ONE6

CORNER KIT

PART: CK-16-1

INSTALLATION MANUAL

ONLY FOR USE ON SÓLAS MODELS: SL-16N, SL-16P

When installing the SÓLAS-ONE6 Wall-Mount with Corner Install Kit, you will need to refer

to both this manual and the Installation & Operation's Manual supplied with the fireplace.

SÓLAS ONE6 CORNER KIT

NOTE: A 12" straight section of Direct Vent Pipe will be required to

complete the corner installation.

INSTALLER: Leave this manual with appliance | CONSUMER: Retain this manual for future reference

solasfires.com

Need help?

Do you have a question about the ONE6 and is the answer not in the manual?

Page 1 INSTALLATION MANUAL ONLY FOR USE ON SÓLAS MODELS: SL-16N, SL-16P When installing the SÓLAS-ONE6 Wall-Mount with Corner Install Kit, you will need to refer to both this manual and the Installation & Operation’s Manual supplied with the fireplace. SÓLAS ONE6 CORNER KIT NOTE: A 12"...
Page 2 Cut the vent outlet hole and gas inlet hole (refer to page 18 of the SÓLAS ONE6 Installation & Operation’s Manual). Pre-drill the 9 lag bolt holes with a 5/32” diameter drill. Be sure that there is solid wood at each mounting location.
Page 3 8. Fit the custom 45˚ vent starter pipe and gasket supplied Figure 5 with the Corner Kit to the SÓLAS ONE6 Fireplace BEFORE mounting the fireplace to the wall mount. Mount the unit on the wall mount and complete the installation as described in the Installation &...
Page 4 We recommend that our gas hearth products be installed and serviced by professionals who are certified in the U.S. by the National Fireplace Institute® (NFI) as NFI Gas Specialists. www.NFIcertified.org RECORD YOUR PRODUCT INFORMATION Model #: ________________________ Serial Number: ______________________________ Date Purchased: __________________ Date Installed: _______________________________ THANK YOU FOR CHOOSING solasfires.com...
