- Page 1 D5032S - D5032D INSTRUCTION MANUAL SIL 3 Switch/Proximity Detector Repeater Relay Output, Termination Board Models D5032S, D5032D D5032 - SIL 3 Switch/Proximity Detector Repeater Relay Output G.M. International ISM0108-12...
-
Page 2: Technical Data
Current consumption @ 24 V: 35 mA for 2 channels D5032D, 18 mA for 1 channel D5032S with short circuit input and relay energized, typical. Power dissipation: 0.85 W for 2 channels D5032D, 0.45 W for 1 channel D5032S with 24 V supply voltage, short circuit input and relay energized, typical. -
Page 3: Terminal Block Connections
Ordering Information Model: D5032 1 channel 2 channels Front Panel and Features SIL 3 according to IEC 61508:2010 Ed. 2 for Tproof = 2 / 10 years (≤10% / >10 % of total SIF), considering 100 mA max contact current. ... - Page 4 Parameters Table In the system safety analysis, always check the Hazardous Area/Hazardous Locations devices to conform with the related system documentation, if the device is Intrinsically Safe check its suitability for the Hazardous Area/Hazardous Locations and group encountered and that its maximum allowable voltage, current, power (Ui/Vmax, Ii/Imax, Pi/Pi) are not exceeded by the safety parameters (Uo/Voc, Io/Isc, Po/Po) of the D5032 series Associated Apparatus connected to it.
- Page 5 Resistors R1 - R2 used with Termination Relay contact shown in voltage free contact required board connector de-energized position for line fault detection. Internal Dip switches programmable MODEL D5032S Supply 24 Vdc voltage free voltage free Proximity Contact Contact Out NO Contact (SIL 3) Termination...
-
Page 6: Operation
On the section “Function Diagram” and enclosure side a block diagram identifies all connections. Identify the number of channels of the specific card (e.g. D5032S is a single channel model and D5032D is a dual channel model), the function and location of each connection terminal using the wiring diagram on the corresponding section, as an example: For Model D5032S, in case of Proximity or Voltage free Contact, connect the wires at terminal “7”... -
Page 7: Dip Switch Configuration
Configuration D5032D used as double channel A configuration DIP switch is located on component side of pcb. This switch allows the configuration of input/output relationship, fault detection functions and operating mode. WARNING: dip-switch 6-7-8 must be set to “OFF” position. Dip switch factory settings. - Page 8 Configuration D5032D used as duplicator or fault output A configuration DIP switch is located on component side of pcb. This switch allows the configuration of input/output relationship, fault detection functions and operating mode. WARNING: Terminals 9-10 must be shorted to set module as Duplicator or Fault Out. Dip-switch 3 must be set to “OFF”...
- Page 9 Configuration D5032S A configuration DIP switch is located on component side of pcb. This switch allows the configuration of input/output relationship, fault detection functions and operating mode. WARNING: Dip-switch 7-8 must be set to “OFF” position. Dip switch factory settings. All Switches are OFF Dip switch configuration 7-8 must be set to "OFF"...
- Page 10 Configuration DIP Switch factory settings (valid for D5032S and D5032D) SW1 SW2 SW7 SW8 D5032D (used as double channel) Configuration Summary Table WARNING: dip-switch 6-7-8 must be set to “OFF” position. Channel Channel Line fault detection IN/OUT Operation Disabled NO-NE or NC-ND...
