LAN
/OPT
SD
1.2 Dimension
Note
The figures are for reference only, which are used to know the device dimension.
Please refer to the actual device for more details. The unit is mm (inch).
Network port /MB
optical fiber port
SD card port
GND
Table 1-1
Figure 1-4
Some devices are only equipped with 1 channel
audio input port.
LAN: Connect to standard Ethernet cable and
provide PoE power supply function.
OPT: Transmit MB Ethernet data.
Connect it to SD card.
Please make sure the device is securely earthed
to prevent the thunderstorm strike when using the
device.
4
