Owner's Guide and Installation Manual
Attach sales receipt to this card and retain as your proof of purchase
DATE OF PURCHASE:
MODEL NUMBER:
To register your fixture, please visit our website www.montecarlofans.com
5ATR56XXXD Series Fan
cETL Model NO. : 5ATR56XXXD
RETAILER NAME:
RETAILER ADDRESS:
8.2 kg
18.04 lbs
Total fan weight with light
Advertisement
Related Manuals for Monte Carlo Fan Company 5ATR56 Series
Summary of Contents for Monte Carlo Fan Company 5ATR56 Series
- Page 1 Owner’s Guide and Installation Manual 5ATR56XXXD Series Fan cETL Model NO. : 5ATR56XXXD Attach sales receipt to this card and retain as your proof of purchase DATE OF PURCHASE: RETAILER NAME: RETAILER ADDRESS: MODEL NUMBER: To register your fixture, please visit our website www.montecarlofans.com 8.2 kg 18.04 lbs Total fan weight with light...
-
Page 2: Cautions And Warnings
Cautions and Warnings WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING READ AND SAVE THESE INSTRUCTIONS Installation work and electrical wiring must be done by qualified person(s) in accordance with applicable codes and standards (ANSI/NFPA 70), including fire-rated construction. - Page 3 Mounting bracket Canopy Decorative ring Before you begin installing the fan, Switch Before installing this fan make sure the Remove decorative ring from canopy by turning counterclockwise. power off at Service panel and lock outlet box is properly installed to the service disconnecting means to prevent house structure.
-
Page 4: Safety Cable Installation
SAFETY CABLE INSTALLATION Keeper pin Cross pin Lag screw Safety cable Slot Washer Lock washer Slip downrod into motor housing yoke, Install ball end of downrod into mounting For Canadian installation and for USA fan aligning holes and install cross pin and bracket opening. - Page 5 Blade assembly Blade Groove Blade bracket Lift Canopy, aligning the key holes with Install blade bracket with blade by 2 Insert blade assembly into the slot on the preinstalled screws on canopy and blade set screws and washers provided. flywheel. turning clockwise till tight, and then Tighten screws securely.
- Page 6 LED light fixture Light shade Connect white wire from fan to white wire Attach light shade to light pan by locating from LED light kit and then connect blue dimples in light pan with grooves on the (or black) wire from fan to black (or blue) light shade and twist clockwise till tight.
- Page 7 Remote Controller Operation Remove the battery cover from the remote control transmitter and install batteries. Replace the cover. This remote uses 2 1.5V/AAA batteries. Note: If not using for long periods of time, remove battery to prevent DIM (D) damage to remote transmitter, and store the remote transmitter away from excess heat or humidity ON/OFF (O) Dimming, Non Dimming Setting (Only available for fans with light)
- Page 8 Install Transmitter wall mount cradle with 2 screws provided. Useful tips: Take remote transmitter up by pushing it at lower area of the transmitter. The remote transmitter can be held on magnetic metal materials by a magnet built in the transmitter. Wall mount cradle The receiver provides the following protective functions Lock protection- The DC motor has a build-in safety feature...
-
Page 9: Troubleshooting
Trouble Shooting or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, installation, please call our Customer Service Center at the number printed on your parts list insert sheet. Warning means to prevent power from being switched on accidentally. When the service disconnecting means cannot be locked, securely fasten a prominent warning device, such as a tag, to the service panel. - Page 10 Mar.2020...
