Mindray PM-7000 Service Manual

Patient monitor

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

PM-7000

Patient Monitor

Service Manual

Table of Contents

Troubleshooting

Need help?

Do you have a question about the PM-7000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Mindray PM-7000

Page 1 PM-7000 Patient Monitor Service Manual...
Page 3 Mindray may also seek to maintain this work as an unpublished copyright. This publication is to be used solely for the purposes of reference, operation, maintenance, or repair of Mindray equipment.
Page 4 Once being polluted by liquid, they must be thoroughly dried. If to further remove the pollution, please contact your biomedical department or Mindray. It is important for the hospital or organization that employs this equipment to carry out a reasonable maintenance schedule.
Page 5 ■ assembly operations, extensions, re-adjusts, modifications or repairs are carried out by persons other than those authorized by Mindray. ■ the PM-7000 is not used in accordance with the instructions for use, or the electrical installation of the relevant room does not comply with NFPA 70: National Electric...
Page 6 Service Manual Return Policy Return Procedure In the event that it becomes necessary to return a unit to Mindray, the following procedure should be followed: Obtain return authorization. Contact the Mindray Service Department and obtain a Customer Service Authorization (Mindray) number. The Mindray number must appear on the outside of the shipping container.
Page 7 Service Manual Safety Precautions 1. Meaning of Signal Words DANGER, WARNING , and In this manual, the signal words are used CAUTION regarding safety and other important instructions. The signal words and their meanings are defined as follows. Please understand their meanings clearly before reading this manual. Signal word Meaning Indicates an imminently hazardous situation which, if not...
Page 8 Service Manual current at power ON, the circuit breakers and fuses of the building’s supply circuit may be tripped. CAUTION: Malfunctions due to radio waves (1) Use of radio-wave-emitting devices in the proximity of this kind of medical electronic system may interfere with its operation.
Page 9 Service Manual Symbols Equipotential grounding CE mark 93/42/EEC a terminal directive of the European Economic Community Be Careful Protective earth ground Direct current and alternating Direct current (DC) current (DC&AC) Alternating current (AC) Battery indicator ESD sensitivity Power ON/OFF Network connector High voltage Indicates that the instrument is IEC-60601-1 Type CF equipment.
Page 10: Table Of Contents
Service Manual Contents Chapter 1 About the Product .....................1 Introduction........................1 Application ........................1 1.2.1 General ........................1 Environment ........................3 1.3.1 Temperature......................3 1.3.2 Humidity ........................3 1.3.3 Electrical specification ....................3 Chapter 2 Principles........................4 General ..........................4 2.1.1 Parameter Measurement....................5 2.1.2 Main Control Part......................5 2.1.3 Man-Machine Interface .....................5 2.1.4 Power Supply ......................5 2.1.5...
Page 11 Specifications...................42 1.1.6. Welch Allyn CO Specifications ...................43 3.16 AG Specifications .......................44 Chapter 4 Disassembling/Assembling & Troubleshooting .............47 PM-7000 Disassembling/Assembling ................47 4.1.2 PM-7000 Support Assembly ..................48 4.1.3 Front Bezel Assembly ....................50 4.1.4 Rear Housing Assembly....................51 4.1.5 Microstream CO Assembly...................52 Troubleshooting ......................53 4.2.1 Black Screen, Startup Failure ...................53...
Page 12 5.3 IBP CALIBRATE......................59 5.4 CO2 CHECK........................62 5.5 AG CALIBRATE .........................64 5.5.1 AG Check........................64 5.5.2 AG CALIBRATE ......................65 Bill of Materials for PM-7000 Main Unit ...............66 Chapter 6 Maintenance and Cleaning .....................67 6.1 Maintenance ..........................67 6.1.1Checking Before Using ....................67 6.1.2 Regular Checking......................67 Cleaning ..........................67...
Page 13: Chapter 1 About The Product
You can select different configurations as required. Besides, the PM-7000 can be connected with the central monitoring system whereby a monitoring network will be formed. Parameters that the PM-7000 can monitor include: ECG, RESP, SpO , NIBP, 2-channel TEMP, 2-channel IBP, CO, CO and AG.
Page 14 ICU, CCU, intensive care units for heart disease patients, operating rooms, emergency departments and observation wards. They can also be used in clinics. The PM-7000 should be run under the control of clinical staff. PM-7000 has the following functions:...
Page 15: Environment
Minimum Alveolar Concentration (MAC) 4 AG waveforms (CO O, O , AA) The PM-7000 provides the functions of audio/visual alarm, trend graphic storage and output, NIBP measurement, alarm event identification, large font screen, defibrillator synchronization, oxyCRG recall, drug calculation, etc. 1.3 Environment 1.3.1...
Page 16: Chapter 2 Principles
Chapter 2 Principles Chapter 2 Principles General The intended use of the PM-7000 is to monitor a fixed set of parameters including ECG, RESP, , NIBP, TEMP, IBP, CO and CO (IBP, CO and CO are optional). It consists of the following functional parts: Parameter measurement;...
Page 17: Parameter Measurement
2.1.2 Main Control Part In the PM-7000, the main control part refers to the main control part of the main control board. It drives the man-machine interface, manages the parameter measurement and provides users with other special functions, such as storage, recall of waveforms and data. (See Figure 2-1) 2.1.3...
Page 18: Hardware Description
Chapter 2 Principles Hardware Description The structure of the PM-7000 is shown in the following figure. Figure 2-2 Functional structure of the PM-7000...
Page 19: Main Board
Chapter 2 Principles The PM-7000 PCB connection is shown in the following figure. Figure 2-3 PCB connection Basic functions and working principles of modules are described in the following sections. 2.2.1 Main Board 2.2.1.1 General The main board is the heart of the patient monitor. It implements a series of tasks, including the system control, system scheduling, system management, data processing, file management, display processing, printing management, data storage, system diagnosis and alarm.
Page 20 Chapter 2 Principles 2.2.1.2 Principle diagram Figure 2-4 Working principle of the main board 2.2.1.3 Principle The main board is connected with external ports, including the power input port, multi-way serial port, TFT display interface, analog VGA interface, network port and analog output port. Besides, on the main board is also a BDM interface reserved for the software debugging and software downloading.
Page 21: Ecg/Resp/Temp Module
Chapter 2 Principles In addition, FPGA also extends multiple serial ports, which communicate with peripheral modules. FPGA transfers the received data to CPU through the bus; CPU delivers data to FPGA through the bus, and then the FPGA transfers those data to the peripheral modules.
Page 22 Chapter 2 Principles rejects the common-mode interference signal. The low-pas filtering circuit filters the high-frequency interference signal beyond the frequency band of the ECG signal. The PACE signal refers to the ECG pace signal. It has significant interference to the ECG signal detection.
Page 23: Co/Ibp Module
Chapter 2 Principles 2.2.3 CO/IBP Module 2.2.3.1 General This module provides the function of measuring two parameters: Cardiac Output (CO) and Invasive Blood Pressure (IBP). 2.2.3.2 Principle diagram Figure 2-6 Working principle of the CO/IBP module 2.2.3.3 Principle This module collects the CO/IBP signal through the transducers, processes it and sends it to the main board throgh the serial port.
Page 24: Spo 2 Module
Chapter 2 Principles 2.2.4 Module 2.2.4.1 General This module provides the function of measuring the Pulse Oxygen Saturation (SPO 2.2.4.2 Principle diagram Figure2-7 Working principle of the SpO module 2.2.4.3 Principle The SpO measurement principle Collecting the light signal of the red light and infrared transmitting through the finger or toe which is pulsing;...
Page 25: Nibp Module
Chapter 2 Principles CPU System Implementing the logical control of all the circuits; Implementing the data processing for the SpO parameter; Implementing the communication with the main board. Power & Signal isolate Circuit Isolating the external circuits to ensure the safety of human body; Supplying power for all circuits;...
Page 26: Recorder Module
Chapter 2 Principles Valve Drive Circuit This circuit controls the status (ON/OFF) of valves. It, together with the Motor Drive Circuit, implements the inflation and deflation of the cuff. Motor Drive Circuit This circuit controls the action of the air pump. It, together with the Valve Drive Circuit, implements the inflation and deflation of the cuff.
Page 27: Button Panel
Chapter 2 Principles 2.2.6.3 Principle This module receives the to-be-printed data from the main board, converts them to the dot matrix data, sends them to the heat-sensitive printer, and drives the printer. Step Motor Drive Circuit There is a step motor on the heat-sensitive printer. The step motor drives the paper. This circuit is used to drive the step motor.
Page 28: Power Pcb
Chapter 2 Principles Detecting the input signal of the button panel and control knob; Controlling the status of LED; Controlling the audio process circuit; Regularly resetting the Watchdog timer; Communicating with the main board. Audio Process Circuit This circuit generates audio signals and drives the speaker. Watchdog When powered on, the Watchdog provides the reset signal for CPU.
Page 29: Software Description
Chapter 2 Principles 5V DC/DC This part converts the DC voltage to the stable 5V DC voltage and supplies it for the external boards. 12V DC/DC This part converts the DC voltage to the stable 12V DC voltage and supplies it for the external boards.
Page 30: System Task
Chapter 2 Principles 2.3.2 System Task Task Function Period In case of a System initialization Initializing the system startup Data processing Analyzing and saving the data 1 second Display timer Implementing the timed refreshing 1 second information In case of a Switchover of modules Switching over between waveforms and screen change...
Page 31: System Function
Chapter 2 Principles 2.3.3 System Function The system tasks can be classified as follows. Figure 2-13 System task...
Page 32: System Parameter
2.4.1 General For the PM-7000, signals are collected by modules, and the results are transferred to the main board through the adapter board, thus to process and display the data and waveforms. Commands from the main board, as well as the status information of modules, are transferred through the adapter board.
Page 33: Nibp
■ RESP The PM-7000 measures the RESP based on the impedance principle. While a man is breathing, the action of the breast leads to impedance changes between RL and LL. Change the high-frequency signal passing the RL and LL to amplitude-modulation high-frequency signal (AM high-frequency signal), which is converted to the electric signal after being detected and amplified and then sent to the A/D converter.
Page 34: Spo
Chapter 2 Principles pressure can be obtained. For neonates, pediatric and adults, it is necessary to select the cuffs of a proper size to avoid possible measurement errors. In the NIBP measurement, there is a protection circuit used to protect patient from over-high pressure.
Page 35: Co 2
Chapter 2 Principles Measurement principle: Introduce a catheter, of which the external end is connected to the pressure transducer, into the blood vessel under test, inject the physiological saline. Since the liquid can be transferred by pressure, the pressure inside the blood pressure is transferred by liquid to the pressure transducer, and the dynamic waveform of the pressure inside the blood pressure is obtained in real time.
Page 36 Chapter 2 Principles Send the gas to be measured to a sampling chamber; Use an optical infrared filter, select a specific band of infrared, and transmit it through the gas; Measure the infrared that gets through the gas to obtain the gas concentration. For a given volume, the higher the gas concentration is, the more absorbed infrared is, and the less the infrared that gets through the gas is.
Page 37: Chapter 3 Product Specifications
Chapter 3 Product Specifications Chapter 3 Product Specifications 3.1 Safety Classifications Class I with internal electric power supply. Type of protection against Where the integrity of the external protective earth (ground) in electric shock the installation or its conductors is in doubt, the equipment shall be operated from its internal electric power supply (batteries) Monitor: Degree of protection...
Page 38: Environmental Specifications
Chapter 3 Product Specifications 3.2 Environmental Specifications 0 to 40℃ 5 to 35℃ (With Mindray CO module) Operating temperature 10 to 35℃ (With Welch Allyn CO module) 5 to 35℃ (With Oridion CO module) 10 to 35℃ (With AION AG module)
Page 39: Power Source Specifications
Chapter 3 Product Specifications 3.3 Power Source Specifications AC mains Input voltage 100 to 240V Frequency 50/60Hz Power 140VA DC mains Input voltage 10 to 16VDC（rating-12 VDC） Power Internal battery Number of batteries Type Sealed lead-acid battery or lithium-ion battery Time to shutdown 5 to 15min (after the first low-power alarm) Sealed lead-acid battery...
Page 40: Hardware Specifications
Chapter 3 Product Specifications 3.4 Hardware Specifications Physical Size 310 × 280 × 150mm (width×height×depth) Different due to different configurations Weight Standard configuration: 5.5kg Display Type Color TFT LCD Size 10.4 inches (diagonal) Resolution 800×600 pixels Recorder Type Thermal dot array Horizontal resolution 160 dots/cm (at 25 mm/s recording rate) Vertical resolution...
Page 41: Wireless Network
Chapter 3 Product Specifications 7 buttons: POWER, MAIN, FREEZE, SILENCE, RECORD, Button NIBP, MENU Connectors 1 AC power connector Power supply 1 DC power connector Parameter ECG, RESP, TEMP, SPO2, NIBP, IBP, CO, CO2, AG Network 1 standard RJ45 network connector, 100 BASE-TX 1 standard color VGA monitor connector, 15-PIN D-sub Auxiliary output 1 BNC connector...
Page 42: Data Storage
Chapter 3 Product Specifications 3.6 Data Storage Long trend: 96 hours, resolution 1min, 5 min or 10 min. Trend data Short trend: 1 hour, resolution 1 s or 5 s. 70 alarm events and associated waveforms (with user Alarm events selectable waveform length 8s, 16 or 32).
Page 43: Signal Output Specifications
Chapter 3 Product Specifications 3.7 Signal Output Specifications Meets the requirements of EC60601-1 for short-circuit Standards protection and leakage current Output impedance 50Ω ECG analog output Diagnostic mode: 0.05 to 100Hz(12-lead: 0.05 to Bandwidth 150Hz) (-3dB; reference Monitor mode: 0.5 to 40Hz frequency: 10Hz) Surgery mode: 1 to 20Hz...
Page 44: Ecg Specifications
Chapter 3 Product Specifications 3.8 ECG Specifications 3-lead (1 channel): I, II, III Lead type 5-lead (2 channels): I, II, III, aVR, aVL, aVF and V 12-lead (8 channels): I, II, III, avR, avL, avF, V1-V6 Lead naming style AHA, EURO 1.25mm/mV (×0.125), 2.5mm/mV (×0.25), 5mm/mV (×0.5), Sensitivity selection 10mm/mV (×1), 20mm/mV (×2) and auto...
Page 45 Chapter 3 Product Specifications Meets the requirement of ANSI/AAMI EC13-2002: Section 4.1.2.1 f). Response time to heart rate Less than 11 sec for a step increase from 80 to 120 BPM changes Less than 11 sec for a step decrease from 80 to 40 BPM When tested in accordance with ANSI/AAMI EC13-2002 Section 4.1.2.1 g, the response time is as follows.
Page 46: Resp Specifications
Chapter 3 Product Specifications 3.9 RESP Specifications Measurement technique Thoracic impedance Lead Optional: lead I and lead II; default lead II Differential input > 2.5MΩ impedance Respiration impedance test 0.3 to 3Ω range Excitation current < 300µA Baseline impedance range 200 to 2500Ω...
Page 47: Spo Specifications
Chapter 3 Product Specifications 3.10 SpO Specifications 1.1.1. Mindray SpO Module Measurement range 0 to 100% Resolution 70 to 100%: ±2 % (adult/pediatric, non-motion conditions) 70 to 100%: ±3 % (neonate, non-motion conditions) Precision 70 to 100%: ±3 % (in motion conditions) 0% to 69%: Undefined.
Page 48: Nellcor Spo 2 Specifications
Chapter 3 Product Specifications Measurement range 25 to 240bpm Resolution 1bpm ±3bpm (non-motion conditions) Precision ±5bpm (in motion conditions) Refreshing rate 1.1.3. Nellcor SpO Specifications Sensor Range Precision* 70 to 100% ±2% MAX-A, MAX-AL, MAX-N, MAX-P, MAX-I and MAX-FAST 0% to 69% Undefined 70 to 100% ±2.5%...
Page 49: Ibp Specifications
Chapter 3 Product Specifications 3.11 IBP Specifications Measurement technique Auto oscillation Displayed parameters Systolic pressure, diastolic pressure and mean pressure Mode of operation Manual, auto and continuous Measurement interval in 1/2/3/4/5/10/15/30/60/90/120/180/240/480 minutes auto mode Measurement time in 5 minutes continuous mode mmHg Adult Pediatric...
Page 50: Temp Specifications
Chapter 3 Product Specifications 3.12 TEMP Specifications Number of channels Displayed parameters T1, T2 and TD Measurement range 0 to 50°C (32 to 122°F) Resolution 0.1°C 0.1°C (excluding the sensor) Precision ±0.2°C (including the YSI 400 series sensor) Update period Body surface: <...
Page 51: Ibp Specifications
Chapter 3 Product Specifications 3.13 IBP Specifications Number of channels Pressure labels ART, PA, CVP, RAP, LAP, ICP, P1 and P2 0 to 300 mmHg – 6 to 120 mmHg Measurement range CVP/RAP/LAP/ICP – 10 to 40 mmHg P1/P2 – 50 to 300 mmHg Resolution 1 mmHg Precision...
Page 52: Co Specifications
Chapter 3 Product Specifications 3.14 CO Specifications Measurement technique Thermal dilution Calculated parameter CO, hemodynamics 0.1 to 20l/min Measurement range 23 to 43°C 0 to 27°C 0.1 l /min Resolution 0.1°C TB, TI: ±5% or ± 0.1 l /min Precision 0.1°C TB, TI: Alarm range...
Page 53: Co Specifications
Infrared absorption technique Measurement mode Sidestream, microstream or mainstream (optional) Displayed parameter EtCO2, FiCO2, Respiration Rate CO2 function Meet the requirements of EN864 and ISO9918. 1.1.4. Mindray CO Specifications CO2 measurement range 0 to 99mmHg 0 to 40 mmHg: ±2mmHg Precision* 41 to 76 mmHg: ±5%...
Page 54: Oridion Co Specifications
Chapter 3 Product Specifications * Conditions for measurements in typical precision: The measurement is started after the preheating mode of the module; Ambient pressure: 750mmHg to 760mmHg; room temperature: 22 to 28 ; ℃ ℃ The gas under test is dry, and the balance gas is N2; The deflation rate is 150ml/min, the respiration rate is no greater than 30BrPM, with a fluctuation less than ±3BrPM, and the inhale interval/exhale interval is 1:2;...
Page 55: Welch Allyn Co
Chapter 3 Product Specifications 1.1.6. Welch Allyn CO Specifications CO2 measurement range 0 to 99mmHg 0 to 40 mmHg: ±2mmHg Precision* 41 to 76 mmHg: ±5% 77 to 99 mmHg: ±10% Resolution 1mmHg Refreshing rate < 80s (ambient temperature: 25 ; preheating power of ℃...
Page 56: Ag Specifications
Chapter 3 Product Specifications 3.16 AG Specifications Measurement technique Infrared absorption Measurement mode Side stream Meets requirements of ISO9918, ISO11196, EN12598 and AG functions ISO7767 45 seconds (warming-up status) Warm-up time 10 minutes (ready-to-measure status) Adult/Pediatric 120, 150, 200 ml/minute (user-selectable) Sampling flow (sidestream) Neonatal...
Page 57 Chapter 3 Product Specifications ±0.4 5 to 10 ±0.6 10 to 15 ±1 15 to 18 >18 Not specified ±0.15 0 to 1 ±0.2 1 to 5 ±0.4 5 to 8 > 8 Not specified ±0.15 0 to 1 ±0.2 Enf, Iso, Hal 1 to 5 >...
Page 58 Chapter 3 Product Specifications line (2.5m) 350 ms Delay time < 4s...
Page 59: Chapter 4 Disassembling/Assembling & Troubleshooting
Chapter 4 Disassembling/Assembling & Troubleshooting Chapter 4 Disassembling/Assembling & Troubleshooting 4.1 PM-7000 Disassembling/Assembling 4.1.1 Exploded View of PM-7000 Figure 4-1 Exploded view of PM-7000 Material code Part & Specification Quantity 7001-30-67413 Front bezel assembly 0000-10-10876 Hose (φ1.5mm) 0.33 7001-30-67452 Main support assembly...
Page 60: Pm-7000 Support Assembly
Chapter 4 Disassembling/Assembling & Troubleshooting 4.1.2 PM-7000 Support Assembly Figure 4-2 PM-7000 support assembly Material Code Part & Specification Quantity 0000-10-11021 LCD, TFT, 10.4 inch 7000-20-24508 LCD pad, AU M04-051137--- Stainless steel cross head screw M2×4 7000-20-24540 LCD support, LG M04-002405--- Cross head screw M2×6...
Page 61 Chapter 4 Disassembling/Assembling & Troubleshooting 9300-20-13901 Backlight insulation plate 8000-20-10214 IBP insulation plate M03A-30-26050 CO/IBP board 7000-20-24418 Insulation plate for main board 7000-30-24425 Battery rack assembly 7000-30-24424 Socket assembly DA8K-20-14426 SPO2 mount 9006-30-33900 9006 SPO2 board 812A-30-08569 812A ECG board assembly M04-060009--- Bolt M3×14 7001-20-67403...
Page 62: Front Bezel Assembly
Chapter 4 Disassembling/Assembling & Troubleshooting M02A-20-25909 Communication wire to CO module 7000-20-24444 Communication wire to IBP module 7000-20-24439 Communication wire to power board 7000-20-24438 Power cord 7000-20-24500 Signal wire to recorder 7000-20-24443 Communication wire to NIBP board 9200-21-10454 TFT connecting wire 4.1.3 Front Bezel Assembly Figure 4-3 Front bezel assembly Description...
Page 63: Rear Housing Assembly
Chapter 4 Disassembling/Assembling & Troubleshooting 7000-20-24356-51 Silicon button 7000-20-24368 Button fixture M04-003905--- Cross head tapping screw PT3×6 DA8K-20-14416 Connecting wires for encoder 7001-30-67441 Button board M04-003105--- Cross head tapping screw PT3×8 4.1.4 Rear Housing Assembly Figure 4-4 Rear housing assembly Description 7000-21-24435 Rear housing...
Page 64: Microstream Co Assembly
Chapter 4 Disassembling/Assembling & Troubleshooting 9200-20-10622 Mounting plate M04-003105--- Cross head tapping screw PT3×8 7000-20-24377 Cushion 4.1.5 Microstream CO Assembly Figure 4-5 Microstream CO assembly Material Code Part & Specification 9201-30-35959 Microstream CO connector M04-003105--- Cross-head self-tapping screw 3*8 9201-20-36010 Baffle of torsional spring 9201-20-35961 Retaining torsional spring of microstream CO...
Page 65: Troubleshooting
Chapter 4 Disassembling/Assembling & Troubleshooting 4.2 Troubleshooting 4.2.1 Black Screen, Startup Failure Figure 4-6 Location flow of faults causing black screen...
Page 66: White Screen & Other Abnormal Screen
Chapter 4 Disassembling/Assembling & Troubleshooting 4.2.2 White Screen & Other Abnormal Screen In case of faults causing white screen or other abnormal screens, Check whether the LCD connection wires are in good contact; ■ Replace the LCD connection wires, or replace the LCD if necessary; ■...
Page 67: Chapter 5 Test And Material List
Then, the patient monitor displays the start-up screen on the TFT screen and enters the system screen. 5.1.2 Functions of Buttons Press every button on the button panel to check their functions as specified in PM-7000 Patient Monitor Operation Manual. Rotate the control knob to check its functions. 5.1.3 ECG/RESP The TFT screen displays the standard ECG waveform, and the error between the heart rate and the set value of the simulator is no more than ±1, namely 60±1;...
Page 68: Temperature
Set the blood pressure to the 255/195/215 mmHg level, SHIFT to +15, and the HR to 80BPM. Set PM-7000 to the adult mode. Press <START>. Then the results will be obtained in about 30s. The measured results should be respectively 270±8mmHg, 210±8mmHg and 230±8mmHg.
Page 69 200mmHg. Then the screen of the PM-7000 should display 40±1mmHg, 100±2mmHg and 200±4mmHg. Set the simulator output to ART wave. Then the screen of the PM-7000 should display relevant waveform properly. Unplug the IBP probe. Then the screen should prompt “IBP: Transducer 1 OFF!”...
Page 70: Recorder
Chapter 5 Test and Material List the valve is opened permanently, the patient monitor prompts “APNEA ALARM”. Unplug the water trap. The patient monitor prompts “CO water trap OFF”. Plug the water trap again. The prompting message disappears. When the measured value exceeds the high limit of CO , the patient monitor ③...
Page 71: Nibp Calibration
Chapter 5 Test and Material List 5.2 NIBP Calibration Figure 5-1 NIBP Calibration Calibration method: Based on the precision of 50mmHg (6.7kPa), increase the pressure step by step. The maximum error at any pressure point within the NIBP measurement range of the patient monitor should be no more than ±3mmHg (±0.4kPa).
Page 72 Chapter 5 Test and Material List Zero Calibration of Transducer Select CH1, the system will zero IBP1. Select CH2, the system will zero IBP2. Cautions:( Use the PM-6000 IBP module as a example) Turn off patient stopcock before you start the zero procedure. The transducer must be vented to atmospheric pressure before the zero procedure.
Page 73 Turn the knob to select the item CH2 CAL VALUE, press and turn the knob to select the pressure value to be calibrated for channel 2. Then turn the knob to select the item CALIBRATE to start calibrating channel 2. The pressure calibration of PM-7000: Pressure transducer...
Page 74: Co2 Check
5.4 CO2 CHECK Check procedure for sidestream module only Via the PM-7000’s system and maintain menus you are prompted for a password for entering the factory key. After entering the password you get access to the pump rate settings and to check the accuracy of the CO2 measurement.
Page 75 Chapter 5 Test and Material List Neither the mainstream nor the sidestream module can be calibrated. Only the Note overall performance and accuracy is checked. If the Co2 module fails the tests it should be replaced. Figure 5-7 Factory Maintain Menu Figure 5-8 CO2 check menu...
Page 76: Ag Calibrate
Chapter 5 Test and Material List 5.5 AG CALIBRATE 5.5.1 AG Check 1、 Using T-piece to connect the watertrap and Agent steel bottle well. One of the T-piece ports must be vented to atmospheric pressure. 2、Select ‘MEASURE’ from work mode item in “AG SETUP” menu, then set pump rate ‘low’ and wait for 10 minutes after the warm up information disappears.
Page 77: Ag Calibrate
Chapter 5 Test and Material List 5.5.2 AG CALIBRATE （Agent>1.5%, CO2>1.5%, N2O>40%, O2>40% ） 1、Press ‘START CAL’, then input password ‘MINDRAY’ entering ‘CALIBRATE’ menu. Note: Make sure the AG in ‘Measure’ mode not ‘Standby’ mode before you do calibrate. Figure 5-10 Figure 5-11 2、Input each gas concentration value according to the label on the AG bottle label.
Page 78: Bill Of Materials For Pm-7000 Main Unit
Chapter 5 Test and Material List 5.6 Bill of Materials for PM-7000 Main Unit Description Quantity M04-004012--- Cross-head screw M3*6 TR6C-30-16650 Recorder drive board 7000-20-24422 Main support (with lithium battery) M04-002505--- Cross-head screw M3*6 7001-30-67428 CF wireless network card module assembly...
Page 79: Chapter 6 Maintenance And Cleaning
All checks in which the patient monitor should be disassembled should be done by qualified maintenance personnel. The safety and maintenance checks can be done by Mindray engineers. The local office of Mindray at your region will be pleased to provide you with the information about the maintenance contract.
Page 80: Sterilization
Chapter 6 Maintenance and Cleaning 6.4 Sterilization To avoid the long-time damage to the patient monitor, we recommend you To conduct only sterilization which is considered necessary in your maintenance plan; To clean the patient monitor before the sterilization; To sterilize the patient monitor with specified sterilization agent: Ethylate, and Acetaldehyde.
Page 82 7001-20-67407(1.0) P/N:...
