Summary of Contents for Monte Carlo Fan Company 5STR52
- Page 1 Owner’s Manual Ceiling Fan Installation Instructions Total fan weight For 5STR52 Fan READ AND SAVE THESE INSTRUCTIONS Quality Ceiling fans...
-
Page 2: Installation
Attach the mounting bracket using only the hardware supplied with the outlet box. To reduce the risk of fire or electric shock, do not use this fan with any solid state fan speed control device, or variable speed control. If this unit is to be installed over a tub or shower , it must be marked as appropriate for the application. - Page 3 Loosen the 3 screws with slots and remove the other 3 screws. Save the screws. Label Use this label on the fan body for the first blade arm starting position. Use caution with blade arms and blades. Any pressure on blade arms or blades...
- Page 4 Rotate fan so that the notch on the ball engages the ridge in the mounting bracket. This will allow hands-free wiring.
- Page 5 To control fan speed select from High, Medium or low speed buttons. To turn the fan off press the Fan on / off button. To dim lights press and hold button. To turn off light press and quickly release button. Press button marked REV to...
-
Page 6: Troubleshooting
If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart. If a problem cannot be remedied, or you are experiencing difficulty in installation, please call our Customer Service Center at the number printed on your parts list insert sheet.
