Printed Matter No. 9836 6515 00
Valid from Serial No. A3540001
2015-04
LMS08 SR42 (7-45Nm)
Read all safety warnings and instructions
Failure to follow the safety warnings and
instructions may result in electric shock, fire
and/or serious injury.
Save all warnings and instructions for
future reference
8434 1081 06
WARNING
LMS08 SR42
Product Instructions
Impact Wrench
Advertisement
Related Manuals for Atlas Copco LMS08 SR42
Summary of Contents for Atlas Copco LMS08 SR42
- Page 1 Printed Matter No. 9836 6515 00 Impact Wrench Valid from Serial No. A3540001 Product Instructions 2015-04 LMS08 SR42 (7-45Nm) 8434 1081 06 WARNING Read all safety warnings and instructions Failure to follow the safety warnings and instructions may result in electric shock, fire and/or serious injury.
- Page 2 Table of content LMS08 SR42 Table of content Product information ...............3 Installation ..................5 Operation ..................6 Service ..................7 Spare part list ................13 Accessories .................16 © Atlas Copco Industrial Technique AB - 9836 6515 00...
- Page 3 NOTICE is used to address practices not related to personal injury. Warranty Contact the Atlas Copco sales representative within your area to claim a product. Warranty will only be approved if the product has been installed, operated and overhauled according to the Operating Instructions.
- Page 4 If the machine is not working properly, it should immediately be taken away for inspection. At the overhauls, all parts should be cleaned ac- curately and defective or worn parts should be replaced. © Atlas Copco Industrial Technique AB - 9836 6515 00...
- Page 5 D = Number of drops per min (1 drop = 15 mm L* 0.2 = D this applies to the use of long work cycle air line tools. A single point lubricator type Atlas Copco Dosol can also be used for tools with short running cycles.
- Page 6 Never exceed the recommended maximum tightening torque. Test methods Measurement using a hydraulic Torque Tension tester is recommended for testing tool performance, see Test data. © Atlas Copco Industrial Technique AB - 9836 6515 00...
- Page 7 Lubricate the threads with grease prior to fitting. A All O-rings must be greased prior to assembly. When the machine is in constant operation, installation of an Atlas Copco DIM oil mist lubricating device or a Dosol type single point lubricating device is recommended.
- Page 8 Socket size Socket length Socket size Socket opening Bolt size d (max) L (max) D (max) A/F (max) B (max) Quick change 22mm 34mm 20mm 13mm (1/2") M8 (5/16") 1/4" © Atlas Copco Industrial Technique AB - 9836 6515 00...
- Page 9 Clutch jaw Driver A (max) B (max) C (max) 1.1 mm 1.1 mm 1.5 mm Inspection of silencer Change or clean the filters regularly. Clogged filters will reduce power output. © Atlas Copco Industrial Technique AB - 9836 6515 00...
- Page 10 Spread a layer of grease on all sliding and impact surfaces. Use the rest of the grease, approximately half the amount, inside the cavity of the hammer and on the driver flange. Total grease amount 1ml. © Atlas Copco Industrial Technique AB - 9836 6515 00...
- Page 11 LMS08 SR42 Service Lubrication of motor parts Note No grease is needed for protected Ball bearings (ex. 2Z). • Where oil is needed, apply only a thin layer. • © Atlas Copco Industrial Technique AB - 9836 6515 00...
- Page 12 4200 rpm 16 mm (5/8”) LMS88 Skidmore-Wilhelm model K 2” 660 kN 3200 rpm 16 mm (5/8”) * = If Free speed is to low: check silencer for clogged filters. © Atlas Copco Industrial Technique AB - 9836 6515 00...
- Page 13 Spare parts Parts without ordering number are not delivered separately for technical reasons. The use of other than genuine Atlas Copco replacement parts may result in decreased tool performance and increased maintenance and may, at the company option, invalidate all warranties.
- Page 14 4150 0594 90 Valve, compl. 0663 6110 00 O-ring 3.1x1.6 0663 2111 00 O-ring 4.3x2.4 4150 0594 00 Valve 4210 0252 00 Spring 0663 9057 00 O-ring 9.2 X 1.8 © Atlas Copco Industrial Technique AB - 9836 6515 00...
- Page 15 Ø68 x 10 mmService tool for dismantling/ assembling of Motor bearings. For further information, pls see Service instructions Motor 4080 0206 07 Mandrel Ø55/65 mmService tool for dismantling/ assembling of Motor bearings. For further in- formation, pls see Service instructions © Atlas Copco Industrial Technique AB - 9836 6515 00...
- Page 16 4080 1358 00 For filling Impact mechanism with grease, see service instruction Suspension yoke Ref. No. Ordering No. Description Remark / Included in Service kit 4210 0243 00 Suspension yoke © Atlas Copco Industrial Technique AB - 9836 6515 00...
- Page 20 Atlas Copco Industrial © Copyright 2012, Atlas Copco Industrial Technique AB. All rights reserved. Any unauthorized use or copying of the contents or part thereof is prohibited. This Technique AB applies in particular to trademarks, model denominations, part numbers and SE-10523 STOCKHOLM drawings.
