- Page 1 Owner’s Manual Ceiling Fan Installation Instructions Total fan weigh with light For 5AYR54 Series Fans READ AND SAVE THESE INSTRUCTIONS Quality Ceiling fans...
-
Page 2: Installation
Attach the mounting bracket using only the hardware supplied with the outlet box. To reduce the risk of fire or electric shock, do not use this fan with any solid state fan speed control device, or variable speed control. If this unit is to be installed over a tub or shower , it must be marked as appropriate for the application. - Page 3 . If you have more than one fan with remote. You can set the dip switches to different positiosns to have seperate control.
- Page 4 Plug white wire from fan to white wire from light kit. Then plug black wire from fan to black wire from light kit. Install glass bowl using the rubber washer and nut provided.
- Page 5 Place face plate over battery compartment and buttons. Place remote over 2 pins on front cover. Attach cover of remote by placing over 4 pins and snaping into place. Install wall control unit to outlet box using machine screws provided. Attach front cover to wall control with screws provided.
-
Page 6: Fan Speed
The light will cycle from bright to dim to bright until button is released. Light will FORWARD/REVERSE change rotation direction with fan running. MEDIUM SPEED high. To turn fan off press square”. maintain last setting if turned off. Depress rev button allow a few seconds for remote to FAN REVERSE... -
Page 7: Troubleshooting
If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart. If a problem cannot be remedied, or you are experiencing difficulty in installation, please call our Customer Service Center at the number printed on your parts list insert sheet. - Page 8 9/21/04 REV.0 New made from 5AHR manual...
