- Page 1 Model H IR Dome Network Camera Quick Start Guide V1.0.1 ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD.
-
Page 2: Foreword
Foreword General This manual introduces the functions, installation, and operations of the camera. Safety Instructions The following categorized signal words with defined meaning might appear in the manual. Signal Words Meaning Indicates a medium or low potential hazard which, if not avoided, WARNING could result in slight or moderate injury. - Page 3 occurred when using the device. If there is any uncertainty or controversy, please refer to our final explanation. Foreword II...
-
Page 4: Important Safeguards And Warnings
Important Safeguards and Warnings Electrical Safety All installation and operation should conform to your local electrical safety codes. The power source shall conform to the Safety Extra Low Voltage (SELV) standard, and supply power with rated voltage which conforms to Limited power Source requirement according to IEC60950-1. - Page 5 It is recommended to use the device together with lightning arrester to improve lightning protection effect. It is recommended to ground the device to enhance reliability. Do not touch the image sensor (CMOS) directly. Dust and dirt could be removed with air blower, or you can wipe the lens gently with soft cloth that moistened with alcohol.
-
Page 6: Table Of Contents
Table of Contents Foreword ..............................I Important Safeguards and Warnings ....................III 1 Introduction ............................1 Device Ports ..........................1 Connecting Alarm Input/output ..................... 2 2 Network Configuration.......................... 4 Initializing Device .......................... 4 Modifying Device IP Address ......................5 Logging in to Web Interface ......................6 3 Installation .............................. -
Page 7: Introduction
Introduction Device Ports Device ports might vary with different models, and the actual product shall prevail. Waterproof all the cable joints with insulating tape and waterproof tape to avoid short circuit and water damage. For the detailed operation, see the FAQ Manual. Figure 1-1 Device ports For more information about device ports, see Table 1-1. -
Page 8: Connecting Alarm Input/Output
No. Port Name Description CVBS Outputs analog video signal. Table 1-2 Alarm I/O port introduction Port Port Name Description ALARM_IN (pin1– Receives the switch signal of external alarm pin3) source. GND (pin4) Connect all the alarm input devices to the same GND port. - Page 9 Figure 1-3 Alarm output Step 3 Log in to web interface, and configure alarm input and alarm output in alarm setting. The alarm input on the web interface is corresponding to the alarm input end of the I/O port. There will be high level and low level alarm signal generated by the alarm input device when alarm occurs, set the input mode to "NO"...
-
Page 10: Network Configuration
Network Configuration Device initialization and IP address setting can be finished with the "ConfigTool" or on web interface. For more information, see the Web Operation Manual. Device initialization is available on select models, and it is required at first use or after the device being reset. -
Page 11: Modifying Device Ip Address
The Device initialization interface is displayed. Step 6 Select the devices that need initialization, and then click Initialize. The password setting interface is displayed. See Figure 2-2. Figure 2-2 Password setting Step 7 Set and confirm the password of the devices, then enter a valid email address, and then click Next. -
Page 12: Logging In To Web Interface
After clicking Search setting, enter the username and password, and make sure that they are the same as what you set during initialization; otherwise there will be wrong password notice. Step 2 Select the devices whose IP addresses need to be modified, and then click Modify IP. The Modify IP Address interface is displayed. - Page 13 Figure 2-4 Main interface Network Configuration 7...
-
Page 14: Installation
Installation Packing List The tool required for the installation such as electric drill is not provided in the package. The operation manual and related tool are contained in the disk or the QR code, and the actual packing shall prevail. Dimensions The following figures are for reference only, and the actual product shall prevail. -
Page 15: Installing Device
Installing Device 3.3.1 Installation Method 3.3.2 Installing SD Card (Optional) Disconnect the power before installing or removing the SD card. Press and hold the reset button for 10 s to reset the camera. 3.3.3 Threading Cable This section takes threading network cable for example. Installation 9... -
Page 16: Attaching Device
3.3.4 Attaching Device Make sure that the mounting surface is strong enough to hold at least three times of the weight of the device and bracket. Installation 10... - Page 17 Cable going through the mounting surface Installation 11...
-
Page 18: Wrapping Waterproof Tape (Optional)
Cable going through the side cable tray 3.3.5 Wrapping Waterproof Tape (Optional) This part is needed when the cable connector is out of the junction box. Installation 12... -
Page 19: Adjusting Lens Angle
3.3.6 Adjusting Lens Angle Installation 13... - Page 20 ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD. Address: No.1199, Bin'an Road, Binjiang District, Hangzhou, P.R. China Postcode: 310053 Tel: +86-571-87688883 Fax: +86-571-87688815 Email: overseas@dahuatech.com Website: www.dahuasecurity.com...
