ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE
!
Use the correct bolts as indicated. Do not tighten any of the bolts until is completely assembled.
!
Do not discard of any of the packaging until you have checked that you have all of the parts and
fittings required.
!
Keep children away during assembly. This item contains small parts that can be swallowed by
children. Children should always be under direct adult supervision while using this product.
!
Retain these assembly instructions for future reference.
!
Quote the following FQC NO. when contacting the service center.
INTENDED FOR RESIDENTIAL USE ONLY.
RUS422F
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
DON'T RETURN TO STORE!
STOP
PAGE 1 OF 6
-WM
COURTYARD CREATIONS INC.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Courtyard Creations RUS422F-WM
Summary of Contents for Courtyard Creations RUS422F-WM
- Page 1 Children should always be under direct adult supervision while using this product. Retain these assembly instructions for future reference. Quote the following FQC NO. when contacting the service center. SERVICE CENTER TOLL FREE NO. TEL: 1-877-539-7436 FAX: 1-877-539-7439 DON’T RETURN TO STORE! STOP COURTYARD CREATIONS INC. PAGE 1 OF 6 ...
- Page 2 A. Read instructions thoroughly. Acquaint yourself with the inventory of parts and the accompanying drawings to ensure safe and proper assembly. B. You will need the following tools: - Phillips Screwdriver (Not Included) - Nut Wrench (See Part #27) - Hex. Key Wrench (See Part #26) C.
- Page 3 ASSEMBLY (Note: For all nuts and bolts fastening, always use a washer (#19 or #20) between the tube and bolt or the tube and Step A - 1 nut.) Step A - 1: 21 19 Insert into the top cross beam w/adjustable teeth (#1) upright supports (#2 and #3), fasten them by using bolts (#12), washers Do not tighten the bolts...
- Page 4 Step B: Insert the front of the seat assembly (#7) into the swing arm (#6). Fasten them together by using bolt (#17) and steel washer (#20). Open the seat assembly (#7) and fasten a swing arm tube (#8) and a swing arm (#6) to the seat assembly (#7) by using bolt (#15) and washers (#19), and plastic nut (#21).
- Page 5 Step 1 & Step 2: Slide the canopy/frame connectors (#24) into the canopy (#28). Fasten them together by using screws (#18) in the pre-drilled holes. Make sure that the teeth of the canopy/frame connectors are facing toward Step 1 the inside of the frame. Step 2 Fig.
- Page 6 Cleaning and Maintenance • Wash frame parts and fabric with mild soap and water, rinse thoroughly. Dry frame completely and allow the fabric to drip dry. • Do not use bleach, acid, or other solvents on the fabric or frame parts. •...
