Courtyard Creations RUS0188-WM Assembly Instructions

ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE

PARTS LIST

PART
MATERIAL CODE
NO.
1
RUS0188-CS01
2
RUS0188-CS02
3
62RUS023DH101
4
RUS0175-CS02
5
RUS0188-CS03
6
17C01A0710002Y4
7
17C01A0719072Y4
Attention:
Make sure that each bolt needed for all steps match the
corresponding figure to ensure proper assembly.

STEP 1:

Insert the right and left arms (#1 and #2) into the cross braces (#3)
on both sides. Fasten them together by using bolts (#6), washers
(#9), and plastic nuts (#10). Keep the bolts loose. See Figure 1.
NOTE:
1. The labels marked "L" and "R" on the arms (#1 and #2) should
coincide with Figure 1 to ensure proper assembly.
2. The arrows mark on the right and left arms (#1 and #2) must
coincide with Figure 1 to ensure proper assembly.
Do not discard any of the packaging until you have checked that you have all the parts and pack of fittings.
!
! Keep children away during assembly. This item contains small parts which can be swallowed by children.
Children should always be under direct adult supervision while using the product.
! Retain the assembly instructions for future reference.
Please quote following FQC NO. when contacting service center.
!
INTENDED FOR RESIDENTIAL USE ONLY.
RUS0188-
PART
RIGHT ARM
LEFT ARM
CROSS BRACE
BOTTOM FRAME
SEAT ASSEMBLY
BOLT M6*30
BOLT M6*55
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
DON'T RETURN TO STORE!
STOP
PAGE 1 OF 2
WM
PART
Q'TY MATERIAL CODE
NO.
1
8
17C01A0726011Y4
1 9
17FA05040301-Y4
2 10
1800C23001
1 11
1800337002
1 12
61R0188C00001BA
4 13
17KAA0201----Y4
4 14
17KAB1101----Y4
FIGURE 1
R
Arm
assembly
PART
BOLT M6*80
WASHER d6.5*D13*1.0
PLASTIC NUT M6*P1.0
BOLT CAP M6
CUSHION
HEX.KEY WRENCH 6MM
NUT WRENCH 10&13MM
#6 BOLT M6*30
COURTYARD CREATIONS INC.
Q'TY
4
32
12
16
2
1
1
L
