Summary of Contents for Monte Carlo Fan Company 5AHR60 Series
- Page 1 Owner’s Manual Ceiling Fan Installation Instructions Total fan weight with light kit included For 5AHR60 Series Fans READ AND SAVE THESE INSTRUCTIONS Quality Ceiling fans...
- Page 2 WARNING – Risk of fire, electric shock, or personal injury, The fan in this box may be either directly supported from a structural framing mem- ber of a building and/or may be mounted to an outlet box marked acceptable for fan support of 31.8 kg. (70 lbs.) or less. Most outlet boxes commonly used for the support of luminaires may not be acceptable for fan support and may need to be replaced.
- Page 3 Loosen the 2 downrod set screws to allow downrod intallation to the yoke. Lower upper glass disk onto fan housing and align 3 holes in glass with 3 holes in fan hous- ing. Align hole in arch arm and hole in tab the fan housing.
- Page 4 Hang assembled fan from the mounting bracket installed to ceiling in previous step. Make sure the fan is hanging straight. Rotate fan until the tab on the Mounting bracket engages the slot on the Downrod Ball. This must be done to prevent the fan body from rotating when the blades are in motion.
- Page 5 . If you have more than one fan with remote. You can set the dip switches to different positiosns to have seperate control. Attach cover of remote by placing over buttons and snaping into place.
- Page 6 If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart. If a problem cannot be remedied, or you are experiencing difficulty in installation, please call our Customer Service Center at the number printed on your parts list insert sheet.
