Congratulations! Thank you for choosing Friedrich. Your Friedrich unit is designed for maximum comfort and quietness. Table of Contents Introduction ..................2 Safety Precautions...............3 How to operate your Friedrich ...........5 Adjusting the Air Flow Direction..........6 Care and Maintenance ..............7 Hardware Location ...............8 Installation Instructions............9... -
Page 3: Introduction
Introduction Before Operating Your Unit Make sure the wiring is adequate f or y our unit. If you have fuses, they should be of the time delay type. Before you install or relocate this unit, be sure that the amperage rating of the circuit breaker or time delay fuse does not exceed the amp rating listed in figure 1. DO NOT use an extension co r d. -
Page 4: Safety Precautions
For inner cleaning, contact an Authorized Service Center or a dealer. Do not use harsh detergent that causes corrosion or damage on the unit. Harsh detergent may also cause failure of product, fire, or electronic shock. -
Page 10: Installation Instructions
Installation Instructions Read these instructions completely and carefully. Tools You Will Need ❒ Phillips-head screwdriver ❒ Scissors or knife ❒ Flat-blade screwdriver ❒ Pencil ❒ Ruler or tape measure ❒ Level ❒ Hammer Before You Begin NOTE TO INSTALLER: Leave these CAUTION: instructions with the air conditioner after Do not under any circumstances, cut or remove... - Page 11 How to Install the Unit 1. To prevent vibration and excess noise, Fence make sure the unit is installed securely Awning and firmly. Cooled air 2. If possible Install the unit where the sunlight Heat does not shine directly on the unit. radiation 3.
- Page 12 Installation Kit Contents Type B:3EA Type A:13EA Type C:5EA (SCREW) (SCREW) (SCREW) Type E:2EA Type F:2EA Type G:2EA Type D:2EA (FRAME CURTAIN) (NUT) (SILL SUPPORT) (BOLT) 10mm Type H:1EA Type K:2EA Type L:1EA Type M:1EA (FOAM-STRIP) (FRAME-GUIDE) (WINDOWLOCKINGBRACKET) (FOAM-PE) Type N:1EA (DRAIN JOINT PIPE) Have the following tools available for installation: * Screwdriver (Slotted and Phillips)
- Page 13 Suggested Tool Requirements SCREWDRIVER(+, -), RULER, KNIFE, HAMMER, PENCIL, LEVEL Shipping screws PREPARATION OF CHASSIS 1. Remove the screws which fasten the cabinet at both sides and at the back. (Fig .1) 2. Slide the unit out from the cabinet by gripping the base pan handle and pulling forward while bracing the cabinet.
- Page 14 Cabinet Installation 1. Open the window. Mark a line on center of the window stool. Carefully place the cabinet on the window stool and align the center mark on the bottom front with the center line marked in the window stool. (Fig. 1) Upper Guide Window stool Front Angle...
- Page 15 6. The cabinet should be installed with a very slight tilt (about 1/2") downward toward the outside Screw(Type B) (See Fig. 5). Adjust the bolt and the nut of Sill Support for balancing the cabinet. Sill Support 7. Attach the cabinet to the window stool by driving Sash track the screws [Type B: Length 16mm (5/8 inch)
- Page 16 Fig.11...
- Page 17 Through-the-Wall Installation Instructions-Optional IMPORTANT The case may be installed through the wall (cont.) in both existing and new construction. Secure with 14 wood screws anchored at Read completely, then follow step-by-step. Ieast an inch into the wall support structure. NOTE: Obtain all materials locally for NOTE: Drill pilot holes, if necessary, for mounting the air conditioner through...
-
Page 18: Troubleshooting Tips
Troubleshooting Tips Troubleshooting Tips save time and money! Review the chart below first and you may not need to call for service. Normal Operation • You may hear a pinging noise caused by water being picked up and thrown against the condenser on rainy days or when the humidity is high. -
Page 19: Warranty
