braking action or locked together to provide simultaneous rear wheel braking. FOR MOST DRIVING AND OPERATING CONDITIONS, THE BRAKE PEDALS SHOULD BE LOCKED TOGETHER TO PROVIDE THE MOST EFFECTIVE BRAKING ACTION.
Page 87 OPERATION 8.3 Driving the Tractor and Boom Start off driving at a slow speed and gradually increase your speed while maintaining complete control of the tractor. Never operate the tractor at speeds that cannot be safely handled or which will prevent the operator from stopping quickly during an emergency.
Page 88 OPERATION Never Leave the mower unattended while the head is in the raised position. The mower could fall causing serious injury to anyone who might inadvertently be under the mower . (SBM-4) Always keep a careful lookout and use extreme care when working around overhead obstructions.
Page 89 OPERATION Avoid mowing in reverse direction when possible. Check to make sure there are no persons behind the mower and use extreme care when mowing in reverse. Mow only at a slow ground speed where you can safely operate and control the tractor and mower. Never mow an area that you have not inspected and removed debris or foreign material.
Page 90 OPERATION Mow at the speed that you can safely operate and control the tractor and mower. The correct mowing speed depends on terrain condition and grass type, density, and height of cut. Normal ground speed range is from 2 to 5 mph(3-8 kph). Use slow mowing speeds when operating on or near steep slopes, ditches, drop-offs, overhead obstructions, power lines, or when debris and foreign objects are to be avoided.
Page 91 OPERATION 9.4 Mower Operation The rotating parts in this machine have been designed and tested for rugged use. However, they could fail upon impact with heavy solid objects-such as steel guard rails, concrete abutments,etc., causing them to be thrown at a very high velocity. Never allow cutter head to contact such objects. Inspecting the cutting area for such objects and removing them prior to mowing can help eliminate these potiential hazards.
Page 92 OPERATION For cutting brush, it is usually best to stop the tractor and swivel the boom and mower into foilage. The horizontal positioning action of the boom is designed to position the cutting head and provide a limited pressure relief when excessive pressure is applied to the boom. DO NOT use excessive force when positioning cutting head into heavy branches or stumps.
Page 93 OPERATION When cutting trees and brush approach material to be cut with the head perpendicular to material. The cutting edge of the blades should be the only elements in contact with material. The blade bar should not contact with material. The mower head blades should...
Page 94 OPERATION Do not allow knives to cut down to the ground. Position ground roller to maintain knife arc at a minimum of 2 inches above the ground. Knife contact or lug contact with ground will cause permanent damage to cutter shaft, knives, and knife attachment parts. 9.7 63”...
Page 95 OPERATION 9.8 Shutting Down the Attached Head- For Standard Equipment To shut down attached mower head, first bring the tractor to a complete stop. Decrease engine RPM to idle then disengage cutterhead. The mower head will come to a complete stop within a suitable amount of time.
Page 96 OPERATION 10.TRACTOR, BOOM, AND ATTACHED HEAD STORAGE Properly preparing and storing the unit at the end of the season is critical to maintaining its appearance and to help ensure years of dependable service. The following are suggested storage procedures: • Thoroughly clean all debris from boom and head to prevent damage from rotting grass and standing water.
Page 97 OPERATION 11.1 Placing Boom Arm on Boom Arm Rest - For Standard Equipment Before transporting tractor between locations, idle the tractor engine, disengage the attached head, and wait for all head motion to come to a complete stop. Place the boom in its storage cradle rest support and then turn the joystick master switch to the OFF position.
Page 98 OPERATION 11.2 Transporting on Public Roadways Extreme caution should be used when transporting the tractor and mower on public roadways. The tractor must be equipped with all required safety warning features including a SMV emblem and flashing warning lights to alert drivers of the tractor’s presence. Remember that roadways are primarily designed for automotive drivers and most drivers will not be looking out for you, therefore, you must look out for them.
Page 99 OPERATION When operating public roads, have consideration for other road users. Pull to the side of the road occasionally to allow all following traffic to pass. Do not exceed the legal speed limit set in your state or municipality for agricultural tractors. Always stay alert when transporting the tractor and mower on public roads.
Page 100 OPERATION 11.3 Hauling the Tractor and Implement Before transporting a loaded tractor and implement, measure the height and width dimensions and gross weight of the complete loaded unit. Ensure that the load will be in compliance with the legal limits set for the areas that will be traveled through.
Page 101 The tractor and the mower head should now be chained down securely to the trailer bed. If any part of this operating section, or any other section of this manual is not completely understood, contact your Tiger dealer or the address on the cover of this manual for assistance! Boom Operation Section 3-45 ©2013 Alamo Group Inc.
Page 104 Regular maintenance at the intervals mentioned will result in the maximum efficency and long life of the Tiger Mower. When you purchase a Tiger Mower you also acquire another valuable asset, Tiger’s parts organization. Our rapid and efficent service has guaranteed the customer satisfaction for many years.
Page 105 MAINTENANCE Relieve hydraulic pressure prior to doing any maintenance or repair work on the Implement. Place the Mower Head on the ground or securely supported on blocks or stands, disengage the PTO, and turn off the engine. Push and pull the control Levers or Joystick several times to relieve pressure prior to starting any maintenance or repair work.
Page 106 MAINTENANCE Regular Maintenance The intervals at which regular servicing should be done are based on hours of operation. Use the tractors hour meter to determine when regular servicing is required. Refer to the Det ailed Maintenance section for futher instructions on greasing. Copy and use the Daily Maintenance sheet located at the end of this section.
Page 107 MAINTENANCE WEEKLY OR EVERY 40 HOURS ITEM SERVICE COMMENTS Rotary Spindle Lubricate Every 40 hours or weekly WEEKLY OR EVERY 50 HOURS ITEM SERVICE COMMENTS In Tank Hyd. Fluid Change Change after first 50 Filter hours only, then every 500 hours or yearly 10 micron filter) In-Line High Pressure Change...
Page 108 MAINTENANCE TROUBLESHOOTING SYMPTOMS CAUSE REMEDY 1. Loose Bolts 1. Check all bolts and tighten to Vibration recommended torque specs. 2. Cutter assembly 2a. Check for damage blades, disc Unbalanced or cutter shaft. Replace if needed. 2b. Check for wire, rope, etc. entangled in the cutter assembly 1.
Page 109 MAINTENANCE TROUBLESHOOTING (CONTINUED) SYMPTOMS CAUSE REMEDY 1. Belts Inspect belts and pulleys. Replace Motor runs but belts and repair as needed. will not cut. 2. Tensioner Adjust tensioner nuts tension should be 106 freq cyl/sec. 1. Contaminants Remove large nut on side of large Mower turns slowly restricting spool valve block.
Page 111 Deck Boom Pivot & Grease Lithium Complex Mobilgrease CM-S Deck Stop Adjustment Gun Extreme Pressure Rotary & Flail) NLGI-ISO 320 Deck Spindle(Rotary) Grease Tiger Spindle Lubricant Mobilith SHC 220 part number 06540000 WildKat Maintenance Section 4-9 ©2021 Alamo Group Inc.
Page 112 MAINTENANCE GRAFFITI REMOVAL Butyl cellosolve (for removal of paints, marking pen inks, lipstick, etc.) The use of masking tape, adhesive tape or lint removal tools work well for lifting off old weathered paints. To remove labels, stickers, etc., the use of kerosene or VM&P na phtha are generally effective. When the solvent will not penetrate sticker material, apply heat (hair dryer) to soften the adhesive and promote removal.
Page 113 MAINTENANCE DETAILED MAINTENANCE REPLACING HIGH PRESSURE HYDRAULIC FILTER ELEMENT: Ensure the system has been shut down and de- pressurized. Locate High Pressure Filter housing. Confirm that the element that is a bout to be installed matches the element p/n on the filter model tag.
Page 114 MAINTENANCE GREASING GROUND ROLLER SHAFT-FLAIL Locate grease zerks on eack end of roller tube at lower end of head. Normal conditions require one or two pumps in each bearing, using Lithium-Complex Extreme Pressure grease conforming to NLGI2-ISO 320 specifications. This is to be do ne with a standard grease gun daily or at 8 hour intervals.
Page 115 Inject Lithium-Complex Extreme Pressure grease conforming to NLGI2-ISO 320 specifications until grease begins to protrude from ends. GREASING SPINDLE Locate grease fitting o n inside of deck hou sing. Inject Tiger Spindle Lubricant, part number 06540000 into s pindle housing. Fill with lubricant until lubricant weeps out of to p spindle seal.
Page 116 MAINTENANCE TIGHTENING SPINDLE BOLTS The spindle mounting bolts should be checked and retorqued daily or every 8 hours of service. Torque the (6) bolts shown below to 357 dry or 315 ft. lbs. lubricated. GREASING PUMP DRIVE SHAFT COUPLER With engine stopped, ensure drive shaft alignment by grasping coupler and sliding back and forth.
Page 117 MAINTENANCE DRIVE SHAFT YOKE, U-JOINT STUB SHAFT WIth engine stopped, inject Lithium-Complex extreme pressure grease confirming to NLGI2-ISO 320 specifications into universal joints and slip yoke until grease appears at the seal. Grease them daily or every 8 hours. GREASING THE BOOM SWIVEL Locate the zerks on the main swivel boss (if applicable), main boom pivot boss (if ap plicable) and on both ends of th e boom swivel cyl inder.
Page 118 MAINTENANCE GREASING BOOM CYLINDER(S) PIVOT POINTS Locate the zerk on the butt end tang of cylinder and on rod end tang. Inject Lithium-Complex Extreme Pressure grease confirming to NLGI2- ISO 320 specifications until grease begins to protrude from ends. This procedure is to be used on the main boom cylinder, secondary boom cylinder, deck pivot, and swivel cylinders daily or at 8 hour...
Page 119 MAINTENANCE BELT TENSION ADJUSTMENT Locate the tensioning rod for the flail. Loosen the top tension adjustment nut. To tighten the belt, turn the bottom tension nut to compress the spring. To loosen the belt tension, turn the tension nut up to relax the spring.
Page 120 MAINTENANCE REVERSING MOWER ROTATION OF RSS FLAIL MOWERS To reverse the rotation of the Rear Side Stow flail, you need to switch the pressure and return motor hoses at the brake valve. Make sure the tractor is shut off and the ball valve is closed. Relieve the hydraulic pressure in the system first before removing any hoses.
Page 121 MAINTENANCE Blades Check the Blades for cracks and wear and Blade Bolts for tightness, daily. Blades should be replaced when they are worn excessively, bent, deformed, or out of balance. Blades should always be replaced in pairs. Blades of different weights can cause serious imbalance and damage to the machine and personnel.
Page 122 MAINTENANCE ROTARY KNIFE REPLACEMENT Be sure you have a complete matching set of new knives for replacement. Remove knives and inspect holes for damage. Also watch for cracks in the disk (if applicable) around the holes. Lube threads with anti-seize. Install bolts through knife and disk from bottom side of disk/blade bar. Install new self-locking nuts and torque them to 800 ft.
Page 123 MAINTENANCE Flail Blades Inspection Inspect the Blades daily for ab normal wear. REPLACE ALL BLADES on the carrier IMMEDIATELY if any blades have: • Become bent or deformed from its original shape, or • Wear inside the blade bolt hole, or •...
Page 124 MAINTENANCE Blade Pins and D-Ring Inspection Inspect Blade Pins and D-Rings daily for wear or damage as follows: Inspect the Blade pins and D-Rings daily for abnormal wear. Make sure the cotter pins are in place and properly spread. REPLACE BLADE Pins and D-Rings IMMEDIATELY if they have: •...
Page 125 MAINTENANCE BOOM FLAIL KNIFE REPLACEMENT If knives are damaged or badly worn, they will need to be replaced as a set. Replacing a single knife can cause severe vibration and possible damage to the mower. Assemble knives, clevis, bolts and nuts as shown in part section of manual. Install locking hex nut so that the flat face of nut is towards the knife.
Page 126 MAINTENANCE THE SPINDLE ASSEMBLY See the diagram below for identification of spindle parts, while servicing. WildKat Maintenance Section 4-24 ©2021 Alamo Group Inc.
Page 127 Position the spindle housing horizontally with the drain hole oriented “up”. Grease through the zerk with Tiger Spindle Lubricant (part number 06540000) until the grease purges from the drain hole. Install the plug into the drain hole. BEARING ADJUSTMENT...
Page 128 MAINTENANCE Boom Cylinder Removal and Replacement Instructions Clear the area of all personnel before lowering the boom mower head. From the tractor seat with your seat belt fastened around you, Lower the boom mower head to the ground. Extend the boom to the furthest reach and lower the mower head flat on the ground. DO NOT attempt to replace the cylinders with the boom in the raised or transport position.
Page 129 MAINTENANCE CUTTERSHAFT BEARING REPLACEMENT Remove existing cuttershaft, bearings and string guards. Make sure that the end knives on each end of the cuttershaft are oriented as shown. Apply anti-seize on cuttershaft as shown on next page. Before installation the bearings must be fully greased per the following protocol: 1.Add 2 or 3 pumps of grease, 2.
Page 131 MAINTENANCE GROUND ROLLER BEARING REPLACEMENT Remove existing ground roller brackets, bearings, and ground roller. Remove bearings from stub shafts and ground roller brackets. Clean stub shafts thoroughly, and apply anti-seize to O.D. of outer end. Before installation, bearings must be fully greased per the following protocol: 1.Add 2 or 3 pumps of grease, 2.
Page 132 MAINTENANCE DAILY MAINTENANCE SCHEDULE The following services should be performed daily or every 8 hours of service, following the detailed maintenance instructions in the operator’s manual. _______ Pump driveshaft: If required with drive shaft/coupler check for end play and lubricate at zerks. _______ Crankshaft adapter: If equipped with rubber grommets check condition, replace if missing or damaged.
Page 133: Parts Section
JD61xxM/R WILDKAT BOOM w/ INDEPENDENT HYDRAULICS PARTS SECTION...
Page 134 PART NAME INDEX PARTS ORDERING GUIDE ..................................3 TRACTOR MOUNT KIT....................................4 TRACTOR MOUNT KIT - HYDRAULICS..............................6 BOOM MOUNT KIT..................................... 8 COOLER MOUNT...................................... 10 LIFT VALVE MOUNT....................................12 ELECTRONIC PROPORTIONAL LIFT VALVE............................14 JOYSTICK AND SWITCHBOX MOUNT..............................16 CANBUS JOYSTICK CONTROL................................18 CANBUS ELECTRONIC LIFT VALVE SWITCHBOX...........................
Page 137 TRACTOR MOUNT KIT Continued... ITEM PART NO. QTY. DESCRIPTION 06300383 MAINFRAME MOUNT, JD6110M, T4F 06402946 RISER, LH, 06300383 33880 FLATWASHER, 3/4" GR8, SAE 06530237 CAPSCREW, 3/4" X 2-1/4" NC GR8 06531008 HEX NUT, 3/4" NC, GR8 31731 CAPSCREW, 20MM X 50MM (2.5 PITCH) 06300384 AXLE BRACE, RH, JD6110M, T4F, RS 06300386...
Page 139 TRACTOR MOUNT KIT - HYDRAULICS Continued... ITEM PART NO. QTY. DESCRIPTION 06700220 TANK, HYDRAULIC, WHEEL WELL 34309 BALL VALVE, 1-1/2"FOR 06503083 ADAPTER, 1/2"ORB X 1-1/2"ORB 06503084 ELBOW, 1-1/2"FB X 1-1/2"FB 34710 ADAPTER, 1-1/2ORB X 1-1/2MJ 06500743 HOSE, 1-1/2" X 110" 32382 BRACKET, HOSE 24849...
Page 141 BOOM MOUNT KIT Continued... ITEM PART NO. QTY. DESCRIPTION ------ MAINFRAME *REFER TO TRACTOR MOUNT KIT 21782 CAPSCREW,5/8" X 1-3/4",NC 21777 NYLOCK NUT,5/8",NC 32381 PIN,CAPPED 32322 BUSHING 06505185 CLAMP KIT 6T3211 GREASE ZERK,1/8"NPT 21677 NYLOCK NUT,7/16",NC 32380 PIN,1" 21683 CAPSCREW,7/16" X 2",NC TB1023 ROLL PIN 06420100...
Page 143 COOLER MOUNT Continued... ITEM PART NO. QTY. DESCRIPTION 06380108 MOUNT, COOLER, LH, JD6M.19 06380117 MOUNT, CAB, COOLER, JD6M 06510351 COOLER, ADAMS, OPTIMUM 06380118 GUARD, FAN, COOLER, JD6M 21729 CAPSCREW, 1/2" X 1" NC 21629 CAPSCREW, 3/8" X 3/4" NC 34948 FLATWASHER, 3/8"...
Page 145 LIFT VALVE MOUNT Continued... ITEM PART NO. QTY. DESCRIPTION 06502203 VALVE, 5SP, DF, CANBUS, EFS, T4F 06340063 PLATE, VALVE, 6110-30, T4F 21987 LOCKWASHER, 5/16" 21579 CAPSCREW, 5/16" X 3/4" NC 24860 CAPSCREW, 20MM X 40MM 33880 FLATWASHER, 3/4" JD61xxM-R WILDKAT w IH ©2021 Alamo Group Inc.
Page 147 ELECTRONIC PROPORTIONAL LIFT VALVE Continued... ITEM PART NO. QTY. DESCRIPTION 06700230 ELECTRONIC VALVE, DF, CNBS, EFS 32807 ADAPTER,5/8”MB X 3/8”MJ 06503199 ELBOW, 12MJ X 12FJX, BT90 33271 ADAPTER, 1/2" MOR X 3/8" MJ 0503023 ADAPTER, 3/4" MB X 3/4"MJ 06501357 HOSE, 3/8"...
Page 149 JOYSTICK AND SWITCHBOX MOUNT Continued... ITEM PART NO. QTY. DESCRIPTION 06510285 JOYSTICK, 4AXIS, RH, DF, W/SUBD 06411652 MOUNT, JOYSTICK ARM, JD6M 06403098 RING, JOYSTICK, 06340058 32829 SCREW, MACHINE, 10-32X3/4, FLTHD 06340007 MOUNT, JOYSTICK BASE, JD6M 06537060 CARRIAGE BOLT, 1/4X3/4, NC 94902A101 HEX NUT, 1/4 NC, FLNG, GR8 21737...
Page 151 CANBUS JOYSTICK CONTROL Continued... ITEM PART NO. QTY. DESCRIPTION 06510286 SWITCHBOX, DF, RSS, CNBS 06510285 JOYSTICK, RH, DF, CNBS 06510083 BRAKE VALVE, SOL, 3000PSI 06510315 CONTROLLER, SWBX, CNBS, EFS 06700230 VALVE, 5SPL, DF, CNBS, OC, EFS 06510313 ADAPTER HARNESS JD61xxM-R WILDKAT w IH ©2021 Alamo Group Inc.
Page 152 CANBUS ELECTRONIC LIFT VALVE SWITCHBOX ITEM PART NO. QTY. DESCRIPTION 06510286 SWITCHBOX ASSEMBLY 06502171 SWITCH, MASTER, TRAVEL LOCK 06502172 INDICATOR LIGHT, FLOAT, GREEN 06502170 SWITCH, SHIELD 34540 STRAIN RELIEF, 3/4" BLACK 06502174 INDICATOR LIGHT, ON, RED 06502169 CIRCUIT BREAKER, 15A 06550044 LABEL, SWBX 35226...
Page 155 CANBUS LIFT VALVE BREAKDOWN - 06502207 Continued... ITEM PART NO. QTY. DESCRIPTION 34308 END PLATE, PVP, DANFOSS, 32 PVG 42698 VALVE SECTION, PVG 32 06502076 VALVE SECTION, PVG, 32, ROLL 06502077 VALVE SECTION, PVG 32, SHIELD 42202 KIT, TIE ROD, 5 SECTION, PVG, 32 42697 VALVE, SPOOL, 10.6 GPM, PVG 32 06502178...
Page 156 POLYCARBONATE SAFETY WINDOW ITEM PART NO. QTY. DESCRIPTION 31965 TRIM SEAL,3/8" CLIP X 3/4"OD (FEET) 27508 CAPSCREW,8MM X 20MM,1.25P 22015 FLATWASHER,5/16" 21581 CAPSCREW,5/16" X 1-1/4",NC 06490005 POLYCARB,FRMD,DOOR,RH 06490027 POLYCARB,FRMD,REAR,RH 06520040 BRKT,JD,POLY,RETAIN 6T2619 LOCKWASHER,8MM 21577 NYLOCK NUT,5/16",NC JD61xxM-R WILDKAT w IH ©2021 Alamo Group Inc.
Page 159 BOOMREST Continued... ITEM PART NO. QTY. DESCRIPTION 06310157 BOOMREST 06310116 SADDLE 21733 CAPSCREW, 1/2" X 2" NC 06533004 FLATWASHER, 1/2" SAE 21725 HEX NUT, 1/2" NC 21782 CAPSCREW, 5/8" X 1-3/4" NC 33764 FLATWASHER, 5/8" SAE 21775 HEX NUT, 5/8" NC JD61xxM-R WILDKAT w IH ©2021 Alamo Group Inc.
Page 160 WHEEL WEIGHT - 500 LBS ITEM PART NO. QTY. DESCRIPTION 31455 CAPSCREW, 3/4" X 17" NC 33880 FLATWASHER, 3/4" SAE 06770057 WHEEL WEIGHT, 500LBS 06430143 SPACER, 5.5" 21825 HEX NUT, 3/4" NC JD61xxM-R WILDKAT w IH ©2021 Alamo Group Inc. Parts Section -28...
Page 161 WHEEL WEIGHT - 1700 LBS ITEM PART NO. QTY. DESCRIPTION 06530213 CAPSCREW, 7/8" X 16" NC, GR8, 3"THRD 06533000 FLATWASHER, 7/8" GR8 32517 WHEEL WEIGHT 1700# 06400410 SPACER 06531000 HEX NUT, 7/8" NC, GR8 JD61xxM-R WILDKAT w IH ©2021 Alamo Group Inc. Parts Section -29...
Page 163 75IN SIDE FLAIL - STANDARD ROTATION Continued... ITEM PART NO. QTY. DESCRIPTION 28736D BONNET,75",STD,T3F,RT 28737 BAFFLE,75",STD ROT-STD 6T2283 CARRIAGE BOLT,3/8" X 1",NC 6T2615 WASHER,FENDER,3/8" 21988 LOCKWASHER,3/8" 21625 HEX NUT,3/8",NC 27975A GUARD,CUTTERSHAFT 21731 CAPSCREW,1/2" X 1-1/2",NC 21990 LOCKWASHER,1/2" 21725 HEX NUT,1/2",NC 28735 GROUND ROLLER ADJ BRKT,STD DTY 06520028...
Page 165 75IN SIDE FLAIL - REVERSE ROTATION Continued... ITEM PART NO. QTY. DESCRIPTION 28736D BONNET,75,STD,T3F,RT 28968A TRASH GUARD,75" 6T2283 CARRIAGE BOLT,3/8" X 1",NC 6T2615 WASHER,FENDER,3/8" 21988 LOCKWASHER,3/8" 21625 HEX NUT,3/8",NC 27975A GUARD,CUTTERSHAFT 21731 CAPSCREW,1/2" X 1-1/2",NC 21990 LOCKWASHER,1/2" 21725 HEX NUT,1/2",NC 28735 GROUND ROLLER ADJ BRKT,STD DTY 06520028...
Page 166 102IN REAR FLAIL - STANDARD ROTATION ITEM PART NO. QTY. DESCRIPTION 22046J BONNET,102",HD 21732 CAPSCREW,1/2" X 1-3/4",NC 21990 LOCKWASHER,1/2" TF4335 ROD,GROUND ROLLER ADJ,LF JD61xxM-R WILDKAT w IH ©2021 Alamo Group Inc. Parts Section -34...
Page 167 102IN REAR FLAIL - STANDARD ROTATION Continued... ITEM PART NO. QTY. DESCRIPTION 21725 HEX NUT,1/2",NC 21632 CAPSCREW,3/8" X 1-1/2",NC 22016 FLATWASHER,3/8" TF1703 BAR,FLAP,TSF/TRF,102" TF1704A FLAP,DEFLECTOR,TSF/TRF,102" 21625 HEX NUT,3/8",NC 21988 LOCKWASHER,3/8" 6T2615 WASHER,FENDER,3/8" TF4334 ROD,GROUND ROLLER ADJ,RT 21731 CAPSCREW,1/2" X 1-1/2",NC TF1040 GUARD,CUTTERSHAFT 21399...
Page 168 102IN REAR FLAIL - REVERSE ROTATION ITEM PART NO. QTY. DESCRIPTION 22046J BONNET,102",HD 21732 CAPSCREW,1/2" X 1-3/4",NC 21990 LOCKWASHER,1/2" TF4335 ROD,GROUND ROLLER ADJ,LF JD61xxM-R WILDKAT w IH ©2021 Alamo Group Inc. Parts Section -36...
Page 169 102IN REAR FLAIL - REVERSE ROTATION Continued... ITEM PART NO. QTY. DESCRIPTION 21725 HEX NUT,1/2",NC 21632 CAPSCREW,3/8" X 1-1/2",NC 22016 FLATWASHER,3/8" TF1703 BAR,FLAP,TSF/TRF,102" TF1704A FLAP,DEFLECTOR,TSF/TRF,102" 21625 HEX NUT,3/8",NC TF4334 ROD,GROUND ROLLER ADJ,RT 21731 CAPSCREW,1/2" X 1-1/2",NC TF1040 GUARD,CUTTERSHAFT 21399 HEX NUT,3/4",ACME THRD TF4333A GROUND ROLLER ADJ BRKT 6T2294...
Page 170 102IN REAR FLAIL DRIVE ASSEMBLY ITEM PART NO. QTY. DESCRIPTION 22046J BONNET,102",HD 31279A HITCH,3-POINT 40454 SPACER 27508 CAPSCREW,8MM X 20MM(1.25) 6T2619 LOCKWASHER,8MM 28447E GUARD,OUTPUT SHAFT 28505 GEARBOX,REAR FLAIL,COMER T22A 06520181 GUARD,PTO,GRBX 34948 FLATWASHER,8MM 27507 CAPSCREW,8MM X 15MM(1.25) 28914 COUPLING,6 SPLINE 6T3209 GREASE ZERK,1/4"...
Page 171 102IN REAR FLAIL DRIVE ASSEMBLY Continued... ITEM PART NO. QTY. DESCRIPTION 28417B OUTPUT EXTENSION SHAFT,102"R6F ---- 28419B OUTPUT EXTENSION SHAFT,102"OFF 30162 CAPSCREW,SKT HD,8MM X 20MM(1.25) 28429A SHAFT GRD,HD,102"RCM 28425B SHAFT GRD,HD,102"R6F ---- 28427B SHAFT GRD,HD,102"ROFF 21725 HEX NUT,1/2",NC 21990 LOCKWASHER,1/2" 22018 FLATWASHER,1/2",WIDE 21732...
Page 172 3IN X 10IN HYDRAULIC CYLINDER BREAKDOWN ITEM PART NO. QTY. DESCRIPTION ------ 6T0151R HYD. CYLINDER 3" X 10" 6T0167 CYLINDER BUTT 6T0170 CYLINDER GLAND 6T0178 CLEVIS END 6T0164 CYLINDER TUBE 6T0161 PISTON ROD 6T0173 PISTON 6T0179 LOCKNUT 6T0176 TIE ROD ASY ------ 6T0187 SEAL KIT...
Page 173 3IN X 12IN HYDRAULIC CYLINDER BREAKDOWN ITEM PART NO. QTY. DESCRIPTION ------ 32215 HYD. CYLINDER 3" X 12" 6T0167 CYLINDER BUTT 6T0170 CYLINDER GLAND 6T0178 CLEVIS END 6T0204 CYLINDER TUBE 6T0203 PISTON ROD 6T0173 PISTON 6T0179 LOCKNUT 6T0205 TIE ROD ASY ------ 6T0187 SEAL KIT...
Page 175 COMMON REAR STOW SIDE PARTS SECTION Common Section 6-1...
Page 176 PART NAME INDEX PARTS ORDERING GUIDE ..................................4 BOOM MOUNT KIT..................................... 5 NOTES 2........................................7 BOOM ASSEMBLY - FLAIL..................................8 BOOM ASSEMBLY - ROTARY................................10 60IN ROTARY MOWER.................................... 12 60IN ROTARY DISK AND KNIVES................................. 14 60IN BLADE BAR AND KNIVES................................16 NOTES.........................................
Page 177 PART NAME INDEX FIRE SUPPRESSION FRONT MOUNT..............................60 FIRE SUPPRESSION SYSTEM ELECTRICAL SCHEMATIC........................ 62 WETCUT........................................63 WETCUT 50 GALLON TANK - 3PNT MOUNT............................64 WETCUT 100 OR 150 GALLON TANK - 3PNT MOUNT........................65 WETCUT 3PNT PLUMBING - 50IN MOWERS............................66 WETCUT 3PNT PLUMBING - LARGE MOWERS..........................
Page 180 BOOM MOUNT KIT Continued... ITEM PART NO. QTY. DESCRIPTION ------ MAINFRAME *REFER TO TRACTOR MOUNT KIT 21782 CAPSCREW,5/8" X 1-3/4",NC 21777 NYLOCK NUT,5/8",NC 32381 PIN,CAPPED 32322 BUSHING 06505185 CLAMP KIT 6T3211 GREASE ZERK,1/8"NPT 21677 NYLOCK NUT,7/16",NC 32380 PIN,1" 21683 CAPSCREW,7/16" X 2",NC TB1023 ROLL PIN 06420100...
Page 183 BOOM ASSEMBLY - FLAIL Continued... ITEM PART NO. QTY. DESCRIPTION ------ SWIVEL ASSY *REFER TO BOOM MOUNT KIT PAGE 6T3211 GREASE ZERK,1/8" 32321 BEARING 06500723 HOSE,1/4" X 52" 06500724 HOSE,1/4" X 70" ------ HOSE *REFER TO TRACTOR SPECIFIC PARTS ------ HOSE *REFER TO TRACTOR SPECIFIC PARTS 06505116 HOSE CLAMP...
Page 185 BOOM ASSEMBLY - ROTARY Continued... ITEM PART NO. QTY. DESCRIPTION ------ SWIVEL ASSY *REFER TO BOOM MOUNT KIT PAGE 6T3211 GREASE ZERK,1/8" 32321 BEARING 06500723 HOSE,1/4" X 52" 06500724 HOSE,1/4" X 70" ------ HOSE *REFER TO TRACTOR SPECIFIC PARTS ------ HOSE *REFER TO TRACTOR SPECIFIC PARTS 06505116 HOSE CLAMP...
Page 186 60IN ROTARY MOWER ITEM PART NO. QTY. DESCRIPTION 06320183 DECK,WLDMNT,60" RTRY,RSS 33777 SKID SHOE,RTRY 06320162 SHIELD,60"RTRY 33879 CAPSCREW,3/4" X 2-1/4",NF,GR 8 33880 FLATWASHER,3/4",GR 8,SAE 21993 LOCKWASHER,3/4",GR 8 6T2413 HEX NUT,3/4",NF,GR 8 6T1024H5 SPINDLE ASSY,CPLT,HD,5/8 HOLES 6T2270 PLOW BOLT,3/8" X 1",NC 22016 FLATWASHER,3/8"...
Page 187 60IN ROTARY MOWER Continued... ITEM PART NO. QTY. DESCRIPTION 21633 CAPSCREW,3/8" X 1-3/4",NC 6T0823 FLAP RETAINER,60" RTRY 06520238 FLAP,60" RTRY 6T1033 COUPLER COVER 6T1029 COUPLER CHAIN 21223 SPROCKET 21733 CAPSCREW,1/2" X 2",NC 33776 MOTOR MOUNT,PLATE,RTRY 06500458 HOSE,1" X 95" (PRESSURE) TF4852 FLANGE KIT,#20 06504011...
Page 189 60IN ROTARY DISK AND KNIVES Continued... ITEM PART NO. QTY. DESCRIPTION 27167 BOLT KIT (INCLUDES ITEMS 7, 8 & LOCTITE) 34876 BLADE MOUNTING DISK 6T1023R NYLOCK NUT,1-1/8”,NF 34878 SPACER 34684 STANDARD GRASS KNIFE 34685 HIGH SUCTION GRASS KNIFE (OPTIONAL) 34497 KNIFE MOUNTING BOLT 25270 FLATWASHER,5/8",GR8,USS...
Page 190 60IN BLADE BAR AND KNIVES ITEM PART NO. QTY. DESCRIPTION PT1018H5 SPINDLE 06400690 BAR,BLADE,RTRY60 6T1023R KNIFE MTG NUT,1-1/8,NYLOCK,NF 06533002 FLATWASHER,1-1/8,GR8 06521001 KNIFE,TRB50,5/8 06538000 KNIFE MTG BOLT,5/8 SHOULDER 33764 FLATWASHER,5/8,GR 8,SAE 6T2259 CAPSCREW,5/8 X 1-3/4,NF,GR8 COMMON RSS ©2014 Alamo Group Inc. Parts Section 6-16...
Page 193 ROTARY MOWER SPINDLE ASSEMBLY Continued... ITEM PART NO. QTY. DESCRIPTION 6T1024H5 SPINDLE ASSEMBLY COMPLETE 6T1031 SPROCKET 6T1016 BEARING LOCK NUT - THICK 22596 JAM WASHER 6T1015 BEARING ADJUSTMENT NUT - THIN 6T1014 BEARING ADJUSTMENT SLEEVE 6T1011 UPPER SEAL - SET OF 2 6T1012 BEARING CONE 6T1013...
Page 194 75IN FLAIL - STANDARD ROTATION ITEM PART NO. QTY. DESCRIPTION 06320185 BONNET,75",STD,RSS 28737 BAFFLE,75",STD COMMON RSS ©2014 Alamo Group Inc. Parts Section 6-20...
Page 195 75IN FLAIL - STANDARD ROTATION Continued... ITEM PART NO. QTY. DESCRIPTION 6T2283 CARRIAGE BOLT,3/8" X 1",NC 6T2615 WASHER,FENDER,3/8" 21988 LOCKWASHER,3/8" 21625 HEX NUT,3/8",NC 27975A GUARD,CUTTERSHAFT 21731 CAPSCREW,1/2" X 1-1/2",NC 21990 LOCKWASHER,1/2" 21725 HEX NUT,1/2",NC 28735 GROUND ROLLER ADJ BRKT,STD DTY 06520028 BEARING,FLANGE,1-3/8,GRNDRLR 06520027...
Page 196 75IN FLAIL - REVERSE ROTATION ITEM PART NO. QTY. DESCRIPTION 06320185 BONNET,75,STD,RSS 28968A TRASH GUARD,75" COMMON RSS ©2014 Alamo Group Inc. Parts Section 6-22...
Page 197 75IN FLAIL - REVERSE ROTATION Continued... ITEM PART NO. QTY. DESCRIPTION 6T2283 CARRIAGE BOLT,3/8" X 1",NC 6T2615 WASHER,FENDER,3/8" 21988 LOCKWASHER,3/8" 21625 HEX NUT,3/8",NC 27975A GUARD,CUTTERSHAFT 21731 CAPSCREW,1/2" X 1-1/2",NC 21990 LOCKWASHER,1/2" 21725 HEX NUT,1/2",NC 28735 GROUND ROLLER ADJ BRKT,STD DTY 06520028 BEARING,FLANGE,1-3/8",GRNDRLR 06520027...
Page 199 FLAIL DRIVE ASSEMBLY Continued... ITEM PART NO. QTY. DESCRIPTION ------ BONNET *REFER TO HEAD PARTS 32287 MOTOR CHANNEL 21700 HEX NUT,1/2",NF TF3620A SPRING,TENSIONER 27938 BUSHING,MACH,1"OD X 1/2"ID X 14GA. 40496 ROD,THREADED,1/2"NF X 8" PT3611A CLEVIS,6" 06504013 MOTOR TF3044 SHEAVE,8.0" TF3013 BUSHING,QD,SK 1-1/4",1/4"...
Page 201 BOOM PIVOT ASSEMBLY Continued... ITEM PART NO. QTY. DESCRIPTION ------ BOOM *REFER TO BOOM ASSEMBLY 32316 LINKAGE, BOOM TO CYLINDER 21677 NYLOCK NUT, 7/16",NC 32319 PIN,LINKAGE 21687 CAPSCREW, 7/16" X 3" NC 21688 CAPSCREW, 7/16" X 3-1/4" NC 32318 BEARING 32745 LINKAGE,CYLINDER TO TREE 6T3207...
Page 203 SLIDE ASSEMBLY Continued... ITEM PART NO. QTY. DESCRIPTION ------ MOWER *REFER TO MOWER ASSEMBLY PAGE 35336 06770096 SLIDE ASSEMBLY 06501027 CYLINDER, 2-1/2" X 30" 21632 CAPSCREW, 3/8" X 1-1/2" NC 21630 CAPSCREW, 3/8" X 1" NC 21804 CAPSCREW, 3/4" X 1-1/4" NF 21929 CAPSCREW, 1"...
Page 204 HOSE RING ASSEMBLY ITEM PART NO. QTY. DESCRIPTION ------ TREE *REFER TO BOOM PIVOT ASSY PAGE 21631 CAPSCREW,3/8" X 1-1/4",NC 22016 FLATWASHER,3/8" 06460043 ANGLE,MOUNT 21627 NYLOCK NUT,3/8",NC 6310117 RING,HOSE 06530003 CAPSCREW,SHOULDER,SKT HD 06505021 COVER,HOSES (BOOM TO HOSE GUIDE) *NOT SHOWN ---- 06505020 COVER,HOSES (HOSE GUIDE TO DECK) *NOT SHOWN...
Page 205 2-1/2IN X 30IN CYLINDER BREAKDOWN ITEM PART NO. QTY. DESCRIPTION 06501027 CYLINDER,WELDED,2-1/2" X 30" 06501615 PISTON ROD ASSY 06501616 BUTT & TUBE ASSY 06501617 PISTON 06501618 GLAND 06501598 PORT PLUG 6-15 06501619 SEAL KIT COMMON RSS ©2014 Alamo Group Inc. Parts Section 6-31...
Page 206 3IN X 15IN CYLINDER BREAKDOWN ITEM PART NO. QTY. DESCRIPTION 06501026 CYLINDER,WELDED,3" X 15" 06501608 PISTON ROD ASSY 06501609 BUTT & TUBE ASSY 06501610 PISTON 06501563 GLAND 6T0179 LOCK NUT,1-1/4"-12 UNF (TORQUE TO 315 FT.LB.) 06501598 PORT PLUG (NOT SHOWN) 06501611 BUSHING 06501612...
Page 207 4IN X 14IN CYLINDER BREAKDOWN ITEM PART NO. QTY. DESCRIPTION ------ 06501028 HYDRAULIC CYLINDER COMPLETE 06501623 06501624 TUBE WELDMENT 06501558 PISTON 06501607 CYLINDER HEAD 6T0172 CLEVIS ------ 06501560 SEAL REPAIR KIT (ITEMS 6 THROUGH 12) COMMON RSS ©2014 Alamo Group Inc. Parts Section 6-33...
Page 208 4IN X 15IN CYLINDER BREAKDOWN ITEM PART NO. QTY. DESCRIPTION 32365 CYLINDER,WELDED,4" X 15" 06501604 PISTON ROD ASSY 06501605 BUTT & TUBE ASSY 06501606 PISTON 06501607 GLAND 06501753 LOCK NUT,1-1/4"-12 UNF (TORQUE TO 510 FT.LB.) 33757 SEAL KIT,PACKING (ITEMS 12 THRU 19) ------ GREASE ZERK ------...
Page 211 FRONT PUMP BREAKDOWN Continued... ITEM PART NO. QTY. DESCRIPTION 23152 PUMP ASSEMBLY,1-3/4”,COMPLETE 22766 SHAFT END COVER 22779 PORT END COVER 22774 GEAR HOUSING,1-3/4” 22771 GEAR SET 23824 CAPSCREW 06504078 SCREW,DRIVE 22773 DOWEL PINS 06504077 NAMEPLATE 22770 THRUST PLATE 22767 PLUG 06504075 SEAL,BK-UP 06504074...
Page 213 ROTARY MOTOR BREAKDOWN Continued... ITEM PART NO. QTY. DESCRIPTION 06504011 MOTOR ASSEMBLY,TRB60 22790 END,COVER 06504088 HOUSING, PEC 06504062 HOUSING, GEAR,TRB60 06504090 SET, GEAR SHAFT 06504104 CAP SCREW,TRB60 06504078 SCREW, DRIVE 06504092 06504093 PIN, DOWEL 06504094 NAME PLATE 06504095 THRPL 2961940 PLUG, ODT 2962200 RING, SNAP...
Page 215 FLAIL MOTOR BREAKDOWN Continued... ITEM PART NO. QTY. DESCRIPTION 06504132 MOTOR ASSEMBLY 350 - TBF50, TBF63 06504141 SHAFT END COVER 06504040 PORT END COVER 06504041 GEAR HOUSING 06504117 MATCHED GEAR SET TF4402 BALL BEARING 06504043 CAP SCREW 06504044 SET SCREW 06504028 06504045 DOWEL PIN...
Page 217 COOLER ASSEMBLY - OPTION Continued... ITEM PART NO. QTY. DESCRIPTION 21530 CAPSCREW,1/4 X1 NC 21986 LOCKWASHER,1/4 22014 FLATWASHER,1/4 35176 1/4 U-NUT 06370015 SCREEN,COOLER,FRNT 06380006 MNT,COOLER,BUMPER TANK,RH 06380007 MNT,COOLER,BUMPER TANK,LH 06510350 COOLER,FRONT MNT 06510029 FAN ASSY, ONLY 21629 CAPSCREW,3/8 X 3/4 NC 21988 LOCKWASHER,3/8 22016...
Page 218 RESERVOIR TANK FILTER ASSEMBLY ITEM PART NO. QTY. DESCRIPTION 06505044 FILTER ASSY SAE 10 MICRON 28583 CAPSCREW,8MM X 25MM(1.25 PITCH) 06505045 COVER 06505046 SEAL KIT 06505047 SPRING 06505048 BYPASS 35259 FILTER,10 MIC,RETURN LINE 06505049 CAN/BODY COMMON RSS ©2014 Alamo Group Inc. Parts Section 6-44...
Page 219 PUMP AND GRILL GUARD OPTIONS ITEM PART NO. QTY. DESCRIPTION 32430 UNIVERSAL PUMP GUARD 32737 UNIVERSAL GRILL GUARD 21833 CAPSCREW,3/4" X 2-1/4",NC 22021 FLATWASHER,3/4" 21993 LOCKWASHER,3/4" 21825 HEX NUT,3/4",NC COMMON RSS ©2014 Alamo Group Inc. Parts Section 6-45...
Page 220 MANUAL LIFT VALVE SWITCH BOX ITEM PART NO. QTY. DESCRIPTION 06514013 SWBX,ALUM,BLK,06510102 35226 SWITCH,MOWER,COLEHERSEE 33811 SWITCH,MASTER/DECK FLOAT 6T3923 INDICTATOR LIGHT,ON,RED 06514014 BREAKER,10A,SWBX 34540 STRAIN RELIEF,3/4,BLACK,NYLON 06550018 DECAL,SWTCHBX,TM/TSF,CG 35227 RELAY,DP,DT,12V,LY2F,35226 COMMON RSS ©2014 Alamo Group Inc. Parts Section 6-46...
Page 222 ELECTRONIC LIFT VALVE SWITCH BOX ITEM PART NO. QTY. DESCRIPTION 06510196 SWBX,ASSY 33811 SWITCH,MASTER/DECK FLOAT 33813 SWITCH,SFTY SHIELD 34532 SWITCH,TRVL LCK 34540 STRAIN RELIEF,3/4",BLACK,NYLON 6T3923 INDICTATOR LIGHT,ON,RED 06514006 BREAKER,15A,SWBX 06550044 DECAL,SWBX,06510047 35226 SWITCH,MOWER,COLEHERSEE 35227 RELAY,DP,DT,12V,LY2F,35226 COMMON RSS ©2014 Alamo Group Inc. Parts Section 6-48...
Page 224 SOLENOID SWITCH BOX AND WIRING ITEM PART NO. QTY. DESCRIPTION ------ SWITCH BOX RE37651 PLUG,AUX PWR 24204 FUSE HOLDER,IN-LINE (OPTION) 6T3965 FUSE,3AMP (OPTION) 6T3934 TEMPERATURE GAUGE (OPTION) 6T3931 TEMPERATURE SENSOR (OPTION) COMMON RSS ©2014 Alamo Group Inc. Parts Section 6-50...
Page 225 BRAKE VALVE ASSEMBLY ITEM PART NO. QTY. DESCRIPTION 06510083 BRAKE VALVE, ASSY 34092 BRAKE VALVE, BLANK 34094 LOGIC ELEMENT 34095 RELIEF VALVE, 3000 PSI 06510095 METRI PAK COIL 34093 CARTRIDGE, 2 POSITION, 3 WAY (WITH NUT & WASHER) 34091 RELIEF VALVE, 2600 PSI 34096 RELIEF SEAL KIT ----...
Page 233 FIRE SUPPRESSION 3-POINT MOUNT Continued... ITEM PART NO. QTY. DESCRIPTION 06370137 MOUNT,3PNT,FIRE SYS 06503108 FITTING,1/2"BARB X 1/2"MP 35091 CLAMP,HOSE,#6 06520469 HOSE,1/2",BULK (FEET) 06503168 SWIVEL,1/2"STR,POLY 06520359 PUMP,LARGE 35176 U-NUT,1/4" 06520367 ELBOW,1/2"BARB X 1/2"MP,POLY 27329 U-BOLT,1/4" 06520361 FILTER 06520351 ELEMENT,FILTER 06520349 FITTING,BARB,HOSE 06503169 REDUCER,BUSHING (100 &...
Page 235 FIRE SUPPRESSION FRONT MOUNT Continued... ITEM PART NO. QTY. DESCRIPTION 06520342 TANK,50 GALLON 06370204 MNT,TANK,FRNT,50 GALLON 35176 U-NUT,1/4,3/4 TO CENTER 35091 CLAMP,HOSE,#6 06503168 SWIVEL,1/2 STR,POLY 06520469 HOSE,1/2,SPRAYER 06520359 PUMP,FIRE KIT 06503108 FITTING,1/2"BARB X 1/2"MP 06520367 ELBOW,1/2MPX1/2BARB,POLY 27329 U-BOLT,1/4X2X1 06520361 FILTER,FIRE KIT,RAILKUT 06520351 STRAINER,40 MESH 06520349...
Page 238 WETCUT 50 GALLON TANK - 3PNT MOUNT ITEM PART NO. QTY. DESCRIPTION 06370128 MNT,3PNT,UNI 06370136 MNT,TANK,50GAL,WETCUT 06520342 TANK,50GA.,WETCUT RD1032 PIN,LYNCH,1/4" X 2" TB1036 PIN,SEC BOOM SWIV,1" X 4-11/16" 06520343 ANCHOR,STRAP,WETCUT 06520344 BOLT,STRAP,TANK,WETCUT 06520345 STRAP,TANK,WETCUT COMMON RSS ©2014 Alamo Group Inc. Parts Section 6-64...
Page 239 WETCUT 100 OR 150 GALLON TANK - 3PNT MOUNT ITEM PART NO. QTY. DESCRIPTION 06370128 MNT,3PNT,UNI 06370138 MNT,TANK,100GAL,WETCUT 06370139 MNT,TANK,150GAL,WETCUT 06520372 TANK,100GA.,WETCUT 06520373 TANK,150GA.,WETCUT 21527 HEX NUT,NYLOCK,1/4",NC 21530 CAPSCREW,1/4" X 1",NC RD1032 PIN,LYNCH 1/4" X 2" TB1036 PIN,SEC BOOM SWIV,1" X 4-11/16" 06520345 STRAP,TANK,WETCUT 06520344...
Page 241 WETCUT 3PNT PLUMBING - 50IN MOWERS Continued... ITEM PART NO. QTY. DESCRIPTION 06370128 MNT,3PNT,UNI 06520336 CNTRLR,SENSOR,06520333 06520341 PUMP,WETCUT 06520346 FITTING,BULKHEAD,WETCUT (50 GALLON TANKS ONLY) 06520347 FITTING,ELBOW,WETCUT 06520348 VLV,BALL,WETCUT 06520349 FITTING,BARB,HOSE,WETCUT 06503173 FITTING,1/2MP X 3/8"BARB 06520353 FITTING,TEE,WETCUT 06520367 ELBOW,1/2" X 1/2"BARB,POLY 06520361 FILTER,FIRE KIT,RAILKUT 06520400...
Page 243 WETCUT 3PNT PLUMBING - LARGE MOWERS Continued... ITEM PART NO. QTY. DESCRIPTION 06370128 MNT,3PNT,UNI 35176 U-NUT,1/4,3/4 TO CENTER 06520336 CNTRLR,SENSOR,06520333 06520354 BUSHING,REDUCER,WETCUT 27329 U-BOLT,1/4" X 1" X 2" 06520353 FITTING,TEE,WETCUT 06520349 FITTING,BARB,HOSE,WETCUT 35091 CLAMP, HOSE #6 06520469 1/2" HOSE (FEET) 06503168 SWIVEL,1/2"...
Page 245 WETCUT FRONT PLUMBING - 50IN MOWERS Continued... ITEM PART NO. QTY. DESCRIPTION 06370204 MNT,FRONT,UNI 06520336 CNTRLR,SENSOR,06520333 06520341 PUMP,WETCUT 06520346 FITTING,BULKHEAD,WETCUT 06520347 FITTING,ELBOW,WETCUT 06520348 VLV,BALL,WETCUT 06520349 FITTING,BARB,HOSE,WETCUT 06503173 FITTING,1/2"MP X 3/8"BARB 06520353 FITTING,TEE,WETCUT 06520367 ELBOW,1/2"MP X 1/2"BARB,POLY 06520361 FILTER,FIRE KIT,RAILKUT 06520351 STRAINER,40MESH 06520400 QUIK CPLR,MALE,1/2",WETCUT...
Page 247 WETCUT FRONT PLUMBING - LARGE MOWERS Continued... ITEM PART NO. QTY. DESCRIPTION 06370204 MNT,FRONT,UNIV 35176 U-NUT,1/4,3/4 TO CENTER 06520336 CNTRLR,SENSOR,06520333 06520354 BUSHING,REDUCER,WETCUT 27329 U-BOLT,1/4" X 1" X 2" 06520353 FITTING,TEE,WETCUT 06520349 FITTING,BARB,HOSE,WETCUT 35091 CLAMP, HOSE #6 06520469 1/2" HOSE (FEET) 06503168 SWIVEL,1/2"...
Page 249 WETCUT 50IN SPRAYER HEAD ASSEMBLY Continued... ITEM PART NO. QTY. DESCRIPTION 06370105 HOOD,SPRAYER 06370106 HINGE,LH,SPRAYER 06370107 HINGE,RH,SPRAYER 06370108 HINGE,CNTR,SPRAYER 06410668 GUARD,SPRAYER,WETCUT 06410753 MNT,RH,WET CUT (FLAIL) 06410942 MNT,RH,WET CUT (ROTARY) 06410754 MNT,LH,WET CUT (FLAIL) 06410943 MNT,LH,WET CUT (ROTARY) 06410796 GUARD,HOSE,WETCUT 06420069 PIN,HINGE,WET CUT 06497003 TUBE,LG,SPRAYER...
Page 251 WETCUT 60IN SPRAYER HEAD ASSEMBLY Continued... ITEM PART NO. QTY. DESCRIPTION 06370210 HOOD,SPRAYER 06370106 HINGE,LH,SPRAYER 06370107 HINGE,RH,SPRAYER 06370108 HINGE,CNTR,SPRAYER 06411234 GUARD,SPRAYER,WETCUT 06410753 MNT,RH,WET CUT (FLAIL) 06410942 MNT,RH,WET CUT (ROTARY) 06410754 MNT,LH,WET CUT (FLAIL) 06410943 MNT,LH,WET CUT (ROTARY) 06410796 GUARD,HOSE,WETCUT 06420069 PIN,HINGE,WET CUT 06497009 TUBE,LG,SPRAYER...
Page 253 WARRANTY SECTION Warranty Section 7-1...
Page 255: Warranty Information
All Tiger obligation under this warranty shall be terminated if the equipment is modified or altered in ways not approved in writing by Tiger, if repair parts other than genuine Tiger repair parts have been used, or if the equipment has been subject to misuse, neglect, accident, improper maintenance or improper operation.
Page 256 . Common sense should play a large role in the operation of this machine. Since we at Tiger Corporation are constantly striving to improve out products, we reserve the right to change specifications or design at any time.
Page 257 TO THE OWNER / OPERATOR / DEALER To keep your implement running efficiently and safely, read your manual thoroughly and follow these directions and the Safety Messages in this manual and on the machine. The table of contents clearly identifies each section where you can easily find the information you need. The Occupational Safety and Health Act (OSHA 1928.51 subpart C) makes the following minimum requirements for tractor operators.

This manual is also suitable for:

Wildkat jd6110-20m/r

Tiger WILDKAT JD61 M/R Series Manual

Quick Links

Need help?

Questions and answers

Summary of Contents for Tiger WILDKAT JD61 M/R Series

Page 5: Table Of Contents

Page 7: Safety Section

Page 33: Assembly / Mounting Section

Page 57: Operation Section

Page 103: Maintenance Section

Page 133: Parts Section

Page 255: Warranty Information

This manual is also suitable for:

Tiger WILDKAT JD61 M/R Series Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Tiger WILDKAT JD61 M/R Series

Summary of Contents for Tiger WILDKAT JD61 M/R Series

Page 5: Table Of Contents

Page 7: Safety Section

Page 33: Assembly / Mounting Section

Page 57: Operation Section

Page 103: Maintenance Section

Page 133: Parts Section

Page 255: Warranty Information

This manual is also suitable for:
