Solas LGS-48 Installation Manual

Direct vent log set kit

Advertisement

Quick Links

FORTY8
DIRECT VENT LOG SET KIT
PART #: LGS-48
INSTALLATION MANUAL
ONLY FOR USE ON SÓLAS MODELS: 48N-SSL, 48N-SSR, 48N-ST
WARNING
This log set kit shall be installed by a qualified service agency in accordance with
the manufacturer's instructions and all applicable codes and requirements of the
Authority Having Jurisdiction. If the information in these instructions is not
followed exactly, a fire, explosion or production of carbon monoxide may result
causing property damage, personal injury or loss of life. The qualified service
agency is responsible for the proper installation of this kit. The installation is not
proper and complete until the operation of the converted appliance is checked as
specified in the manufacturer's instructions supplied with the kit.
NOT FOR USE WITH VENT FREE OR OUTDOOR FIREPLACES
0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LGS-48 and is the answer not in the manual?

Questions and answers

Summary of Contents for Solas LGS-48

  • Page 1 FORTY8 DIRECT VENT LOG SET KIT PART #: LGS-48 INSTALLATION MANUAL ONLY FOR USE ON SÓLAS MODELS: 48N-SSL, 48N-SSR, 48N-ST WARNING This log set kit shall be installed by a qualified service agency in accordance with the manufacturer’s instructions and all applicable codes and requirements of the Authority Having Jurisdiction.
  • Page 2 LOG SET INSTALLATION Kit Contents: • (4) Ceramic Logs • (5) Ceramic Rocks • 1lb 3oz Lava Rock • Metal Logset burner Step #1 FIGURE 09 Install the 3-rock cluster on the 2 pins located just right of the pilot. (Figure Step #2 FIGURE 10 Install the center birch log by placing...
  • Page 3 LOG SET INSTALLATION Step #3 FIGURE 11 Install the second, smaller, 3-rock cluster on the pin located right of 3-rock cluster installed during step #8. Once the 3-rock cluster is sitting on the pin, rotate clockwise until the lower left rock touches the rear edge of the burner.
  • Page 4 LOG SET INSTALLATION Step #6 FIGURE 14 Between the rock installed during step #12 and the center birch log are 4 pins located in close proximity to each other. Place the first of the 2 individual rocks on the left set of pins. Look for a gap between the front of the rock and the leading edge of the burner, if the rock overhangs the front of the burner the incorrect...
  • Page 5 LOG SET INSTALLATION Step #9 FIGURE 17 Evenly distribute the included 1lb and 3oz of lava rock on the exposed burner top. Cover the burner top completely but do not compress or “pack” the lava rock tightly. Pay special attention to tight and hard to reach areas when placing the media on the burner.
  • Page 6 LOG SET INSTALLATION Installation is now complete, refer to the FORTY6 owner’s manual for instructions on final assembly and lighting of the appliance.
