- Page 1 CMOS Camera BU Series BU302M-ES BU505M-ES Specifications Information contained in this document is subject to change without prior notice. D4247095A...
-
Page 2: Table Of Contents
Overview ............................. 5 Features .............................. 5 Configuration ............................7 Optional part ............................7 Functions ............................. 8 Specifications ............................ 15 Timing chart............................23 Warranty rules ........................... 25 Outline Drawing ..........................26 D4247095A Copyright © 2015 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp... -
Page 3: Restriction For Use
As this product is an engineering sample, you can use this product for your demo applications, or your system evaluation. You shall not sale this product, or shall not sale your system which is installed this product to the third parties. D4247095A Copyright © 2015 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp... -
Page 4: Cases For Indemnity (Limited Warranty)
CASES FOR INDEMNITY (LIMITED WARRANTY) As this product is an engineering sample, for any damage, resulting in association with the use of this product, we do not take any responsibility. D4247095A Copyright © 2015 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp... -
Page 5: Usage Precautions
If an intense magnetic or electromagnetic field is generated near the camera or connection cable, noise may be generated on the screen. If this occurs, move the camera or the cable. D4247095A Copyright © 2015 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp... - Page 6 The brightness of the upper part of the screen may be different from that of the lower part. Note that this is a characteristic of a CMOS image sensor and is not a fault. D4247095A Copyright © 2015 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp...
-
Page 7: Overview
Overview BU302M-ES and BU505M-ES are an integrated-(one-body)-type camera that adopts a global shutter CMOS sensor. For video output and camera control, the USB 3.0 interface standard is adopted for high transfer rate, and it is easy to integrate into industrial equipment. - Page 8 * IIDC2 is a unified standard established by JIIA (Japan Industrial Association). * e-CON (Easy & Economy connector) is a sensor connector that is normalized by the manufacturer of the sensor, FA equipment and connector. D4247095A Copyright © 2015 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp...
-
Page 9: Configuration
* No application software and manuals are attached to this camera. Optional part - Camera mounting kit Model name: CPTBU * Contact your dealer / distributor for details of option units. D4247095A Copyright © 2015 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp... -
Page 10: Functions
Arbitrary curve and binarization are possible by using 10 bit input and 10 bit output LUT. Exposure Time Manual exposure time control is available. Exposure time is adjustable by the internal sync signal. D4247095A Copyright © 2015 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp... - Page 11 - When the interval of the input trigger signal is extremely short, or when the trigger signal is noisy, there is a possibility of causing the malfunction. In this case, please input a proper trigger signal. D4247095A Copyright © 2015 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp...
- Page 12 - In Sequential Shutter mode, window size and position are unchangeable. Trigger Delay You can add the delay between trigger signal input and the start of exposure. Trigger signal TriggerDelay Exposure USB bus Image D4247095A Copyright © 2015 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp...
- Page 13 : End of transferring streaming data. (6) ExposureStart : Start of Exposure. (7) ExposureEnd : End of Exposure. (8) Timer0Start : Start of Timer0. (9) Timer0End : End of Timer0. D4247095A Copyright © 2015 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp...
- Page 14 An External trigger is input during this period, exposure starts immediately. EXT_TRIG Exposure CMOS Transfer USB Bus Delay Duration TIMER0 ACTIVE EXPOSURE ACTIVE FRAME ACTIVE FRAME TRANSFER FRAME TRIGGER WAIT * ActiveLow D4247095A Copyright © 2015 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp...
- Page 15 In the scalable mode, camera reads out only necessary area at the normal speed and reads out other area at high speed. The trigger interval can be shorter when the vertical height size is small. D4247095A Copyright © 2015 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp...
- Page 16 : All pixels 255 LSB (@ 8-bit) Gray A : Full screen 85 LSB (01010101 ) (@ 8-bit) Gray B : Full screen 170 LSB (10101010 ) (@ 8-bit) Horizontal ramp waveform Vertical ramp waveform D4247095A Copyright © 2015 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp...
-
Page 17: Specifications
User Free Memory Test Pattern Black, White, Gray A, Gray B Horizontal ramp waveform, Vertical ramp waveform (factory setting : OFF) Power supply DC +5V5% (from USB connector) Power consumption(*1) D4247095A Copyright © 2015 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp... - Page 18 User Free Memory Test Pattern Black, White, Gray A, Gray B Horizontal ramp waveform, Vertical ramp waveform (factory setting : OFF) Power supply DC +5V5% (from USB connector) Power consumption(*1) D4247095A Copyright © 2015 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp...
- Page 19 The exposure time depends on the MANUAL Exposure time setting 255 times (maximum) Number of Exposures in Bulk mode Sequential Shutter 16 entries (maximum) 0 to 2000000μs (factory setting : 0μs) Trigger Delay D4247095A Copyright © 2015 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp...
- Page 20 Delay 0 to 2000000μs (factory setting : 0μs) Duration TimerTriggerSource Line0Active, ExposureStart, FrameTrigger Interface specification Interface USB 3.0 (Only SuperSpeed is supported) Transmission speed 5Gbps (Maximum) Protocol USB3 Vision D4247095A Copyright © 2015 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp...
- Page 21 (e.g. dropping frames may occur). In this case, change to frame rate setting lower. Event notification FrameTrigger, FrameTriggerError, FrameTriggerWait Event name FrameTransferStart, FrameTransferEnd ExposureStart, ExposureEnd Timer0Start, Timer0End Event notification delay approx. 10us later from the event occurs Time stamp unit 16.7ns (60.0MHz) D4247095A Copyright © 2015 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp...
- Page 22 Humidity : +90% or less (no condensation) Notes on Heat Dissipation: - The temperature of camera housing must be kept less than 50 Celsius. Please provide sufficient heat dissipation depending on your installation. D4247095A Copyright © 2015 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp...
- Page 23 * Matching connector is not an accessory of this product. Pin assignment ↑TOP * Above figure is connector view from insert side. Pin No. Signal Name Function GPIO(Line2) GPIO Output GPIO(Line1) GPIO Output Ground TRIG_IN Trigger Input D4247095A Copyright © 2015 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp...
- Page 24 6.13 Typical spectral response The lens characteristics and light source characteristics is not reflected in table. D4247095A Copyright © 2015 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp...
-
Page 25: Timing Chart
Frame Rate setting BU505M-ES 12.9 13.3 by the application. * If the value of T2 is not set by the application, it will be the same as T1. D4247095A Copyright © 2015 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp... - Page 26 - When the interval of the input trigger signal is extremely short, or when the trigger signal is noisy, there is a possibility of causing the malfunction. In this case, please input a proper trigger signal. D4247095A Copyright © 2015 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp...
-
Page 27: Warranty Rules
Warranty rules As this product is an engineering sample, we do not provide any warranty period. If it seems to be a failure, please contact our sales representative. D4247095A Copyright © 2015 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp... -
Page 28: Outline Drawing
Outline Drawing D4247095A Copyright © 2015 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp... - Page 29 □ It certainly occurs. □ It sometimes occurs. □ It occurs, after time passes. （ □ Others ） <For dealer use> Reception date : Receipt No. : JOB No. : Check : D4247095A Copyright © 2015 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp...
