Managing Traces

Clearing a Trace from the Display

Clearing a Trace from the Display
Although the test application automatically loads the last traces used, you
can clear the screen and start new acquisitions. Also, if a trace (main or
reference) you acquired does not meet your requirements, it is possible to
clear that trace and start over.
To clear a trace from the display:
1. Press Storage in the main window.
2. From the Storage window, select New file. You must confirm that you
want to discard the current trace from the MWM test application.
3. Press OK. The trace is deleted from memory. Press Exit Storage to
return to the main window. You can now take a new measurement
and save the file. For more information, see Taking Measurements in
WDM Mode on page 49 and Taking Measurements in Drift Mode on
page 61.
Note: Deleting a trace from memory does not delete it from the storage media.

Renaming a Trace

Renaming trace files can help you manage them better.
To rename a trace:
1. Press Storage in the main window.
2. From the Storage window, select Rename file.
