Quick Start Guide
NetDirector
1U Rackmount
™
KVM Switch with IP Access
Model # B022-U08-IP
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
Copyright © 2013 Tripp Lite. All rights reserved. All trademarks are the property of their respective owners.
The policy of Tripp Lite is one of continuous improvement. Specifications are subject to change without notice.
1
