- Page 1 8/16-Port 1U Rack-Mount 4K HDMI/USB 3.0 KVM Switch with Audio and Peripheral Sharing Models: B024-H4U08, B024-H4U16 A complete Owner’s Manual is available on Tripp Lite’s website: tripplite.com. WARRANTY REGISTRATION Register your product today and be automatically entered to win an ISOBAR ®...
-
Page 2: Product Features
Product Features • Control up to eight (B024-H4U08) or 16 (B024-H4U16) 4K HDMI computers and two USB 3.0 peripheral devices using one centralized monitor, keyboard and mouse. • Cascade up to three levels with the B024-H4U08 (control up to 512 computers) or two levels with the B024-H4U16 (control up to 256 computers). -
Page 3: Optional Accessories
Optional Accessories • P569-Series High Speed HDMI Cables • UR022-Series USB Reversible A/B Cables • P312-Series 3.5 mm Mini Stereo Audio Cables • P782-0XX-HA HDMI/USB/Audio Custom KVM Cable Kits* * P130-000 HDMI to DVI adapter sold separately. System Requirements Console • 4K HDMI-compliant monitor • USB Mouse/Keyboard • Speakers (Optional) Computers • Source with a 4K HDMI port •... -
Page 4: Front Panel
Introduction Front Panel Model B024-H4U08 8-PORT 4K HDMI Model: B024-H4U08 8-PORT 4K HDMI Model: B024-H4U08 Model B024-H4U16 16-PORT 4K HDMI Model: B024-H4U16 16-PORT 4K HDMI Key Component Description Model: B024-H4U16 Port For manual port selection*: Selection • Press a port selection pushbutton for less than two Pushbuttons seconds to bring the KVM, USB hub, and audio focus to the computer attached to its corresponding port. • Press a pushbutton for longer than two seconds to bring the KVM and audio selection to the computer attached to its corresponding port. - Page 5 Introduction Key Component Description Port LEDs The Port LEDs are built into the Port Selection Switches. The KVM Port LEDs are on the left. The USB LEDs are on the right. • Illuminates dim orange to indicate the computer attached to the corresponding port is up and running (On-Line). • Flashes to indicate Firmware Upgrade mode is in effect. • Illuminates bright orange to indicate the computer connected to the corresponding port has the KVM focus (Selected).
-
Page 6: Rear Panel
Introduction Rear Panel (Model B024-H4U08 shown) CPU 8 CPU 7 CPU 6 CPU 5 CPU 4 CPU 3 CPU 2 CPU 1 Key Component Description Power Jack The power adapter cable connects here. Console The cables from the console HDMI monitor, USB keyboard, Port USB mouse and speakers connect here. Each connector is Selection marked with an appropriate icon to indicate the connector type. -
Page 7: Single-Level Installation
Installation Note: Before beginning installation: • Make sure power to all devices that you will be connecting has been turned off. • It is recommended to properly ground the KVM switch to prevent damage to your installation from surges or static electricity. Single-Level Installation To set up single-level installation, refer to the following installation diagram (the numbers in the diagram correspond to the steps below) and perform the following: 8-PORT 4K HDMI Model: B024-H4U08 CPU 8 CPU 7 CPU 6 CPU 5... - Page 8 Plug secondary speakers into the audio port located on the unit’s rear panel (optional). Using Tripp Lite’s P782-0XX-HA HDMI/USB/Audio KVM cable kit or individual 4K HDMI, USB 3.0 and audio cables, plug the 4K HDMI connector into any available 4K HDMI port, then plug the accompanying USB 3.0 and audio cables into their corresponding ports.
-
Page 9: Warranty And Product Registration
2-Year Limited Warranty TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of two (2) years from the date of initial purchase. TRIPP LITE’s obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products. To obtain service under this warranty, you must obtain a Returned Material Authorization (RMA) number from TRIPP LITE or an authorized TRIPP LITE service center. Products must be returned to TRIPP LITE or an authorized TRIPP LITE service center with transportation charges prepaid and must be accompanied by a brief description of the problem encountered and proof of date and place of purchase. This warranty does not apply to equipment which has been damaged by accident, negligence or misapplication or has been altered or modified in any way. EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. -
Page 10: Regulatory Compliance
Regulatory Compliance FCC Notice, Class A This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. The user must use shielded cables and connectors with this equipment. Any changes or modifications to this equipment not expressly approved by Tripp Lite could void the user’s authority to operate this equipment. Regulatory Compliance Identification Numbers For the purpose of regulatory compliance certifications and identification, your Tripp Lite product has been assigned a unique series number. The series number can be found on the product nameplate label, along with all required approval markings and information. When requesting compliance information for this product, always refer to the series number. The series number should not be confused with the marketing name or model number of the product. Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice. Photos and illustrations may differ slightly from actual products. - Page 12 1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support 21-11-004 93406E_RevA...
