SEVENTY2
DIRECT VENT LOG SET KIT
PART #: LGS-72
INSTALLATION MANUAL
ONLY FOR USE ON SÓLAS MODELS: 72N-SSL, 72P-SSR, 72N-ST, 72P-SSL, 72P-SSR, 72P-ST
WARNING
This log set kit shall be installed by a qualified service agency in accordance with
the manufacturer's instructions and all applicable codes and requirements of the
Authority Having Jurisdiction. If the information in these instructions is not
followed exactly, a fire, explosion or production of carbon monoxide may result
causing property damage, personal injury or loss of life. The qualified service
agency is responsible for the proper installation of this kit. The installation is not
proper and complete until the operation of the converted appliance is checked as
specified in the manufacturer's instructions supplied with the kit.
NOT FOR USE WITH VENT FREE OR OUTDOOR FIREPLACES
0
Advertisement
Related Manuals for Solas SEVENTY2 LGS-72
Summary of Contents for Solas SEVENTY2 LGS-72
- Page 1 SEVENTY2 DIRECT VENT LOG SET KIT PART #: LGS-72 INSTALLATION MANUAL ONLY FOR USE ON SÓLAS MODELS: 72N-SSL, 72P-SSR, 72N-ST, 72P-SSL, 72P-SSR, 72P-ST WARNING This log set kit shall be installed by a qualified service agency in accordance with the manufacturer’s instructions and all applicable codes and requirements of the Authority Having Jurisdiction.
- Page 2 LOG SET INSTALLATION Kit Contents: • (5) Ceramic Logs • 2lb 0oz Lava Rock • (6) Ceramic Rocks • Metal Logset burner set Figure 01 - Burner Support locations Step #1 Your fireplace will have shipped from the factory with the Glass Media burners in place, before installing the logset burners, we need to remove the glass burners.
- Page 3 LOG SET INSTALLATION Step #3 To remove the right burner, remove the 6 sheet metal screws securing the right burner, these screws are identified by the 6 arrows below. Once all hardware has been removed, slide the burner to the right and lift the burner out of the fireplace. Figure 03 Step #5 Once the glass media burner has been removed, locate the Logset burner included in the kit LGS-72 and...
- Page 4 LOG SET INSTALLATION Step #6 Install the left logset burner within the firebox by lowering the burner into the firebox.(while keeping the burner pressed toward the left side of the firebox) then sliding the burner right towards the center of the firebox to engage the burner orifice.
- Page 5 LOG SET INSTALLATION Step #9 Install the 3-rock cluster on the 2 pins located at the far left of the firebox as shown in figure 09. Figure 09 Step #10 Install these two rocks shown in figure 10 on the pins slightly to the right of the 3-rock cluster you installed in step 9.
- Page 6 LOG SET INSTALLATION Step #12 Install the 3-rock cluster shown in figure 12 to the right of the cluster installed in step 11. Figure 12 Step #13 Install the middle birch log set by placing the right side of the log on the 3-rock cluster you installed in step #11.
- Page 7 LOG SET INSTALLATION Step #14 Install the log shown in figure 14 with the left side resting on the 3-rock cluster you installed in step 9. The right side of the log rests on the burner as shown located by a pin. Figure #14 Step #15 Install the log shown in figure 15 with the right side resting on the 2 rocks installed in step 10.
- Page 8 LOG SET INSTALLATION Step #16 Install the log shown in figure 16 with the left side resting on the 3-rock cluster installed in step 12. The rock is located by a single pin and aligned parallel to the front edge of the burner. The log rests on the rock as shown, the right side is located by 2 pins on the burner.
- Page 9 LOG SET INSTALLATION Step #18 Evenly distribute the included 2lb and 0oz of lava rock on the exposed burner top. Cover the burner top completely but do not compress or “pack” the lava rock tightly. Pay special attention to tight and hard to reach areas when placing the media on the burner.
