  • Page 1 RoomAir Conditioners Chill Premiere Series Models Fixed chassis, cool only CCF05A10A, CCF06A10A, CCF08A10A, CCF10A10A CCF12A10A Slide out chassis, cool only CCW06B10A, CCW08B10A, CCW10B10A, CCW12B10A CCW15B10A, CCW18B30A, CCW24B30A Unifit Series Models Cool Only UCT08A10A, UCT10A10A, UCT10A30A, UCT12A10A, UCT12A30A, UCT14A30A Cool with Electric Heat UET08A11A, UET10A33A, UET12A33A, UET14A33A 93011400_00...

  • Page 2: Table Of Contents

    Table of Contents INTRODUCTION IMPORTANT SAFETY INFORMATION PERSONAL INJURY OR DEATH HAZARDS SPECIFICATIONS Electrical Data Product Dimensions OPERATION Remote Control Control Panel Sequence of Operation R-410A SEALED SYSTEM REPAIR Refrigerant Charging Undercharged Refrigerant Systems Overcharged Refrigerant Systems Restricted Refrigerant System Sealed System Method of Charging/ Repairs COMPONENT TESTING Hermetic Components Check...

  • Page 3: Introduction

    INTRODUCTION IMPORTANT SAFETY INFORMATION The information in this manual is intended for use by a qualified technician who is familiar with the safety procedures required for installation and repair, and who is equipped with the proper tools and test instruments required to service this product.

  • Page 4: Personal Injury Or Death Hazards

    INTRODUCTION PERSONAL INJURY OR DEATH HAZARDS WARNING AVERTISSEMENT ADVERTENCIA SAFETY FIRST Do not remove, disable Ne pas supprime, désactiver No eliminar, desactivar o or bypass this unit’s ou contourner cette l´unité pasar por alto los safety devices. Doing so des dispositifs de sécurité, dispositivos de seguridad de may cause fire, Doing so faire vous risqueriez de...
  • Page 5 INTRODUCTION PERSONAL INJURY OR DEATH HAZARDS • REFRIGERATION SYSTEM REPAIR HAZARDS: • Use approved standard refrigerant recovering procedures and equipment to relieve high pressure before opening system for repair. • Do not allow liquid refrigerant to contact skin. Direct contact with liquid refrigerant can result in minor to moderate injury.
  • Page 6 Installation procedures are not given in this manual. They are given in the Installation/Operation manual which can be aquired on the Friedrich website. IMPORTANT: It will be necessary for you to accurately identify the unit you are servicing, so you can be certain of...

  • Page 7: Specifications

    SPECIFICATIONS Model Cooling Heating Volts Cooling Cooling Heating Heating CEER Moisture Refrigerant Refrigerant Sleeve Weight Rated Amps Watts Amps Watts Removal- Charge Net./ Pints/HR Ship lbs. FIXED CHASSIS, COOL ONLY (WINDOW INSTALLATION ONLY) CCF05A10A 5200 — — — 12.1 12.1 R410A 12.35 44/51...
  • Page 8 — CCW10B10A, CCW12B10A — — CCW15B10A, CCW18B30A CCW24B30A — — Chill Premier Installation Figure 202 ( White- Fedders/ Sleeve Westinghouse/ Carrier (51S Friedrich USC Emerson/ Emerson/ Dimen- Amana Whirlpool Frigidaire/ Sleeve Friedrich Fedders Hotpoint Series) sions Carrier (52F Series) Height ”...

  • Page 9: Electrical Data

    SPECIFICATIONS Electrical Data WARNING NOTICE ELECTRIC SHOCK HAZARD FIRE HAZARD Turn off electric power before service or installation. electically unsafe conditions which could cause moderate All electrical connections and wiring MUST be or serious property damage. Read, understand and follow the above warning. the National Electrical Code and all local codes which have jurisdiction.
  • Page 10 SPECIFICATIONS Electrical Data WARNING Electrical Shock Hazard Make sure your electrical receptacle has the same configuration as your air conditioner’s plug. If different, consult a Licensed Electrician. Do not use plug adapters. Do not use an extension cord. Do not remove ground prong.Always plug into a grounded 3 prong outlet.

  • Page 11: Product Dimensions

    SPECIFICATIONS Product Dimensions Model A “(inches) B “(inches) C “(inches) Chill® Premier CCF05A10A, CCF06A10A 13 3/8 18 5/8 15 5/8 CCF08A10A 13 3/8 18 5/8 17 5/8 CCF10A10A, CCF12A10A 15 1/8 19 7/8 21 3/4 CCW06B10A, CCW08B10A, CCW10B10A, 14 5/8 19 3/4 23 3/4 CCW12B10A...

  • Page 12: Operation

    OPERATION Remote Control 1. Power: Turn the air conditioner on and off. This button will clear the TIMER setting. 2. MODE: Press the button to select the mode of operation, AUTO, COOL, DRY, FAN ONLY, HEAT. Note: The HEAT mode is only for some heating models. If you do not need it, press the MODE button for more than 5 seconds to delete the HEAT function, and the COOL mode will be selected automatically.

  • Page 13: Control Panel

    OPERATION Control Panel USING YOUR AIR CONDITIONER Cool Mode: The cooling function allows the air Electronic Control Panel & Remote Control conditioner to cool the room and at the same time reduces air humidity. Press the MODE button to NOTE: This display always shows the room temperature in Fan activate the cooling function.
  • Page 14 OPERATION Control Panel or HEAT mode and...

  • Page 15: Sequence Of Operation

    OPERATION Sequence of Operation Main function NOTES: RT------Room Temperature. IPT------Indoor Pipe (Coil) Temperature. ST------indoor Set Temperature. OPT---Outdoor Pipe (Coil) Temperature. CRT---Compensated Room Temperature 1. Cooling mode In the cooling mode, COOL indicator is ON, the set temperature and fan speed could be changed or adjusted. a.
  • Page 16 OPERATION Sequence of Operation temperature drop temperan1Ie 1ise 39.2°F ° 39.2 high speed wind 35.6° F ° 35.6 middle speed wind ° low speed wind Auto fan speed in cooling mode 2. Dry mode While selected to Dry mode, AC works at set temperature to 44.6°F for 3 minutes. After that the set temperature change to be RT 28.4°F, the compressor works as cooling mode, and indoor fan motor operates at low speed.
  • Page 17 OPERATION Sequence of Operation 4. Heating mode (for Cooling & Heating pump) When in heating operation mode, the set temperature, fan speed and air direction could be adjusted, compressor does not operate, but electrical heater works, and indoor fan motor starts up 10s later. a ST-RT≥...
  • Page 18 OPERATION Sequence of Operation a) The indoor fan runs at the set speed when processing sleep mode, after the 1st change, unit runs at low speed, and after the 2nd change, unit runs at low-low speed ( if AC without low-low speed, it runs at low speed instead).
  • Page 19 OPERATION Sequence of Operation a) The indoor fan motor runs for 1 min according to the set speed continuously, and then stops. b) The indoor fan keeps the stopping status in the following 10 min if RT meets the requirement of compressor stopping work.
  • Page 20 OPERATION Sequence of Operation Malfunction: buzzer BIBI shortly 3 times Protection / Failure code 1 Anti-frozen protection for indoor evaporator: If IPT≤32°F for continuous 3min, compressor shut off, fan motor keeps former operation; 3min later, if IPT≥50°F, compressor start up operation and fan motor keeps the former running status. 2 SENSOR error protection When sensor short circuit or broken, Room Temperature failure shows E1, and Coil Temperature failure shows E2.
  • Page 21 OPERATION Refrigeration Sequence Of Operation A good understanding of the basic operation of the refrigeration system is essential for the service technician. Without this understanding, accurate troubleshooting of refrigeration system problems will be more difficult and time consuming, if not (in some cases) entirely impossible.

  • Page 22: R-410A Sealed System Repair

    11. Introduce liquid refrigerant charge into the high side of the system. 12. For low side pressure charging of R-410A, use a charging adaptor. 13. Use Friedrich approved R-410A filter dryers only. IMPORTANT SEALED SYSTEM REPAIRS TO COOL-ONLY MODELS REQUIRE THE INSTALLATION OF A LIQUID LINE DRIER.

  • Page 23: Refrigerant Charging

    R-410A SEALED SYSTEM REPAIRS WARNING RISK OF ELECTRIC SHOCK Unplug and/or disconnect all electrical power to the unit before performing inspections, maintenances or service. Failure to do so could result in electric shock, serious injury or death. WARNING HIGH PRESSURE HAZARD Sealed Refrigeration System contains refrigerant and oil under high pressure.

  • Page 24: Undercharged Refrigerant Systems

    R-410A SEALED SYSTEM REPAIRS Undercharged Refrigerant Systems An undercharged system will result in poor WARNING performance (low pressures, etc.) in both the heating and cooling cycle. RISK OF ELECTRIC SHOCK Unplug and/or disconnect all electrical power to the unit before performing inspections, Whenever you service a unit with an undercharge of maintenances or service.

  • Page 25: Overcharged Refrigerant Systems

    R-410A SEALED SYSTEM REPAIRS Overcharged Refrigerant Systems Compressor amps will be near normal or higher. WARNING Noncondensables can also cause these symptoms. To confirm, remove some of the charge, if conditions RISK OF ELECTRIC SHOCK improve, system may be overcharged. If conditions Unplug and/or disconnect all electrical power to the unit before performing inspections, don’t improve, Noncondensables are indicated.

  • Page 26: Restricted Refrigerant System

    R-410A SEALED SYSTEM REPAIRS Restricted Refrigerant System Troubleshooting a restricted refrigerant system can be difficult. The following procedures are the more common problems and solutions to these problems. There are two types of refrigerant restrictions: Partial restrictions and complete restrictions. A partial restriction allows some of the refrigerant to circulate through the system.

  • Page 27: Sealed System Method Of Charging/ Repairs

    R-410A SEALED SYSTEM REPAIRS Sealed System Method of Charging/ Repairs CAUTION WARNING FREEZE HAZARD BURN HAZARD Proper safety procedures must be followed, Proper safety procedures must be followed, and proper protective clothing must be worn and proper protective clothing must be worn when working with liquid refrigerant.

  • Page 28: Component Testing

    COMPONENT TESTING Hermetic Components Check WARNING WARNING BURN HAZARD CUT/SEVER HAZARD Proper safety procedures must be followed, Be careful with the sharp edges and corners. and proper protective clothing must be worn when working with a torch. Wear protective clothing and gloves, etc. Failure to follow these procedures could Failure to do so could result in serious injury.

  • Page 29: Reversing Valve Description And Operation

    COMPONENT TESTING Reversing valve description and operation The Reversing Valve controls the direction of refrigerant flow to the indoor and outdoor coils. It consists of a pressure-operated, main valve and a pilot valve actuated by a solenoid plunger. The solenoid is energized during the heating cycle only.

  • Page 30: Testing The Reversing Valve Solenoid Coil

    COMPONENT TESTING Testing The Reversing Valve Solenoid Coil WARNING ELECTRIC SHOCK HAZARD Disconnect power to the unit before servicing. Failure to follow this warning could result in serious injury or death. The solenoid coil is an electromagnetic type coil mounted on the reversing valve and is energized during the operation of the compressor in the heating cycle.

  • Page 31: Checking The Reversing Valve

    COMPONENT TESTING Checking The Reversing Valve WARNING HIGH PRESSURE HAZARD Sealed Refrigeration System contains refrigerant and oil under high pressure. Proper safety procedures must be followed, and proper protective clothing must be worn when working with refrigerants. Failure to follow these procedures could result in serious injury or death.

  • Page 32: Replace The Reversing Valve

    COMPONENT TESTING Replace The Reversing Valve WARNING NOTICE FIRE HAZARD HIGH PRESSURE HAZARD The use of a torch requires extreme care and proper Sealed Refrigeration System contains refrigerant judgment. Follow all safety recommended precautions and and oil under high pressure. Proper safety procedures must be followed, notice could result in moderate to serious property damage.

  • Page 33: Touch Test Chart : To Service Reversing Valves

    COMPONENT TESTING Touch Test Chart : To Service Reversing Valves NORMAL FUNCTION OF VALVE NOTES: VALVE OPERATING * TEMPERATURE OF VALVE BODY CONDITION ** WARMER THAN VALVE BODY POSSIBLE CAUSES CORRECTIONS Cool Normal Cooling Cool *TVB as (2) as (1) Cool Normal Heating Cool...

  • Page 34: Compressor Checks

    COMPONENT TESTING Compressor Checks WARNING WARNING ELECTRIC SHOCK HAZARD BURN HAZARD Turn off electric power before service or installation. Proper safety procedures must be followed, All electrical connections and wiring MUST be and proper protective clothing must be worn when working with a torch. the National Electrical Code and all local codes which have jurisdiction.
  • Page 35 COMPONENT TESTING Compressor Checks WARNING WARNING HIGH PRESSURE HAZARD ELECTRIC SHOCK HAZARD Sealed Refrigeration System contains refrigerant Turn off electric power before service or and oil under high pressure. installation. Extreme care must be used, if it Proper safety procedures must be followed, becomes necessary to work on equipment with and proper protective clothing must be worn power applied.

  • Page 36: Compressor Replacement

    COMPONENT TESTING Compressor Replacement 1. Be certain to perform all necessary electrical and refrigeration tests to be sure the compressor is actually defective before replacing. WARNING 2. Recover all refrigerant from the system though the process tubes. PROPER HANDLING OF RECOVERED REFRIGERANT ELECTRIC SHOCK HAZARD ACCORDING TO EPA REGULATIONS IS REQUIRED.

  • Page 37: Compressor Replacement -Special Procedure In Case Of Compressor Burnout

    COMPONENT TESTING Compressor Replacement -Special Procedure in Case of Compressor Burnout 1. Recover all refrigerant and oil from the system. 2. Remove compressor, capillary tube and filter drier from the system. 3. Flush evaporator condenser and all connecting tubing with dry nitrogen or equivalent.

  • Page 38: Fan Motor

    COMPONENTS TESTING Fan Motor A single phase permanent split capacitor motor is used to drive the evaporator blower and condenser fan. A self- resetting overload is located inside the motor to protect against high temperature and high amperage conditions. Figure 23 WARNING Blower/Fan Motor ELECTRIC SHOCK HAZARD...

  • Page 39: Troubleshooting

    IS THE FRESH / EXHAUST AIR VENT OPEN? _____ ____ AREA TO BE APPROXIMATE IS A FRIEDRICH SLEEVE INSTALLED? _____ ____ CONDITIONED COOLING BTU IS A FRIEDRICH OUTDOOR GRILLE INSTALLED? _____ ____ IN SQ. FT. REQUIRED IS MAINTENANCE BEING PERFORMED? _____ ____ 100 - 150 5000...

  • Page 40: Product Does Not Operate At All

    TROUBLESHOOTING Product Does Not Operate At All Product does not operate at all. Power supply voltage check Product input voltage Power input voltage on driving load terminal. Connector contact check Display PCB connector Power transformer output voltage AC about 12±3V PCB assy check Figure 715...

  • Page 41: Indoor Fan Does Not Operate At All

    TROUBLESHOOTING Indoor Fan Does Not Operate At All Indoor fan does not operate at all. Check: Connector contact Motor output connector Motor capacitor Check: Fan(Blower) fixed state Fan(Blower) contact Moto r-related parts state Motor detail check Op eration mode check Check: Motor driving circuit PCB ass' y check...

  • Page 42: Compressor Or Outdoor Fan Does Not Operat At All

    TROUBLESHOOTING Compressor Or Outdoor Fan Does Not Operat At All Compressor or outdoor fan does not operate at all. Re-input after power of f Set the desired temperature of remote controller to be lower by 2°C or over than room temperature, and start the cooling operation. Repeat running/stopping Does not operate at all.

  • Page 43: Display E1 Or E2

    TROUBLESHOOTING Display E1 or E2 Display E1 and E2 Check the wire connection of indoor Connector contact temperature sensor assembl y. Replace sensor Replace main PCB Figure 716...

  • Page 44: Wiring Diagrams

    WIRING DIAGRAMS Chill Premier CCF Models: CCF05A10A CCF06A10A CCF08A10A CCF10A10A CCF12A10A Figure 801...

  • Page 45: Chill Premier Ccw

    WIRING DIAGRAMS Chill Premier CCW Models: CCW06B10A . CCW24B30A Figure 802...

  • Page 46: Chill Premier Ccw

    WIRING DIAGRAMS Chill Premier CCW CCW08B10A odels: Models: CCW10B10A.CCW12B10A.CCW15B10A Figure 803...
  • Page 47 WIRING DIAGRAMS Chill Premier CCW10B10A, CCW12B10A, CCW15B10A, CCW18B30A Models: CCW10B10A.CCW12B10A.CCW15B10A Figure 804...

  • Page 48: Unifit

    WIRING DIAGRAMS Unifit UCT08A10A, UCT10A10A, UCT12A10A, UCT10A30A, UCT12A30A, UCT14A30A Models: UCT08A10A UCT10A10A UCT12A10A UCT10A30A UCT12A30A UCT14A30A Models: UET10A33A UET12A33A UET14A33A UET08A11A Figure 805...
  • Page 49 WIRING DIAGRAMS Unifit UET10A33A, UET12A33A, UET14A33A, UET08A11A Models: UET10A33A UET12A33A UET14A33A UET08A11A Figure 806...

  • Page 50: Parts Catalog

    PARTS CATALOG Chill Premier Models: CCW06B10A CCW08B10A CCW10B10A CCW12B10A ITEM PART PART DESCRIPTION USED ON MODEL NUMBER 68000163 41106-003745_UI - Front Panel CCW06B10A, CCW08B10A,CCW10B10A Assembly 68000264 41106-003738_UI - Front Panel CCW12B10A Assembly 68000175 41507-000136 - Air Filter CCW06B10A, CCW08B10A, CCW10B10A, CCW12B10A 68000181 41505-000230 - Electrical Box CCW06B10A, CCW08B10A, CCW10B10A, CCW12B10A...
  • Page 51 PARTS CATALOG Chill Premier Models: CCW06B10A CCW08B10A CCW10B10A CCW12B10A ITEM PART PART DESCRIPTION USED ON MODEL NUMBER 68000211 41509-000049 - Adjustable shade CCW06B10A, CCW08B10A, CCW10B10A, CCW12B10A 68000221 41509-000053 - left Adjustable CCW06B10A, CCW08B10A, CCW10B10A, CCW12B10A shade rail 68000222 41508-000016_UI - Cabinet CCW06B10A, CCW08B10A, CCW10B10A, CCW12B10A 68000223 41509-000023 - Up Adjustable...

  • Page 52: Chill Premier Models: Ccw15B10A Ccw18B30A

    PARTS CATALOG Chill Premier Models: CCW15B10A CCW18B30A ITEM PART PART DESCRIPTION USED ON MODEL NUMBER 68000273 41106-003518_UW - Front Panel CCW15B10A, CCW18B30A Assembly 68000276 42008-000095 - Air Filter CCW15B10A, CCW18B30A 68000280 41504-000148_UW - Front Vortex Shell CCW15B10A, CCW18B30A 68000281 41214-001067_UW - Electrical Box Cover CCW15B10A, CCW18B30A supporter 68000282...
  • Page 53 PARTS CATALOG Chill Premier Models: CCW15B10A CCW18B30A ITEM PART PART DESCRIPTION USED ON MODEL NUMBER 68000301 41214-000856 - Pipe Cover (two-way) CCW15B10A, CCW18B30A 68000302 41602-000016_UW - Base CCW15B10A, CCW18B30A 68000303 92014-000260 - Compressor CCW15B10A 68000321 92014-000275 - Compressor CCW18B30A 68000304 22007-000280_UW - Compressor wire CCW15B10A, CCW18B30A 68000257...

  • Page 54: Chill Premier Models: Ccw24B30A

    PARTS CATALOG Chill Premier Models: CCW24B30A ITEM PART PART DESCRIPTION USED ON MODEL NUMBER 68000332 41106-003519_UW - Front Panel CCW24B30A Assembly 68000334 41507-000137 - Air Filter CCW24B30A 68000339 41205-000164 - Left Supporter CCW24B30A 68000340 41505-000229 - Electrical Box CCW24B30A Assembly 68000341 41507-000033 - Control Box panel CCW24B30A 68000342...
  • Page 55 PARTS CATALOG Chill Premier Models: CCW24B30A ITEM PART PART DESCRIPTION USED ON MODEL NUMBER 68000351 41509-000046 - left Adjustable CCW24B30A shade rail 68000352 41509-000018 - Adjustable shade CCW24B30A 68000353 41214-000579 - Adjustable shade CCW24B30A 68000354 41509-000025 - Up Adjustable CCW24B30A shade rail 68000355 41508-000009_UW - Cabinet...

  • Page 56: Chill Premier Models: Ccf05A10A Ccf06A10A Ccf08A10A

    PARTS CATALOG Chill Premier Models: CCF05A10A CCF06A10A CCF08A10A ITEM PART PART DESCRIPTION USED ON MODEL NUMBER 68000216 210826698 - Base CCF05A10A, CCF06A10A 68000145 210826701 - Base CCF08A10A 68000218 210755572 - Front Panel CCF05A10A, CCF06A10A, CCF08A10A Assembly 68000014 210736640A - Air Filter CCF05A10A, CCF06A10A, CCF08A10A 68000008 210755573 - Leading Flow Circle...
  • Page 57 PARTS CATALOG Chill Premier Models: CCF05A10A CCF06A10A CCF08A10A ITEM PART PART DESCRIPTION USED ON MODEL NUMBER 68000151 210736647A - Middle Vortex Shell CCF08A10A 68000125 210736644A - Down Vortex Shell CCF05A10A, CCF06A10A 68000152 210736648A - Down Vortex Shell CCF08A10A 68000053 210736635A - Back Partition plate CCF05A10A, CCF06A10A, CCF08A10A 68000126 211244320 - Discharge Pipe CCF05A10A...
  • Page 58 PARTS CATALOG Chill Premier Models: CCF05A10A CCF06A10A CCF08A10A ITEM PART PART DESCRIPTION USED ON MODEL NUMBER 25.9.2 68000138 210826603 - Sash lock CCF05A10A, CCF06A10A, CCF08A10A 25.9.3 68000139 210826602 - Lock Frame CCF05A10A, CCF06A10A, CCF08A10A 25.9.4 68000140 1180010035 - screw 4.2*9.5 CCF05A10A, CCF06A10A, CCF08A10A 25.9.5 68000141...

  • Page 59: Chill Premier Models: Ccf10A10A Ccf12A10A

    PARTS CATALOG Chill Premier Models: CCF10A10A CCF12A10A ITEM PART PART DESCRIPTION USED ON MODEL NUMBER 68000160 214146537B - Front Panel Assembly CCF10A10A, CCF12A10A 68000024 210755514 - Intake grille CCF10A10A, CCF12A10A 68000027 210736617A - Air Filter CCF10A10A, CCF12A10A 68000161 214146589D - Electrical Assembly CCF10A10A, CCF12A10A 68000162 210736672 - Cable Clamp...
  • Page 60 PARTS CATALOG Chill Premier Models: CCF10A10A CCF12A10A ITEM PART PART DESCRIPTION USED ON MODEL NUMBER 68000033 210901435 - Fan Motor CCF10A10A, CCF12A10A 68000034 210736727 - Centrifugal Fan CCF10A10A, CCF12A10A 68000182 210736653A - Down Vortex Shell CCF10A10A, CCF12A10A 68000184 211234297 - Compressor CCF10A10A 68000204 211234298 - Compressor...

  • Page 61: Unifit Models: Uct08A10A Uct10A10A Uct12A10A Uct10A30A

    PARTS CATALOG Unifit Models: UCT08A10A UCT10A10A UCT12A10A UCT10A30A ITEM PART PART DESCRIPTION USED ON MODEL NUMBER 68000055 210738331 - Display decorative UCT08A10A, UCT10A10A, UCT12A10A, UCT10A30A piece1 68000056 210738332 - Display decorative UCT08A10A, UCT10A10A, UCT12A10A, UCT10A30A piece2 68000057 210755503 - Front Panel UCT08A10A, UCT10A10A, UCT12A10A, UCT10A30A Assembly 68000058...
  • Page 62 PARTS CATALOG Unifit Models: UCT08A10A UCT10A10A UCT12A10A UCT10A30A ITEM PART PART DESCRIPTION USED ON MODEL NUMBER 68000377 210755615A - Display PCB cover UCT08A10A, UCT10A10A, UCT12A10A, UCT10A30A 68000132 210738277 - Control Box panel UCT08A10A, UCT10A10A, UCT12A10A, UCT10A30A 68000378 210836910 - Electrical Box UCT08A10A, UCT10A10A, UCT12A10A, UCT10A30A 68000040 210901721 - Transformer...
  • Page 63 PARTS CATALOG Unifit Models: UCT08A10A UCT10A10A UCT12A10A UCT10A30A ITEM PART PART DESCRIPTION USED ON MODEL NUMBER 68000048 210836767 - intake and outtake UCT08A10A, UCT10A10A, UCT12A10A, UCT10A30A grille 68000386 210836781A - Base UCT08A10A, UCT10A10A, UCT12A10A, UCT10A30A 68000051 210738265 - Water drainage pan UCT08A10A, UCT10A10A, UCT12A10A, UCT10A30A 68000035 210901453A - Power Supply Cord...

  • Page 64: Unifit Models: Uct12A30, Uct14A30A

    PARTS CATALOG Unifit Models: UCT12A30, UCT14A30A ITEM PART PART DESCRIPTION USED ON MODEL NUMBER 68000055 210738331 - Display decorative UCT12A30A, UCT14A30A piece1 68000056 210738332 - Display decorative UCT12A30A, UCT14A30A piece2 68000057 210755503 - Front Panel UCT12A30A, UCT14A30A Assembly 68000058 210755506 - Air Filter UCT12A30A, UCT14A30A 68000398 211238079 - Evaporator...
  • Page 65 PARTS CATALOG Unifit Models: UCT12A30A, UCT14A30A ITEM PART PART DESCRIPTION USED ON MODEL NUMBER 68000379 210836752 - Electrical Box Cover UCT12A30A, UCT14A30A 68000395 210901411H - Main pcb UCT12A30A, UCT14A30A 68000065 210736568 - Main pcb supporter UCT12A30A, UCT14A30A 68000380 210738282 - Capacitor Strip UCT12A30A, UCT14A30A 68000066 1170100004A - Compressor...

  • Page 66: Unifit Models: Uet08A11A Uet10A33A Uet12A33A

    PARTS CATALOG Unifit Models: UET08A11A UET10A33A UET12A33A 68000055 210738331 - Display decorative UET08A11A, UET10A33A, UET12A33A piece1 68000056 210738332 - Display decorative UET08A11A, UET10A33A, UET12A33A piece2 68000057 210755503 - Front Panel UET08A11A, UET10A33A, UET12A33A Assembly 68000058 210755506 - Air Filter UET08A11A, UET10A33A, UET12A33A 68000373 211244404 - Evaporator UET08A11A...
  • Page 67 PARTS CATALOG Unifit Models: UET08A11A UET10A33A UET12A33A 68000040 210901721 - Transformer UET08A11A 68000062 210901700 - Transformer UET10A33A, UET12A33A 68000041 210901745 - Fan Motor Capacitor UET08A11A 68000046 1170100030A - Fan Motor UET10A33A Capacitor 68000063 1170100034A - Fan Motor UET12A33A Capacitor 68000379 210836752 - Electrical Box Cover UET08A11A, UET10A33A, UET12A33A 68000042...
  • Page 68 PARTS CATALOG Unifit Models: UET08A11A UET10A33A UET12A33A 68000413 210738117 - Sensor supporter UET08A11A, UET10A33A, UET12A33A (outlet) 68000374 211244403 - Capillary Assembly UET08A11A -35A 68000392 211238698 - Capillary Assembly UET10A33A -35B 68000399 211238080 - Capillary Assembly UET12A33A 68000045 210901453D - Power Supply Cord UET08A11A -37A 68000052...

  • Page 69: Unifit Models: Uet14A33A

    PARTS CATALOG Unifit Models: UET14A33A ITEM PART PART DESCRIPTION USED ON MODEL NUMBER 68000055 210738331 - Display decorative piece1 UET14A33A 68000056 210738332 - Display decorative piece2 UET14A33A 68000057 210755503 - Front Panel Assembly UET14A33A 68000058 210755506 - Air Filter UET14A33A 68000407 211244409 - Evaporator UET14A33A...
  • Page 70 PARTS CATALOG Unifit Models: UET14A33A ITEM PART PART DESCRIPTION USED ON MODEL NUMBER 68000382 210836909A - Partition plate UET14A33A 68000409 211236912 - Compressor UET14A33A 68000068 210901723 - Fan Motor UET14A33A 68000401 211236902 - Discharge Pipe UET14A33A 68000069 210738266A - Back Partition plate UET14A33A 68000070 210738337 - Propeller Fan...

  • Page 71: Available Accessories

    Available Accessories Unifit USC SLEEVE An existing or new sleeve is required for installation. The Friedrich USC sleeve ships with the accessories needed for installation in new construction, or installation into an existing sleeve. INCLUDED WITH USC SLEEVE USC wall sleeve ships with weather panels (2) and grille.
  • Page 72 FRIEDRICH in your Room Air Conditioner fails because of a defect in workmanship or material within sixty months from date of purchase, FRIEDRICH will pay a labor allowance of $100 and parts necessary to repair the Sealed Refrigeration System;...
  • Page 73 THIS PAGE LEFT INTENTIONALLY BLANK.
