Solas ONE6 Installation Manual
Direct vent log set kit
Hide thumbs
Also See for ONE6:
- Installation manual (6 pages) ,
- Installation manual (4 pages) ,
- Installation & operation manual (56 pages)
Advertisement
Quick Links
ONE6
DIRECT VENT LOG SET KIT
PART #: LGS-16
INSTALLATION MANUAL
ONLY FOR SÓLAS MODELS: SL-16N, SL-16P
WARNING
This log set kit shall be installed by a qualified service agency in accordance with
the manufacturer's instructions and all applicable codes and requirements of the
Authority Having Jurisdiction. If the information in these instructions is not
followed exactly, a fire, explosion or production of carbon monoxide may result
causing property damage, personal injury or loss of life. The qualified service
agency is responsible for the proper installation of this kit. The installation is not
proper and complete until the operation of the converted appliance is checked as
specified in the manufacturer's instructions supplied with the kit.
NOT FOR USE WITH VENT FREE OR OUTDOOR FIREPLACES
0
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Solas ONE6
Summary of Contents for Solas ONE6
- Page 1 ONE6 DIRECT VENT LOG SET KIT PART #: LGS-16 INSTALLATION MANUAL ONLY FOR SÓLAS MODELS: SL-16N, SL-16P WARNING This log set kit shall be installed by a qualified service agency in accordance with the manufacturer’s instructions and all applicable codes and requirements of the Authority Having Jurisdiction.
- Page 2 LOG SET INSTALLATION Kit Contents: • (1) Ceramic Log • (1) Ceramic Rock • 7oz Lava Rock • Metal Logset burner top • Burner Top Gasket Step #1 FIGURE 01 Your fireplace will have shipped from the factory with the Glass Media burner top in place, before installing the logset burner top, we need to remove the glass burner top.
- Page 3 LOG SET INSTALLATION Step #4 Align the burner top gasket on the burner base as shown, check that all holes in the gasket are FIGURE 04 aligned with the holes in the burner base as shown in figure 04. Step #5 Align the burner top on the burner top gasket FIGURE 05 as shown in figure 05, check that all holes in the...
- Page 4 LOG SET INSTALLATION With the burner top installed, the fireplace is now ready to have the Ceramic Log Set installed. Step #7 Install the 3-rock cluster on the 2 pins located just right of the pilot. (Figure 07) FIGURE 07 Step #8 Install the center birch log by placing the left side of the log on the locating pin left of the pilot.
- Page 5 It is ok if small amounts of lava rock are lost over the edge of the burner. (Figure 09) FIGURE 09 Installation is now complete, refer to the ONE6 owner’s manual for instructions on final assembly and lighting of the appliance.
