FORTY6 Slim-Line Built-In
DIRECT-VENT LOG SET KIT
PART: LGS-46BI
INSTALLATION MANUAL
ONLY FOR USE ON SÓLAS MODEL: 46N-BICZ
SÓLAS BIRCH LOG SET KIT
WARNING
This log set kit shall be installed by a qualified service agency in
accordance with the manufacturer's instructions and all applicable
codes and requirements of the Authority Having Jurisdiction. If
the information in these instructions is not followed exactly, a fire,
explosion or production of carbon monoxide may result causing
property damage, personal injury or loss of life. The qualified
service agency is responsible for the proper installation of this kit.
The installation is not proper and complete until the operation of the
converted appliance is checked as specified in the manufacturer's
instructions supplied with the kit.
NOT FOR USE WITH VENT-FREE OR OUTDOOR FIREPLACES
INSTALLER: Leave this manual with appliance | CONSUMER: Retain this manual for future reference
1
solasfires.com
Advertisement
Table of Contents
Related Manuals for Solas FORTY6 LGS-46BI
Summary of Contents for Solas FORTY6 LGS-46BI
- Page 1 FORTY6 Slim-Line Built-In DIRECT-VENT LOG SET KIT PART: LGS-46BI INSTALLATION MANUAL ONLY FOR USE ON SÓLAS MODEL: 46N-BICZ SÓLAS BIRCH LOG SET KIT WARNING This log set kit shall be installed by a qualified service agency in accordance with the manufacturer’s instructions and all applicable codes and requirements of the Authority Having Jurisdiction.
- Page 2 LOG SET INSTALLATION SÓLAS BIRCH LOG SET KIT CONTENTS: • (4) CERAMIC LOGS • 1 lb. 3oz. LAVA ROCK • (5) CERAMIC ROCKS S Ó L AS CO N T E MP OR ARY F IRE...
- Page 3 LOG SET INSTALLATION INTALLATION OF BIRCH LOG SET STEP 1 Install the 3-rock cluster on the 2 pins located just right of the pilot. (Figure 1) Figure 1 STEP 2 Install the center birch log by placing the left side of the log on the locating pin left of the pilot.
- Page 4 LOG SET INSTALLATION STEP 5 Install the single rock on the 2 pins located on the far left of the burner top. The log-locating tab on top of the rock should be toward the back of the burner. (Figure 5) Figure 5 STEP 6 Between the rock installed during Step 5 and...
- Page 5 LOG SET INSTALLATION STEP 9 Evenly distribute the included 1lb and 3oz of Lava Rock on the exposed burner top. Cover the burner top completely but do not compress or “pack” the lava rock tightly. Pay special attention to tight and hard to reach areas when placing the media on the burner.
- Page 6 We recommend that our gas hearth products be installed and serviced by professionals who are certified in the U.S. by the National Fireplace Institute® (NFI) as NFI Gas Specialists. www.NFIcertified.org RECORD YOUR PRODUCT INFORMATION Model #: ________________________ Serial Number: ______________________________ Date Purchased: __________________ Date Installed: _______________________________ THANK YOU FOR CHOOSING solasfires.com...
