- Page 1 Cost-effective HD Indoor Network Camera User’s Manual Version 4.0.0 Zhejiang Dahua Technology CO.,LTD...
- Page 2 Welcome Thank you for purchasing our network camera! This user’s manual is designed to be a reference tool for your system. Please read the following safeguard and warnings carefully before you use this series product! Please keep this user’s manual well for future reference!
-
Page 3: Important Safeguards And Warnings
Important Safeguards and Warnings 1．Electrical safety All installation and operation here should conform to your local electrical safety codes. The power shall conform to the requirement in the SELV (Safety Extra Low Voltage) and the Limited power source is rated 12V DC or 24V AC in the IEC60950-1. (Refer to general introduction) Please note: Do not connect two power supplying sources to the device at the same time;... - Page 4 Do not touch the CCD (CMOS) optic component. You can use the blower to clean the dust on the lens surface. Always use the dry soft cloth to clean the device. If there is too much dust, please use the water to dilute the mild detergent first and then use it to clean the device.
-
Page 5: Table Of Contents
Table of Contents General Introduction ........................1 Overview ........................1 Features ......................... 1 Specifications ........................ 2 1.3.1 Performance ......................2 1.3.2 Factory Default Setup ................... 3 Structure ............................9 Rear Panel ........................9 Framework and Dimension ..................10 Device Installation ........................11 Quick Configuration Tool ...................... -
Page 6: General Introduction
1 General Introduction 1.1 Overview This series network camera integrates the traditional camera and network video technology. It adopts video data collection, transmission together. It can connect to the network directly without any auxiliary device. This series network camera uses standard H.264 video compression technology, which maximally guarantees the video quality. -
Page 7: Specifications
1.3 Specifications 1.3.1 Performance Please refer to the following sheet for network camera performance specification. Model IPC-HF2100 Series Parameter TI Davinci high performance DSP Main Processor Embedded LINUX Support real-time network, local record, and remote operation at the System same time. Resources Remote operation interface such as WEB, DSS, PSS User Interface... -
Page 8: Factory Default Setup
396 (18*22) detection zones; sensitivity level ranges from 1 to 100; Area threshold ranges from 1 to 100. Motion Detect Activation event: video storage, image snapshot, log, email and etc. Manual>External alarm >Video detect>Schedule Record Priority Storage Support display network storage status Management 1-channel wire Ethernet port, 10/100 Base-T Ethernet. - Page 9 Default Setup Setup Item IPC-HF2100 Series BLC Mode Mirror Flip Profile Management Normal Bit stream General type Encode mode H.264 Resolution 720P（1280*720） Frame Rate PAL: 25 NTSC:30 （FPS） Bit Rate Type Main PAL:1536-6124 Kb/S Stream Recommende d Bit NTSC:2048-6144Kb/S Bit Rate 4096 I Frame PAL:50...
- Page 10 UDP Port 37778 Connection HTTP Port RTSP Port Disable HTTPs On HTTPs Port Enable Disable PPPoE Username none Password Server Type Disable，Dahua DDNS Server www.dahuaddns.com Address DDNS Model Auto Domain “MAC address”. dahuaddns.com Name Username none IP Filter Trusted Sites Disable...
- Page 11 Default Setup Setup Item IPC-HF2100 Series Port Disable Anonymity anonymity Username Password **** Sender none Authenticatio none IPC Message Title Enable Attachment Mail Receiver 0 Second Interval Health Mail Disable，interval=60 Seconds UPnP Enable UPnP Disable SNMP Port Read public Community Write private Community...
- Page 12 Default Setup Setup Item IPC-HF2100 Series Command Enable Disable Anti-dither 5 seconds Record Enable Motion Detect Record Delay 10 seconds Send Email Disable Disable Snapshot Disable Enable Disable Record Enable Channel Video Record Delay 10 seconds Masking Send Email Disable Disable Snapshot Disable...
- Page 13 Default Setup Setup Item IPC-HF2100 Series Date Format Y-M-D Time Format Time Zone GMT+08:00 Current Time Sync DST Enable Disable DST Type Date Date and time Start Time 00:00:00 January 1 End Time 00:00:00 January 2 Synchronize Disable with NTP NTP Server clock.isc.org Port...
-
Page 14: Structure
2 Structure 2.1 Rear Panel You can refer to the following figure for rear panel information. See Figure 2-1 Figure 2-1 Rear panel Please refer to the following sheet for detailed information. Port Name Function Connection Note Video output Output analog video signal. Can connect to TV VIDEO OUT port monitor to view video. -
Page 15: Framework And Dimension
2.2 Framework and Dimension Please refer to the following figure for dimension information. The unit is mm. See Figure 2-2 and Figure 2-3. Figure 2-2 Dimension illustration 1 Figure 2-3 Dimension illustration 2... -
Page 16: Device Installation
3 Device Installation This series camera support two installation modes: wall mount and pendant mount. Important Please make sure the installation surface can min support the 3X weight of the camera and the bracket. Figure 3-1 Device installation illustration 1 Step 1 Please select the corresponding installation bracket before your installation. - Page 17 Figure 3-2 Device installation illustration 2 Step 5 After adjust the camera to proper surveillance position. Step 6 Secure the knob of the bracket to fix the camera.
-
Page 18: Quick Configuration Tool
4 Quick Configuration Tool 4.1 Overview Quick configuration tool can search current IP address, modify IP address. At the same time, you can use it to upgrade the device. Please note the tool only applies to the IP addresses in the same segment. 4.2 Operation Double click the “ConfigTools.exe”... - Page 19 If you want to modify the device IP address without logging in the device web interface, you can go to the configuration tool main interface to set. In the configuration tool search interface (Figure 4-1), please select a device IP address and then double click it to open the login interface.
-
Page 20: Web Operation
5 Web Operation This series network camera products support the Web access and management via PC. Web includes several modules: Monitor channel preview, system configuration, alarm and etc. 5.1 Network Connection Please follow the steps listed below for network connection. Make sure the network camera has connected to the network properly. - Page 21 Figure 5- 2 Web login If it is your first time to login in, system pops up warning information to ask you whether install web plug-in or not after you logged in for one minute. For detailed plug-in installation, please refer to the Web Operation Manual included in the resource CD.
- Page 22 Please refer to the Web Operation Manual included in the resource CD for detailed operation instruction.
-
Page 23: Faq
6 FAQ When network upgrade operation failed, you can use port 3800 to I can not upgrade continue upgrade. device network. I can not login the For Windows OS 98 or Windows ME user, if you can not install client-end or the the client-end or can not view after the installation. -
Page 24: Appendix Toxic Or Hazardous Materials Or Elements
If there is any uncertainty or controversy, please refer to the final explanation of us. Please visit our website for more information. Dahua Technology Co.,Ltd Address：No.1187 Bin’an Road, Binjiang District, Hangzhou, PRC. Postcode: 310053 Tel: +86-571-87688883 Fax: +86-571-87688815 Email:overseas@dahuatech.com...
