ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE
!
Use the correct bolts as indicated. Do not tighten any of the bolts until the swing is
completely assembled.
!
Do not discard of any of the packaging until you have checked that you have all of the
parts and fittings required.
!
Keep children away during assembly. This item contains small parts that can be
swallowed by children. Children should always be under direct adult supervision while
using this product.
!
Retain these assembly instructions for future reference.
!
Quote the following FQC NO. when contacting the service center.
V-3
INTENDED FOR RESIDENTIAL USE ONLY.
RTS422E
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
DO NOT RETURN TO THE STORE!
STOP
PAGE 1 OF 7
COURTYARD CREATIONS INC.

Advertisement

loading
Need help?

Need help?

Do you have a question about the RTS422E and is the answer not in the manual?

Questions and answers

Related Manuals for Courtyard Creations RTS422E

Summary of Contents for Courtyard Creations RTS422E

  • Page 1 Retain these assembly instructions for future reference. Quote the following FQC NO. when contacting the service center. SERVICE CENTER TOLL FREE NO. TEL: 1-877-539-7436 FAX: 1-877-539-7439 DO NOT RETURN TO THE STORE! STOP COURTYARD CREATIONS INC. PAGE 1 OF 7...

  • Page 2: Parts List

    C. Lay out all of the parts and identify them by using the table below. PARTS LIST PART MATERIAL PART Q’TY 17GA20405201-Y3 CODE SUSPENSION SPRING RTS422E-CS09-8 17C40A0722001YX BOLT M6*65 62RUS459FH102 17C40A0714001YX BOLT M6*40 REAR CROSS BRACE 62RUS422WI101 17C40A0716001YX BOLT M6*45...
  • Page 3 ASSEMBLY (Note: For all nuts and bolts fastening, always use a washer (#23 or #24) between the tube and bolt or the tube and nut.) Step 1: Insert the top cross beam w/adjustable teeth (#1) into upright supports (#4 and #5), fasten them by using bolts (#18), washers (#24), and Step 1 plastic nuts (#25).
  • Page 4 Step 5: Fasten the back assembly (#8) to the seat assembly (#9) by using bolts (#20), washers (#24), and plastic nuts (#25). Tighten all of the plastic nuts and bolts. See Fig. B. Fig. B Step 6: Open the seat assembly and fasten a swing arm tube (#11) and the left arm (#6) to the back assembly (#8) by using bolt (#19), washers (#24).
  • Page 5 Step 8: Hang the other side of the suspension spring (#16) into the hole located in the angled brace on the top cross beam w/adjustable teeth (#1). Repeat the same procedure for both sides. See Fig. E. Warning: Make sure that both ends of the suspension springs (#16) go completely through the holes in the angled braces on the top cross beam w/adjustable teeth (#1) and swing...

  • Page 6: Warranty

    (i.e. overnight or on rainy days) Warranty • This product is covered by Courtyard Creations Inc.'s one–year limited warranty. • Proof of purchase (dated register receipt) is required for warranty claims. • It remains the customer’s responsibility for freight and packing charges to and from the service center.
  • Page 7 Special Warnings • The user of this swing should always inspect it before each use. • It is essential to place this swing on level ground and not less than 6 feet from any obstruction; such as fences, garages, houses, overhanging branches, laundry lines, or electrical wires. •...

  • Page 8: Instrucciones De Armado

    Cuando se comunique con el centro de servicio, proporcione siempre el siguiente código de control de calidad (FQC, por sus siglas en inglés). NÚMERO GRATUITO DEL CENTRO DE SERVICIO TEL: 1-877-539-7436 FAX: 1-877-539-7439 ¡NO DEVUELVA ESTE PRODUCTO A LA TIENDA! ALTO PÁGINA 1 DE 7 COURTYARD CREATIONS INC.
  • Page 9 C. Coloque todas las piezas en una superficie plana e identifíquelas utilizando la tabla siguiente. PARTS LIST NO.DE CANT CÓDIGO DEL PARTE 17GA20405201-Y3 PARTE MATERIAL -IDAD RESORTE DE SUSPENSIÓN RTS422E-CS09-8 17C40A0722001YX TORNILLO M6*65 62RUS459FH102 17C40A0714001YX REFUERZO TRANSVERSAL TRASERO TORNILLO M6*40 62RUS422WI101 17C40A0716001YX...
  • Page 10 ENSAMBLE (Nota: Para todos los pernos y las tuercas de fijación, utilice siempre una arandela (#23 o #24) entre el tubo y el perno o el tubo y la tuerca.) Paso 1: Inserte en el travesaño superior w/dientes ajustable (#1) soportes verticales (#4 y #5), les sujete mediante los pernos (#18), las Paso 1 arandelas (#24) y las tuercas plásticas (#25).
  • Page 11 Step 5: Sujeta el conjunto de respaldo (#8) con el conjunto del asiento (#9) por medio de los tornillos (#20), las arandelas (#24) y las tuercas de plástico (#25). Apriete todas las tuercas y los tornillos. Consulte la figura Fig. B Paso 6: Despliegue el asiento y sujete un tubo del descansabrazos (#11) y un descansabrazos...
  • Page 12 Paso 8: Colgar los extremos opuestos de resorte de suspension (#16) en los agujeros situados en el angulo de los apoyos de la viga transversal superior w/adjustable dientes (#1). Repita el mismo procedimiento para ambos lados. Consulte la figura E. Advertencia: Asegúrese de que ambos extremos de los resortes de suspensión (#16) pasan...
  • Page 13 Garantía • Este producto está cubierto por una garantía limitada de un año con Courtyard Creations Inc. • Para cualquier reclamación de la garantía es necesario presentar el comprobante de compra (recibo de caja registradora con fecha).
  • Page 14 Advertencias especiales • Inspeccione siempre el columpio antes de usarlo. • Es esencial que coloque el columpio en una superficie plana dejando un margen de al menos de 6 pies (1.80m) respecto de cualquier obstrucción, como rejas, cocheras, casas, ramas bajas de árboles, tendederos o cables eléctricos.
